TVI-AC344-OD
TVI-AC344-OD-2.8
TVI-AC344-OD-BLK
TVI-AC344-OD-2.8-BLK
User Manual
User Manual
This manual includes instructions for using and
managing the product. Pictures, charts, images and all
other information hereinafter are for description and
explanation purposes only. The information
contained in the manual is subject to change, without
notice. Please find the latest version on the company
website. Please use this user manual under the
guidance of professionals.
WARNING: THIS PRODUCT CAN EXPOSE YOU
TO POLYBROMINATED BIPHENYLS, WHICH IS
KNOWN TO THE STATE OF CALIFORNIA TO
CAUSE CANCER AND BIRTH DEFECTS OR
OTHER REPRODUCTIVE HARM. FOR MORE
INFORMATION GO TO
WWW.PROP65WARNINGA.CA.GOV
Legal Disclaimer
SURVEILLANCE LAWS VARY BY JURISDICTION. PLEASE
CHECK ALL RELEVANT LAWS IN YOUR JURISDICTION
BEFORE USING THIS PRODUCT IN ORDER TO ENSURE
THAT YOUR USE CONFORMS TO THE APPLICABLE
LAWS. OUR COMPANY SHALL NOT BE LIABLE IN THE
EVENT THAT THIS PRODUCT IS USED FOR
ILLEGITIMATE PURPOSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS
MANUAL AND THE
APPLICABLE LAW, THE LATER PREVAILS.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TVI-AC344-OD and is the answer not in the manual?

Questions and answers

Related Manuals for Nace TVI-AC344-OD

Summary of Contents for Nace TVI-AC344-OD

  • Page 1 TVI-AC344-OD TVI-AC344-OD-2.8 TVI-AC344-OD-BLK TVI-AC344-OD-2.8-BLK User Manual User Manual This manual includes instructions for using and managing the product. Pictures, charts, images and all other information hereinafter are for description and explanation purposes only. The information contained in the manual is subject to change, without notice.

  • Page 2: Regulatory Information

    Regulatory Information FCC Information Please take attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules.
  • Page 3 Safety Instruction These instructions are intended to ensure that user can use the product correctly to avoid danger or property loss. The precaution measure is divided into “Warnings” and “Cautions”. Warnings: Serious injury or death may occur if any of the warnings are neglected.
  • Page 4 Do not place the camera in extremely hot, cold (the  operating temperature should be -22°F to +140°C), dusty or damp locations, and do not expose it to high electromagnetic radiation. To avoid heat accumulation, good ventilation is  required in the operating environment. Keep the camera away from liquid while in use.

  • Page 5: Product Features

    1 Introduction 1.1 Product Features The camera is applicable for both indoor and outdoor conditions, and the application scenarios include road, warehouse, underground parking lot, bar, etc.. The main features are as follows: High performance CMOS sensor  Low illumination, 0.005 Lux @ (F2.0, AGC ON), 0 ...
  • Page 6 Drill Template Hole A: for cables routed through the ceiling screw hole 1: for Mounting Base Drill Template Figure 2-1 Note: Drill the cable hole if planning to route the cable through the ceiling/wall. Route the cables and fix the mounting base on the ceiling with three screws.
  • Page 7 Reinstall the dome to the camera. Reinstall the Dome Figure 2-4 2.2 Mounting with Wall Mounting Bracket Steps: Mark the screw holes on the desired mounting location. Hole Hole Hole Hole Mark Screw Holes Figure 2-5 Drill 4 screw holes per the template. Remove the dome from the camera.
  • Page 8 Cable Hole Wall Mounting Bracket Fix the Camera to the Wall Mounting Bracket Figure 2-6 Align the wall mounting bracket to the screw holes and fix it to the wall with the supplied screws. Fix the Wall Mounting Bracket to the Wall Figure 2-7 6.

  • Page 9: Menu Description

    3 Menu Description Purpose: button in PTZ Control, Call the menu by clicking the or call preset No.95. Steps: 1. Connect the camera with the TVI DVR, and the monitor, as shown in figure 3-1. TVI DVR Camera Monitor Figure 3-1 Connection 2.
  • Page 10 3.1 FORMAT PAL (Phase Alternating Lines) PAL is a color encoding system for analog television used in broadcast television systems in most countries. NTSC: (National Television System Committee) NTSC is the analog television system that is used in most of North America, parts of South America, Myanmar, South Korea, etc.
  • Page 11 SENSE UP Sense up increases the exposure on a signal frame, which makes a camera more sensitive to light so it can produce images even in low lux conditions. You can set the SENS-UP as OFF or AUTO as desired for different lighting conditions.
  • Page 12 SMART IR  The Smart IR function is used to adjust the light to its most suitable intensity, and prevent the image from over exposure. The SMART IR value can be adjusted from 1 to 8. The higher the value, the stronger the effects will be.

  • Page 13: Save And Exit

    PRIVACY Figure 3-7 Select a PRIVACY area. Set the DISPLAY status to ON. Click up/down/left/down buttons to define the position and size of the area. MOTION In user-defined motion detection areas, moving objects can be detected and recording will be triggered.
