Quoizel QR3328 Installation Manual

SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, install or operate the product.
CAUTION
• For your safety, read instructions completely before beginning installation.
• Quoizel recommends 2 people for each step during assembly.
TOOLS REQUIRED
CARE AND MAINTENANCE
• Wipe clean using soft, dry cloth or static duster. Always avoid using harsh chemicals and abrasives to clean fixture as they may damage
the finish.
If you need further assistance call Quoizel Customer Care at 1-800-645-3184 (9:00am - 5:00pm EST), or visit us on-line at
www.quoizel.com.
PACKAGE CONTENTS
Mirror
A
x 1
INSTALLATION
1
Identify Screws Locations for mounting
the Mirror Hangers By Using Template
The template included with package is provided to assist you in
placing the mirror in the location you desire. The template is a full
size drawing of your mirror and includes hanger mounting
locations that your mirror maybe hung.
Place the template on the wall in the location you have selected
for your mirror. Once you have the template in the location you
desire and making sure it is level you may tape or pin the template
to the wall. Now you may mark the holes for the mounting
hardware as indicated on your template. You may mark the
mounting hardware location by either using a pin and pushing it
through the template leaving a small hole on the wall. Or you may
use a pencil and place a mark on the wall through a small hole you
cut into the template at the correct mounting location.
Remove the template from the wall and install the Mirror Hangers.
INSTALLATION GUIDE FOR
QR3328, QR5135 and QR5136
Metal Part
B
x 2
0.25" Dia.
- 1 of 2 -
MOUNTING HARDWARE
Mirror Hanger
AA
x 2
Screw
CC
x 4
25.25"
2" Dia.
11.75"
TEMPLATE
Mark Self-tapping Screws Locations
On The Wall Through (4) 0.25" Dia. Holes
Released Date: 2021-09-28
Wall Anchor
BB
x 4
Allen Wrench
DD
x 1
22"
TOP
0.25"
28"
11.75"
0.75"
