  • Page 1 S-100C CORDLESS HVLP SPRAY GUN MODEL NO: S-100C SAFETY & OPERATING INSTRUCTION MANUAL...
  • Page 2: Power Tool Safety

    S-100C Cordless HVLP Spray Gun. POWER TOOL SAFETY WARNING: Before using your S-100C, it is critical that you read and understand these safety rules. Failure to follow these rules could result in damage to the tool, serious injury to you or even lead to death.
  • Page 3: Work Area

    Everyday glasses have only impact resistant lenses. They ARE NOT safety glasses. • WARNING: Glasses or goggles not in compliance with ANSI Z87.1 could cause serious injury when they break. WORK AREA Keep your work area clean and well-lit. Cluttered benches and dark areas invite accidents. •...
  • Page 4: Specific Safety Rules

    SPECIFIC SAFETY RULES • 1. Keep your workplace clean, never use the tool in hazardous areas that contain flamma- ble liquids, gasses or dust. 2. Only use paints, solvents or other materials with a flash point of 73 °F(22C) or higher. •...
  • Page 5: Removing & Installing Battery

    These are normal conditions and do not indicate a problem. After about four cycles of charging and discharging through use, the battery will accept a full charge. WARNING: Remove the battery before carrying out any work on the S-100C. Before switching on the power tool. Unpack the spray gun and check that there are no missing or damaged parts.
  • Page 6: Know Your Spray Gun

    KNOW YOUR SPRAY GUN Fig. 01 Exploded View...
  • Page 7 Function: Suitable for disinfecting, sanitizing, deodorizing, cleaning, applying dressings, and other automotive functions. HOW TO USE: Before using the S-100C, material preparation is the first stage. Please refer to the thinning chart and picture. Fig.02 Material Run out Time (Sec)
  • Page 8: Suction Tube

    Unscrew the liquid container from the spray gun. Fig.03 Adjust the suction tube. a. If spraying in an upward direction, the angled end of the suction tube should be pointing toward the rear of the gun. Fig.04 SUCTION TUBE b. If spray in a downward direction, the angled end of the suction tube should be pointing towards the front of the gun.
  • Page 9 Pour material into container, make sure not to exceed 800ml Fig.06 Remove the motor a. Hold the gun with your hand and press the latch in the direction of the arrow. b. At the same time hold the motor handle with your hand and rotate it counterclockwise 90°. c.
  • Page 10 Adjust the needle adjusting screw to meet your requirement. a. Adjust the screw to left to decrease liquid volume, decreasing coverage b. Adjust the screw to right to increase liquid volume, increasing coverage Fig. 09 ADJUSTING SCREW Spray length adjustment: Turn this knob to adjust the round shape from vertical to hori- zontal.Adjust the required length according to the spraying environment, reduce waste and save material.
  • Page 11: Vertical Position

    Adjusting spray patterns a. The gun spray patterns can be changed from a horizontal oval fan pattern to a round b. detailed pattern to a vertical fan pattern by adjusting the nozzle. Fig. 12 VERTICAL POSITION Fig. 13 HORIZONTAL POSITION Open the power switch, pull trigger, the liquid will spray from the nozzle.
  • Page 12 • Do not flex wrist while spraying. Fig. 15 INCORRECT REPLACE NOZZLE AND NEEDLE: When disassembling the nozzle, please pull the trigger first, then press and remove the nozzle. a. As shown in the figure, rotate to remove the needle b.
  • Page 13: Troubleshooting

    TROUBLESHOOTING Cause(s) Solution(s) Problem Little or no material flow 1. nozzle clogged 1. clean 2. suction tube clogged 2. clean 3. material volume setting turn too far to 3. turn to the left the right 4. suction tube loose 4. insert 5.
  • Page 14: Disposal Information

    WARNING: Remove the battery before carrying out any work on the S-100C. Cleaning • Clean the S-100C and grille in front of the vent slots regularly. Frequency of cleaning is depen- dent on the material and duration of use. •...
  • Page 15: Warranty

    WARRANTY 1 year internal parts only, not wearable parts. Warranty starts from the date of sale to the end user. End user or distributor sends the unit back to Tornador at the end user/distributor’s expense. Include ® the bill of sale to help with determining the 1 year as well as contact name, phone number and return address.
  • Page 16 Thank you for your support! The S-100C uses High-Volume, Low-Pressure (HVLP) technology to evenly disperse the flow of any liquid with less risk of overspray. The S-100C is de- signed for the professional detailer and home enthusiast looking to disinfect, sanitize, deodorize, and/or clean any vehicle, without having to worry about cords.
