can use.
7.2 COPYING CONFIGURATION between DATAFLOW RTU Units: This note explains how to
TO COPY CONFIGURATION FROM AN OLDER-FIRMW AREDATAFLOW RTU TO A
NEWER-FIRMWARE DATAFLOW RTU, while preserving the default settings of additional
programmable features:
7.2.1 Connect older-firmware unit to the serial cable and power supply.
7 .2.2 From the Programmer Main Screen, press "2" to select DATAFLOW RTU configuration.
7.2.3 Press "F3' to Upload.
7.2.4 Enter a filename in the "File Name" field.
7.2.5 Press "F6" to write this configuration to the (named) file.
7.2.6 Disconnect the older-firmware unit from the serial cable and power supply.
7.2.7 Connect the newer-firmware unit to the serial cable and power supply
7.2.8 Press ''F3" to Upload from the new unit.
7 .2.9 Enter the filename from Step 4 in the "File Name" field.
7.2.10 Press "F5" to Read the (named) file.
7 .2.11 Press ''F4" to download the configuration to the newer-firmware unit
7.2.12 Press "FlO" to Return to the Programmer Main Screen.
7.3
TO COPY ALL INFORMATION from source-configuration DATAFLOW RTU to same-version
targetDATAFWW RTU:
7.3.1 Connect older-firmware unit to the serial cable and power supply.
7.3.2 From the Programmer Main Screen, press "2" to select DATAFLOW RTU configuration.
7.3.3 Press "F3' to Upload.
7.3.4 Disconnect the source-configuration unit from the serial cable and power supply.
7.3.5 Connect the (same-version) target unit to the serial cable and power supply.
7.3.6 Press "F4" to download the configuration to the target unit.
7.3. 7 Press "Fl O" to Return to the Programmer Main Screen .
8. APPLICATION EXAMPLES
8.1 The following examples provide demonstrations ofRITRON
operation. All examples are included and can be loaded as Software Programming
configuration files on the accompanying programming disk.
8.1.1 These are not "stand alone" examples. Examine and understand each example in sequence
before proceeding to the next. These illustrations and demonstrations have been designed
to run in a laboratory environment using dummy loads for antennas.
8.1.2 The frequency programmed into the configuration files is 460 MHz. If your RTU system
does not operate in this band, change the configuration file frequency to reflect a value you
8.1.3 UPLOAD or DOWNLOAD commands that change RTU configuration also disable the
transmitter. Cycle the RTU by turning it OFF then ON to re-enable the transmitter and re­
establish normal RTU operation.
preserve programmed default settings.
