Mika Shorty Bunk
(75x175cm)
Before You Start
Important: Retain these instructions for future reference.
When you are ready to start, make sure that you have the right tools, plenty of space and a
clean, dry area for assembly.
Unwrap all packaging materials and place the components on top of the carton box or on a
clean floor to prevent it from scratching.
Check the pack and make sure you have all the parts listed.
During assembly children should be kept away from the product due to possible risk of injury.
Tools not included.
Do not use power tools to construct this product.
Due to the size of this product we recommend that it is assembled in the room intended for
use.
Ensure that this product is fully assembled as illustrated before use.
Warnings
This product is intended for a maximum weight of 100 kg. Do not exceed this weight.
It is recommended that 2 people are required to assemble this product.
This product should only be used on firm, level ground.
Make sure the legs remain in contact with the ground.
Keep small parts out of reach of children.
Check all screws or bolts are tightened and inspect regularly.
Do not tighten screws until fully assembled.
Do not over tighten screws or bolts.
Do not use this product if parts are missing, damaged or worn.
Do not allow children to jump on the bed as this could cause damage to the frame.
This product complies with the requirements of UK Bunk Beds Entrapments Hazards Safety
Regulations 1987 and the European Standard EN 747-1 & 2 : 2007
Top bunk not recommended for children under the age of 6 years. Be aware of the danger of
young children (under 6) falling from the upper bunk.
The top of the mattress must not come above the line marked on the bed.
Care Instructions
To clean wipe with a sponge and warm soapy water. Do not use solvent based cleaners or
detergents as they can bleach or damage the product.
Version 1

Advertisement

loading
Need help?

Need help?

Do you have a question about the Mika Shorty Bunk and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Tesco Mika Shorty Bunk

  • Page 1 Mika Shorty Bunk (75x175cm) Before You Start • Important: Retain these instructions for future reference. • When you are ready to start, make sure that you have the right tools, plenty of space and a clean, dry area for assembly.
  • Page 2: Parts List

    Parts List: x 4 PCS (Metal post) x 2 PCS x 2 PCS (Side Rail) x 2 PCS (Headboard /Footboard) (Ladder) x 4 PCS (Metal slat joint) x 1 PC(Long safety rail) x 2 PCS (Metal slat) x 3 PCS (Ladder steps) x 1 PC(Short safety rail) x 2 PCS (Headboard / Footboard)
  • Page 3 Fitting List:- M6 X 20MM 38MM Fitting List:- M6 X 20MM 25 X 50 MM Version 1...
  • Page 4 Fitting List:- Fixing G is used to press down the wire to insert part 5 into part 7 & 8 then release. Remove Fixing G from part 5 and then repeat this all parts 5's are fitted. During assembly, if the pin does not come out, Twist left please follow the steps below to adjust, and right...
  • Page 5 Fitting List:- Fixing G is used to press down the wire to insert part 5 into part 3, then release. Remove Fixing G from part 5 and then repeat this all parts 5's are fitted. During assembly, if the pin does not come out, Twist left please follow the steps below to adjust, and right...
  • Page 6 Fitting List:- M8 X 80MM Fitting List:- M6 X 60 MM M6 X 45 MM (Jcn nut) 25MM (Hex nut 6m) Version 1...
  • Page 7 Fitting List:- Important note The mattress should not be above this max. mattress height. Be aware of the danger of young children (under 6) falling from the upper bunk sticker. Version 1...
