- Page 1 G4224Tv2 Twisted Pair Switch Quick Start Guide GIGA Copper Networks GmbH...
-
Page 2: Package List
Package List G4224T *1 Serial Cable *1 Screw kit Power line Rj21 line Wall-mount kits Sync cable Grounding wire Hardware Introduction 2.1 Physical Dimensions • Dimension (W*D*H): 440mm*268mm*44.5mm,19-inch rack-mount, 1U height. • Case: Aluminum, degree of protection IP30 • Weight: 5.2Kg •... - Page 3 2.2 Front Panel G4224T Front Panel Description: 2.2.1 Panel Description Label Description 24 * G.hn Wave2 ports (RJ45 connector), MIMO and SISO Ghn1-24 1 * 10/100/1000BT RJ45 port for device management MGMT 10G 1/2 2 * 1000-X/10000-X SFP/SFP+ ports CON 115200 1 * RJ45 connector RS232 console for connection to a computer control/ administration.
- Page 4 2.2.2 LED Description Label Type Color State Description Link up Uplink SFP/SFP+ 10G 1/2 Green Blinking Data is transmitting ports status Link down MGMT Port is link up Green MGMT Port is link down or link speed is 100Mbps Management port MGMT status Blinking...
- Page 5 3. Application Diagram and installation instruction 3.1 Application 3.2 Sync Installation If there is only one G4224T, you needn’t use SYNC port. But if there is more than one G4224T, just only one is the primary and the rest are NOTE secondary.
-
Page 6: Chassis Installation
3.3 Chassis Installation Step 1. Insert the screws Step 2. Put the G4224T chassis into the 19’’ rack and tighten it. If there are more than one G4224T chassis need to be installed, please left 0.5U space between chassis to achieve better cooling effect NOTE Step 3. - Page 7 4. G.hn Cable and Connectors Device Supported connectors Supported MIMO RJ45 8P8C RJ11 6P6C RJ11 6P4C Phone Line MDU RJ11 4P4C RJ11 4P2C RJ11 6P6C RJ11 6P4C RJ11 4P4C Phone Line CPE RJ11 4P2C 2 Pairs Cable Application MDU needs to be configured as MIMO mode.
-
Page 8: Default Configuration
Single Pair Cable Application MDU needs to be configured as SISO mode. 5. Login 5.1 Default Configuration: Default IP Address IP Address: 192.168.0.252 IP Sub network: 255.255.255.0 Accounts: User name: superuser Password: 5.2 Login via WEB Interface You can browse http://192.168.0.252 and type user name and password... - Page 9 6. Configure IP You can configure IP Address from “VLAN Management >> VLAN Interface” of left menu 7. G4224T-RJ21 PIN Definition (Optional） G.now RJ21 Pin Color RJ21 Pin Color port 1-24 Blue White Orange White Green White Brown White Gray White Blue Orange...
