- Page 1 sales@artisantg.com artisantg.com (217) 352-9330 | Click HERE Find the Berkeley Nucleonics 555 at our website:...
- Page 2 555 Series Pulse Generator User's Manual Berkeley Nucleonics Corporation Phone (415) 453-9955 2955 Kerner Blvd. Fax (415) 453-9956 San Rafael, CA 94901 www.berkeleynucleonics.com Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
-
Page 3: Table Of Contents
Contents INTRODUCTION ..................1 Technical Support ......................1 Parts List ..........................1 Warranty ..........................1 Safety Issues ........................1 CONTROLS & CONNECTORS .............. 5 Front Panel ......................... 5 Display Layout and Indicators .................... 5 Keypads ..........................5 Parameter Adjustment Knob ..................... 6 BASIC OPERATION ................ - Page 4 SYSTEM Menu ....................... 14 Computer Communication Parameters ................14 Keypad Controls ......................15 Miscellaneous ........................15 STORE Menu ........................15 Storing a Configuration..................... 15 Configuration # ......................... 16 Name ..........................16 RECALL Menu ....................... 16 Recalling a Configuration ....................16 Configuration # .........................
- Page 5 CUSTOM FEATURES ................39 35 Volt Option ........................39 - iii - Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
- Page 6 - iv - Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
-
Page 7: Introduction
INTRODUCTION This manual is designed to familiarize you with the Berkeley Nucleonics Model 555 pulse generator. Rather than the usual array of knobs and switches, the 555 uses a menu-driven user interface with “on-line” help -- once you learn the basics of operating your 555, you may never need to refer to this manual again. -
Page 8: Safety Issues
Berkeley Nucleonics does not warrant the operation of this product to be uninterrupted or error free. This product is not intended for medical or life-support use, for the detonation of explosive devices, or for any other application that could cause bodily harm in the event of a product malfunction. - Page 9 6. Never work alone. Someone should always be nearby to render aid if neces- sary. Training in CPR first aid is highly recommended. 7. Safety symbols used on the instrument - Instruction Manual symbol (user must refer to the instruction manual) - On/Standby switch symbols: Standby - 3 -...
- Page 10 - 4 - Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
-
Page 11: Controls & Connectors
CONTROLS & CONNECTORS Front Panel Display Layout and Indicators A 4 line x 20 character vacuum fluorescent display module displays parameters and status information. The status information is located in the upper-left corner of the display, between the two brackets. There are three enunciators: •... -
Page 12: Parameter Adjustment Knob
To enter two letters which appear on the same keycap, select the first character, then use the right arrow to shift to the next position and enter the next letter. When data entry is com- plete the ENTER key must be pressed. Parameter Adjustment Knob An alternate to the Arrow Keypad, the Parameter Adjustment Knob may be used to adjust the current parameter. -
Page 13: Basic Operation
Basic Operation Overview Gate Internal System Timer Internal and System Mode To Pulse Start Generator Command External Input Start Output Output Gate Channel Timers and Channel Pulses Mode Generators *Start source is: RUN button in Internal Modes * Start source is: RUN button in Internal Modes External input in External Trigger modes External input i n External trigger modes ** Channels are armed by the RUN button. -
Page 14: Quickstart
Burst a pulse is generated for each To pulse, 'n' times, after which output is inhibited Divide-by-n a pulse is generated every n To pulse Different modes may be selected for each output, allowing a wide variety of output combina- tions. -
Page 15: Selecting Menus
• Enter the RATE menu, by pressing the FUNCTION key and then the "4" key. Set the desired pulse period. Note that in general the pulse delay plus pulsewidth should be less than the period. • Press the RUN key. Selecting Menus Parameters are grouped in menus, selectable using the function keys. -
Page 16: Item Edit Mode
Item Edit Mode When the current item is non-numeric, the Up and Down arrow keys are used to select among different options for the parameter. The adjustment knob may also be used to change the selection. If the item is an on/off toggle, the Up arrow (CW adjustment knob) enables the item and the Down arrow (CCW adjustment knob) disables the item. -
Page 17: Menus
MENUS CHANNEL Menu CHANNEL Menus Timing Parameters Pulse Configuration Special Functions Gated Operation Enable Enable Enable Enable Polarity Pulsewidth Output Type Mode Gate Enable Divide-by-N Delay Output Level # / Burst Enable/Disable The top of each Channel menu page is a parameter to enable or disable the output of the channel. -
Page 18: Special Functions
Special Functions • MODE Selects the channel output mode: continuous, single shot, burst, or divide-by-n. • #/BURST Sets the number of pulses to be generated in the burst mode. • DIVIDE-BY-N Sets the divisor for the divide-by-n mode. Gated Operation •... -
Page 19: Rate Menu
• DC ON Sets the number of pulses to be generated each on cycle when in the Duty Cycle mode.. • DC OFF Sets the number of pulses to skip each off cycle when in the Duty Cycle mode. *NOTE: Any mode may be started by either the RUN key in the internal trigger mode or armed by the RUN key and started by an external trigger in the external trigger mode. -
Page 20: Gate/Trigger Mode
Gate/Trigger Mode • MODE Selects external input usage for controlling To: disabled, edge triggered or level gated. • THRESHOLD Sets the voltage threshold for the external input. This level is applied to all uses of the external input. • EDGE Selects rising or falling edge for the trigger mode. -
Page 21: Keypad Controls
Keypad Controls • KEY REPEAT RATE Sets the rate at which the keys will repeat when held down. This is most useful when using the Up/Down arrows to change parameters. • KEY VOLUME Sets the key click volume. • KNOB VOLUME Sets the parameter adjustment knob click volume. -
Page 22: Configuration
• Label the configuration as desired. Press enter key to save label. • From the Store menu, press the store button (function + store). Configuration # Specifies the location to store the current system configuration. Numbers range from 1 to n, where "n"... -
Page 23: Auxiliary Menus
AUXILIARY Menus AUX 1 Menu Pulsewidth D e l a y Ch A Pulsewidth Ch A Delay Ch B Pulsewidth Ch B Delay Ch C Pulsewidth Ch C Delay Ch DPulsewidth Ch D Delay The auxiliary menus provide a location for special functions to be added for semi-custom units. In addition, the Auxiliary 1 menu provides summary menus for pulsewidth and delay. - Page 24 - 18 - Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
-
Page 25: Basic Operation
BASIC OPERATION With the channels in the normal mode, operation of the unit is controlled by the system mode and the external trigger. The basic modes are as follows: Operational Modes w/o External Trigger Continuous RUN/STOP button starts and stops a continuous pulse stream at the rate specified by the RATE menu. - Page 26 Single Shot RUN/STOP button arms unit. Generates a pulse for every external trigger received. Press the RUN/STOP button a second time to disarm the instrument. This corresponds to the normal externally triggered mode for most pulse genera- tors. Burst RUN/STOP button arms unit. Generates a stream of "n" pulses where "n"...
-
Page 27: Computer Interface
COMPUTER INTERFACE Serial Port Pinout 1. No Connection 2. Tx - Transmit (to computer) 3. Rx - Receive (from computer) 4. DTR - connected to pin 6 5. Ground 6. DSR - connected to pin 4 7. RTS - connected to pin 8 8. -
Page 28: Scpi Command Keywords
SCPI Command Keywords The commands are shown as a mixture of upper and lower case letters. The upper case letters indicate the abbreviated spelling for the command. You may send either the abbreviated version or the entire keyword. Upper and/or lower case characters are acceptable. For example: If the command keyword is given as POLarity, the POL and POLARITY are both acceptable forms;... -
Page 29: Scpi Keyword Separator
SCPI Keyword Separator A colon ( : ) must always separate one keyword from the next lower-level keyword. SCPI Option Keyword Optional keywords and/or parameters appear in square brackets ( [ ] ) in the command syntax. Note that the brackets are not part of the command and should not be sent to the pulse genera- tor. -
Page 30: Error Codes
<identifier> Selects from a finite number of predefined strings. Error Codes The unit responds to all commands with either: ok <cr> <lf> ?n <cr> <lf> Where "n" is one of the following error codes: Incorrect prefix, i.e. no colon or * to start command. Missing command keyword. -
Page 31: Interface Examples
Interface Examples Example 1) - 20 ms pulsewidth, 2.3 ms delay, 10 Hz, internal, continuous operation. :PULSE1:STATE ON <cr> <lf> enables channel A :PULSE1:POL NORM <cr> <lf> sets polarity to active high :PULSE:WIDT 0.020 <cr> <lf> sets pulsewidth to 20 ms :PULSE1:DELAY 0.0023 <cr>... - Page 32 Model 555 SCPI Command Summary Std/ Keyword P a r a m e t e r Comments N e w Subsystem. Supports treating each channel as a :INSTrument logical instrument. Query only. Returns a comma-separated list of the :CATalog? names of all channels. A two channel instrument would return: To, ChA, ChB.
- Page 33 Model 555 SCPI Command Summary Std/ Keyword Parameter Comments Subsystem. Contains commands to control the output pulse generation. Commands without suffix :PULSe [0] refer to the currently selected logical instrument. See INSTrument subsystem. Enables / Disables the output for all channels. : STATe <boolean value>...
- Page 34 Model 555 SCPI Command Summary Std/- Keyword Parameter Comments Subsystem. Contains commands to control the output pulse generation. Valid suffix range depends on the number of channels (CHA = 1, ChB = 2, :PULSe [1 / 2 / n] etc). Command without suffix refers to the currently selected logical instrument.
- Page 35 Model 555 SCPI Command Summary Std/ Keyword Parameter Comments Subsystem. Contains commands to control the :DISPlay display. Controls intensity of display. Range is 0 to 1, where :BRIGhtness <numeric value> 0 is off and 1 is full intensity. :UPDate Query Query only.
- Page 36 IEEE 488.2 Common Commands Mnemonic Command Name Parameters Comments Queries the Pulse Generator Identification. The ID *IDN? Identification Query will be in the following format: model#-option#-version# Restores the state of the Pulse Generator from a *RCL Recall Command <numeric value> copy stored in local nonvolatile memory (0 through 10 are valid memory blocks).
-
Page 37: Specifications
SPECIFICATIONS Internal Rate Generator • Trigger Modes Single shot, continuous, burst, duty cycle • Rate 1?? s - 99.99999999 s (.01 Hz to 1 Mhz) • Resolution 100 ns • Accuracy 1 ns + .0001 x period • Jitter 1 ns (RMS) •... -
Page 38: External Trigger And Gate
External Trigger and Gate • Rate DC - 1 MHz • Threshold 100 mV - 12V • Insertion Delay < 250 ns • Jitter 15 ns (RMS) • Trigger Slope Rising or falling edge • Gate Active low or active high •... -
Page 39: Menu Summary
MENU SUMMARY CHANNEL Menus Timing Parameters Pulse Configuration Special Functions Gated Operation Enable Enable Enable Enable Polarity Pulsewidth Output Type Mode Gate Enable Divide-by-N Delay Output Level Polarity # / Burst MODE Menus To Mode To Mode To Mode To Mode Oscillator MODE: Continuous MODE: Single Shot... - Page 40 GATE/TRIGGER Menus Gate/Trigger Mode Gate/Trigger Mode Gate/Trigger Mode MODE: Disabled MODE: Triggered MODE: Gated THRESHOLD THRESHOLD THRESHOLD EDGE POLARITY SYSTEM Menus Keypad Comm. Parameters Misc. Parameters Parameters Baud Rate Key Repeat Rate Echo Enable Key Volume Decimal Mark GPIB Address Knob Volume LCD Brightness STORE Menu...
- Page 41 AUX 1 Menu Pulsewidth Delay Ch A Pulsewidth Ch A Delay Ch B Pulsewidth Ch B Delay Ch C Pulsewidth Ch C Delay Ch D Pulsewidth Ch D Delay - 35 - Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
- Page 42 - 36 - Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
-
Page 43: Maintenance
MAINTENANCE The Model 555 pulse generator has no user-serviceable parts. For repair, contact your dis- tributor. - 37 - Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com... - Page 44 - 38 - Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
- Page 45 CUSTOM FEATURES 35 Volt Option For units with the optional 35 volt output, additional BNC connectors are provided on the rear panel. The 35 volt output can be enabled independently for each of the channels from the channel output mode menu. When enabled, the rear panel outputs will provide an adjustable output from 2 volts to 38 volts and the timing will be calibrated to all other channels.
- Page 46 - 40 - Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com...
