ST-IP4FD
QUICK START GUIDE
www.nacebrands.com
www.securitytronix.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SECURITY TRONICS ST-IP4FD and is the answer not in the manual?

Questions and answers

Related Manuals for Nace SECURITY TRONICS ST-IP4FD

Summary of Contents for Nace SECURITY TRONICS ST-IP4FD

  • Page 1 ST-IP4FD QUICK START GUIDE www.nacebrands.com www.securitytronix.com...
  • Page 2 ST-IP4FD·Quick Start Guide About this Manual This Manual includes instructions for using and managing the product. Pictures, charts, images and all other information hereinafter are for description and explanation only. The information contained in the Manual is subject to change, without notice, due to firmware updates or other reasons.
  • Page 3 ST-IP4FD·Quick Start Guide FCC Information Please pay attention that changes or modification not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. FCC compliance: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC Rules.
  • Page 4 ST-IP4FD·Quick Start Guide This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference. 2. This device must accept any interference received, including interference that may cause undesired operation. EU Conformity Statement This product and - if applicable - the supplied accessories too are marked with "CE"...
  • Page 5 ST-IP4FD·Quick Start Guide Industry Canada ICES-003 Compliance This device meets the CAN ICES-3 (B)/NMB-3(B) standards requirements. This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 6 ST-IP4FD·Quick Start Guide type d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas l'intensité nécessaire à l'établissement d'une communication satisfaisante. This equipment should be installed and operated with a minimum distance 20cm between the radiator and your body. Cet équipement doit être installé...
  • Page 7 ST-IP4FD·Quick Start Guide —Increase the separation between the equipment and receiver. —Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. —Consult the dealer or an experienced radio/TV technician for help. FCC Conditions This device complies with part 15 of the FCC Rules.
  • Page 8 ST-IP4FD·Quick Start Guide See the product documentation for specific battery information. The battery is marked with this symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or mercury (Hg). For proper recycling, return the battery to your supplier or to a designated collection point.
  • Page 9 ST-IP4FD·Quick Start Guide ● While using this product, you must be in strict compliance with the electrical safety regulations of the nation and region. Please refer to technical specifications for detailed information. ● Input voltage should meet both the SELV (Safety Extra Low Voltage) and the Limited Power Source with 12 VDC according to the IEC60950-1 standard.
  • Page 10 ST-IP4FD·Quick Start Guide ● Do not aim the camera at the sun or extra bright places. Blooming or smearing may occur otherwise (which is not a malfunction), and affect the endurance of sensor at the same time. ● The sensor may be burned out by a laser beam, so when any laser equipment is in using, make sure that the surface of sensor will not be exposed to the laser beam.
  • Page 11 ST-IP4FD·Quick Start Guide disassemble the camera yourself. (We shall not assume any responsibility for problems caused by unauthorized repair or maintenance.) 05040510701118...

  • Page 12: Table Of Contents

    ST-IP4FD·Quick Start Guide Table of Contents 1 Appearance Description ............... 12 Type I ................12 Type II ................13 Type III ................15 Type IV ................17 2 Installation ..................19 Memory Card Installation ..........20 Ceiling Mounting ............21 Mounting with Brackets ..........

  • Page 13: Appearance Description

    ST-IP4FD·Quick Start Guide 1 Appearance Description There are three types of camera appearance for this series of camera according to the different models. Type I Figure 1-1 Overview of Type I Camera Table 1-1 Description of Type I Camera Description Description Mounting Base Horizontal Stand...
  • Page 14 ST-IP4FD·Quick Start Guide Description Description IR LED Lens Black Liner Safety Rope Note: Press RESET about 10s when the camera is powering on or rebooting to restore the default settings, including the user name, password, IP address, port No., etc. Type II Figure 1-2 Overview Of Type II Camera...
  • Page 15 ST-IP4FD·Quick Start Guide Table 1-2 Description of Type II Camera Description Description Mounting Base Horizontal Stand Vertical Stand Bubble Network Interface Power Interface IR LED Lens Black Liner Safety Rope Audio Interface (Only Alarm Interface (Only supported by the camera supported by the camera with “-A”...

  • Page 16: Type Iii

    ST-IP4FD·Quick Start Guide Type III DC12VIN Figure 1-3 Overview Of Type III Camera...
  • Page 17 ST-IP4FD·Quick Start Guide Table 1-3 Description of Type III Camera Description Power supply interface (12 VDC) Audio input and output interface Alarm input and output interface RJ45 self-adaptive network interface (PoE) Mounting base Black liner Lens Bubble Memory card slot Reset button Note: ●...

  • Page 18: Type Iv

    ST-IP4FD·Quick Start Guide Type IV Figure 1-4 Overview Of Type IV Camera...
  • Page 19 ST-IP4FD·Quick Start Guide Table 1-4 Description of Type IV Camera Description RJ45 self-adaptive network interface (supports PoE) HDMI Mounting base Black liner Lens Bubble Memory card slot Reset button Note: Press RESET about 10s when the camera is powering on or rebooting to restore the default settings, including the user name, password, IP address, port No., etc.

  • Page 20: Installation

    ST-IP4FD·Quick Start Guide 2 Installation Before you start: ● Make sure the device in the package is in good condition and all the assembly parts are included. ● The standard power supply is 12 VDC or PoE (802.3 af), please make sure your power supply matches with your camera.

  • Page 21: Memory Card Installation

    ST-IP4FD·Quick Start Guide Memory Card Installation For camera models that support memory card as local storage, you can follow the steps to mount and unmount the memory card. This camera series shares a similar structure, type III camera is used for demonstration.

  • Page 22: Ceiling Mounting

    ST-IP4FD·Quick Start Guide Find the memory card slot to insert the memory card. Figure 2-2 Insert Memory Card (Optional) To unmount the memory card, push to get it ejected. Ceiling Mounting This camera series shares a similar structure, type III camera is used for demonstration.
  • Page 23 ST-IP4FD·Quick Start Guide Drill Template Hole A: for cables routed through the ceiling Screw hole 1: for Mounting Base Figure 2-3 Drill Template Notes: ● If you choose to route cable through the ceiling, cut a cable hole according to Hole A on drill template. ●...
  • Page 24 ST-IP4FD·Quick Start Guide Route the cables and fix the mounting base on the ceiling with three screws. Figure 2-5 Fix the Mounting Base Adjust surveillance angle. See the figure of each camera type for detailed angle adjustment range Loosen one tilting adjust adjusting screw to adjust the tilting position.
  • Page 25 ST-IP4FD·Quick Start Guide 0°~360° Tilting Adjust Screw 0°~65° Figure 2-6 Angle Adjustment of Type I Camera Tilt: Pan: 0° to 75° 0° to 355° Tilting Adjust Screw Rotate: 0° to 355° Figure 2-7 Angle Adjustment of Type II Camera...
  • Page 26 ST-IP4FD·Quick Start Guide Figure 2-8 Angle Adjustment of Type III Camera Install the bubble back to the camera. Figure 2-9 Install Bubble...

  • Page 27: Mounting With Brackets

    ST-IP4FD·Quick Start Guide Mounting with Brackets This camera series supports mounting with wall mounting bracket, pendant mounting bracket, and incline mounting bracket. We take Type III camera as the demonstration example. 2.3.1 Wall Mounting The wall mounting bracket is not included in the package. You need to prepare one, if you adopt this mounting type.
  • Page 28 ST-IP4FD·Quick Start Guide 2. Drill 4 screw holes for expansion screws. 3. Unscrew the bubble of the camera. 4. (Optional) Insert the memory card to the camera, if your camera supports memory card installation. Refer to Section 2.1. 5. Route the cables and fix the camera to the cap of the wall mounting bracket with three supplied self-tapping screws.
  • Page 29 ST-IP4FD·Quick Start Guide Figure 2-12 Fix the Wall Mounting Bracket to Wall 7. Adjust surveillance angle of camera. Refer to Step 4 in Section 2.2. 8. Install the bubble back to the camera. Figure 2-13 Install the Bubble...
  • Page 30 ST-IP4FD·Quick Start Guide 2.3.2 Wall Mounting with Junction Box The wall mounting bracket with junction box is not included in the package. You need to prepare one, if you adopt this mounting type. Steps: 1. Mark the screw holes on desired mounting place. 2.
  • Page 31 ST-IP4FD·Quick Start Guide Cover Figure 2-15 Unscrew the Cover 4. Route and connect the cables. Source cables of network, power, etc., go in from the side outlet of the junction box. Camera cables go in from the cap and the bracket.
  • Page 32 ST-IP4FD·Quick Start Guide Camera Cable Source Cable Figure 2-16 Cable Routing 6. Unscrew the bubble of the camera. 7. (Optional) Insert the memory card to the camera, if your camera supports memory card installation. Refer to Section 2.1. 8. Fix the camera to the cap of the wall mounting bracket with three supplied self-tapping screws.
  • Page 33 ST-IP4FD·Quick Start Guide Figure 2-17 Fix the Camera to Wall Mounting Bracket 9. Adjust surveillance angle of camera. Refer to Step 4 in Section 2.2. 10. Install the bubble back to the camera.
  • Page 34 ST-IP4FD·Quick Start Guide Figure 2-18 Install the Bubble 2.3.3 Pendant Mounting The pendant mounting bracket is not included in the package. You need to prepare one in advance, if you adopt this mounting type. Steps: 1. Mark the screw holes on desired mounting place. 2.
  • Page 35 ST-IP4FD·Quick Start Guide Cables Figure 2-19 Fix Pendant Mount 4. (Optional) Insert the memory card to the camera, if your camera supports memory card installation. Refer to Section 2.1. 5. Fix the camera to the cap of the pendant mounting bracket with 3 supplied self-tapping screws.
  • Page 36 ST-IP4FD·Quick Start Guide 6. Screw the cap to the pendant mounting bracket. Figure 2-21 Install the Cap 7. Adjust surveillance angle of camera. Refer to Step 4 in Section 2.2. 8. Install the bubble back to the camera. 2.3.4 Incline Mounting The incline mounting bracket is not included in the package.
  • Page 37 ST-IP4FD·Quick Start Guide Ceiling Mounting Screw Screw Hole Hole Cable Hole Figure 2-22 Drill Template 2. Drill two screw holes for expansion screws, and a cable hole according to the template. 3. Fix the incline mounting bracket to ceiling. Figure 2-23 Fix Incline Mounting Bracket to Wall...
  • Page 38 ST-IP4FD·Quick Start Guide 4. Unscrew the bubble of the camera. 5. (Optional) Insert the memory card to the camera, if your camera supports memory card installation. Refer to Section 2.1. 6. Route the cables and fix the camera to the incline mounting bracket with three supplied self-tapping screws.

  • Page 39: Network Cable Water-Proof Jacket Installation (Optional)38

    ST-IP4FD·Quick Start Guide Figure 2-25 Install the Bubble Network Cable Water-proof Jacket Installation (Optional) Purpose: If the camera is installed outdoor, you can adapt the water-proof accessory for the network cable after the camera is secured on the installation surface. ①...
  • Page 40 ST-IP4FD·Quick Start Guide Table 2-1 Components Components Camera’s Network Interface Socket O-Type Gasket Network Plug Waterproof Endcap Waterproof Rubber Gasket Lock Nut Network Cable from Router/Switch Steps: Feed the plugless network cable ⑦ through the lock nut ⑥, waterproof rubber gasket ⑤ (rubber gasket inset ridge must face waterproof endcap), and the water-proof endcap ④...
  • Page 41 ST-IP4FD·Quick Start Guide Insert the water-proof rubber gasket ⑤ into the waterproof endcap ④, and secure lock nut ⑥ with the water-proof endcap ④. Align the snap on the water-proof endcap ④ with the notch on the camera’s network interface socket ①, and then secure the water-proof endcap ④...

  • Page 42: Setting The Network Camera Over The Lan

    ST-IP4FD·Quick Start Guide 3 Setting the Network Camera over the Note: You shall acknowledge that the use of the product with Internet access might be under network security risks. For avoidance of any network attacks and information leakage, please strengthen your own protection.

  • Page 43: Activating The Camera

    ST-IP4FD·Quick Start Guide Activating the Camera You are required to activate the camera first by setting a strong password for it before you can use the camera. Activation via Web Browser, Activation via SADP, and Activation via Client Software are all supported. We will take activation via SADP software and Activation via Web Browser as examples to introduce the camera activation.
  • Page 44 ST-IP4FD·Quick Start Guide Figure 3-3 Activation Interface(Web) 3. Create a password and input the password into the password field. STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 45 ST-IP4FD·Quick Start Guide Get the SADP software from the supplied disk or the official website, and install the SADP according to the prompts. Follow the steps to activate the camera, please refer to the User Manual of Network Camera for other two activation methods. Steps: 1.

  • Page 46: Modifying The Ip Address

    ST-IP4FD·Quick Start Guide STRONG PASSWORD RECOMMENDED– We highly recommend you create a strong password of your own choosing (using a minimum of 8 characters, including upper case letters, lower case letters, numbers, and special characters) in order to increase the security of your product.
  • Page 47 ST-IP4FD·Quick Start Guide Steps: 1. Run the SADP software. 2. Select an activate device. 3. Change the device IP address to the same subnet with your computer by either modifying the IP address manually or checking the checkbox of Enable DHCP. Figure 3-5 Modify the IP Address...
  • Page 48 ST-IP4FD·Quick Start Guide Note: You can enable the STGO2 service for the device during activation. Refer to Chapter 5.1 for detailed information. 4. Input the admin password and click Modify to activate your IP address modification. The batch IP address modification is supported by the SADP. Please refer to the User Manual of SADP for details.

  • Page 49: Accessing Via Web Browser

    ST-IP4FD·Quick Start Guide 4 Accessing via Web Browser System Requirement: Operating System: Microsoft Windows XP SP1 and above version CPU: 2.0 GHz or higher RAM: 1G or higher Display: 1024×768 resolution or higher Web Browser: Internet Explorer 8.0 and above version, Apple Safari 5.0.2 and above version, Mozilla Firefox 5.0 and above version and Google Chrome 18 and above version Steps:...
  • Page 50 ST-IP4FD·Quick Start Guide 4. Click Login. Figure 4-1 Login Interface 5. Install the plug-in before viewing the live video and managing the camera. Please follow the installation prompts to install the plug-in. Note: You may have to close the web browser to finish the installation of the plug-in.

  • Page 51: Operating Via Guarding Vision App

    ST-IP4FD·Quick Start Guide 5 Operating via STGO2 app Purpose: STGO2 is an application for mobile devices. With the App, you can view live image of the camera, receive alarm notification and so on. Note: STGO2 service is not supported by certain camera models. Enable STGO2 Service on Camera Purpose: Guarding Vision service should be enabled on your camera before...
  • Page 52 ST-IP4FD·Quick Start Guide Service” “Privacy Policy” Figure 5-1 Verification Code Setting (SADP) Note: The verification code is required when you add the camera to STGO2 app. 3. Click and read "Terms of Service" and "Privacy Policy". 4. Confirm the settings. 5.1.2 Enable STGO2 via Web Browser Before you start: You need to activate the camera before enabling the service.

  • Page 53: Guarding Vision Setup

    ST-IP4FD·Quick Start Guide Steps: 1. Access the camera through web browser. Refer to Chapter 4. 2. Enter platform access configuration interface: Configuration > Network > Advanced Settings > Platform Access Guarding Vision dev.guardingvision.com Figure 5-2 Platform Access Configuration (Web) 3. Select Platform Access Mode as Guarding Vision. 4.

  • Page 54: Adding Camera To Guarding Vision

    ST-IP4FD·Quick Start Guide 5.2 STGO2 Setup Steps: 1. Download and install the STGO2 app by searching “STGO2” in App Store or Google Play 2. Launch the app and register for a STGO2 user account. 3. Log in STGO2 app after registration. 5.3 Adding Camera to STGO2 Before you start: You need to enable the STGO2 service on camera before adding...
  • Page 55 ST-IP4FD·Quick Start Guide You can find the QR code on the camera or on the cover of the Quick Start Guide of the camera in the package. Figure 5-4 Scan QR Code Note: If the QR code is missing or too blur to be recognized, you can also add the camera by tapping the icon and inputting the camera's serial number.

  • Page 56: Initializing The Memory Card

    ST-IP4FD·Quick Start Guide Initializing the Memory Card Steps: Check the memory card status by tapping on the Storage Status in the Device Settings interface. If the memory card status displays as Uninitialized, tap to initialize it. The status will then change to Normal. You can then start recording any event triggered video in the camera such as motion detection.
  • Page 57 SECURITYTRONIX 2-Year Limited Fixed Camera Warranty Securitytronix. (the "Company") warrants to the Original Purchaser that the Fixed Camera is free from defects in workmanship or material under normal use. This warranty starts on the date of shipment of the hardware to the Original Purchaser. During the warranty period, the Company agrees to repair or replace, at its sole option, without charge to Original Purchaser, any defective component in the Fixed Camera.
