INSTALLATION AND CARE GUIDE
Ventilation Fan with LED Light
MEW-VF270L
READ AND SAVE THESE INSTRUCTIONS
Please read these instructions carefully before installing, operating or servicing the fan.
Failure to comply with the instructions contained herein could result in personal injury
or property damage. We recommend that you keep this guide for future reference.
1
Advertisement
Table of Contents
Related Manuals for Maxxima Luvoni MEW-VF270L
Summary of Contents for Maxxima Luvoni MEW-VF270L
- Page 1 INSTALLATION AND CARE GUIDE Ventilation Fan with LED Light MEW-VF270L READ AND SAVE THESE INSTRUCTIONS Please read these instructions carefully before installing, operating or servicing the fan. Failure to comply with the instructions contained herein could result in personal injury or property damage.
- Page 2 If this unit is to be installed over a tub or shower, it must be marked as a appropriate for the application. When the fan is going to install in the bathroom, the fan and the tub need to be more than 1.0 meter between each other, the fan required to install at the other side of the tub in ceiling.
- Page 3 39.6W Current : 0.33A Lumen Output / CCT: 600LM / 3000K To Switch To Neutral To Switch To Neutral To Ground...
-
Page 4: Warranty
Warranty Three Year Warranty: Maxxima extends a 3 year limited warranty to the original purchase that the products listed are free from defects in material and/or workmanship only. Maxxima will replace any warrantied product to the original consumer/purchaser if the product fails because of defects due to workmanship and/or materials within the limited warranty period. -
Page 5: Package Contents
Pre-installation (continued) HARDWARE INCLUDED I � NOTE: Hardware shown to actual size. Part Description Quantity Long wood screw (04x30) PACKAGE CONTENTS Part Description Quantity Fan Body Grille Duct Connector... - Page 6 Pull the wire through the hole and into the junction box(not included). Using UL approved wire nuts (not included),secure 120 VAC house...
- Page 7 Typical hole cutout is 7.5" X 7.3"...
- Page 9 Pull the wire through the hole and into the junction box(not included). Using UL approved wire nuts (not included),secure 120 VAC house...
-
Page 10: Care And Maintenance
If the fan clears steam from the room within approximately 15 � minutes of completeing your shower, then the fan is operating properly. 125 Cabot Court Hauppauge, NY 11788 info@maxximastyle.com 866-MAXXIMA (629-9462) www.maxximastyle.com...
