MAIN CHARACTERISTICS OF THE MOTOR MC10
Feeding
Power
Max. weight of the gate
Speed
Maximum torque
Temporary service
230 Vca 50 Hz + -10 %
650W 0.9HP
2000 Kg
9 m/min
5 daN
30 %
Protection Grade
Working temperature
Capacitor
Clutch
Thermal protection
IP44
- 20°C +70 °C
25 uF 400 V
Double disk
130 °C
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for B&R MC10
Summary of Contents for B&R MC10
- Page 1 MAIN CHARACTERISTICS OF THE MOTOR MC10 Feeding 230 Vca 50 Hz + -10 % Protection Grade IP44 Power 650W 0.9HP Working temperature - 20°C +70 °C Max. weight of the gate 2000 Kg Capacitor 25 uF 400 V Speed 9 m/min...
-
Page 2: Typical Installation
TYPICAL INSTALLATION Motor Photocells Key selector Blinker Receiver / Antenna Throughout the installation procedure the board has to be switch CHECKING BEFORE INSTALLATION off. The disposition of materials has to be done in accordance with the Before doing the installation is suggested to do the following operations: current laws. -
Page 3: Installation
The no observance of the described notes could cause damages to persons, animals or objects. In such case the producer can’t be considered responsible 10. Sold the 3 spacing bars of the element. los tres INSTALLATION distanciadores del elemento. 11. In order to obtain the right slack between rack and pinon, Do an excavation for the foundation plate, fix the anchors lower the gear of 1.5mm moving the screws of the to the plate by the furnished screws. -
Page 4: Maintenance
PLACING OF PLATES FOR MAGNETICAL LIMIT SWITCHES ORDINARY MAINTENANCE: Each one of the following operations must be done when we realize the need and in any case every 6 Plate L.S. in closing (Fig 6). Position the gate in complete months. -
Page 5: Ce Statement Of Conformity
CE STATEMENT OF CONFORMITY PROGET s.r.l declares that the product MC10 complies with the essential requisites contained in the following UE directives: - directive on the electromagnetic compatibility 89/336/EEC - directive R&TTE 99/05/EC - directive on the low voltage 73/23/CEE... -
Page 6: Statement Of Conformity
STATEMENT OF CONFORMITY Annex 2 (Machine Directive 98/37/CE, Enclosure II, part A) Constructor: Address: States that: Door/Gate description, model, ID number) Location: (Address) It complies with: □ 98/37/CE Machinery Directive It states that have been observed the following rules: □... -
Page 7: Maintenance Register
Annex 1 MAINTENANCE REGISTER page 1 Technical assistance: Name, address, telephone, technician of reference ) This register contains technical references and registrations of the activities related to installation, maintenance, repairing and modification done, and it has to be available for eventual inspections from authorized organisms. TECHNICAL DATA OF THE MOTORIZED DOOR/GATE AND ABOUT THE INSTALLATION Client: Name, address, person in charge... - Page 8 Annex 1 MAINTENANCE REGISTER page 2 Description of the intervention (Tick the square according to the intervention done. Describe the possible residual risks and/or the foreseeable improper use) □ □ □ □ □ □ Installation Starting Regulations Maintenance Repairing Modifies Notes: Trimmer:...
