Richman RM200 Manual

2 burners gas grill
Hide thumbs

Advertisement

Quick Links

Download this manual
RM200
2 burners gas grill
1. Out door use only
2. This grill in not intended to be installed in or on
recreational vehicles and/or boats.
Dear customer,
Congratulations on your purchase of the RICHMAN 200 grill. This product has been developed on the
basis of the latest technical knowledge and produced using reliable and high quality components.
Please take a few minutes before starting operation of the gas grill unit and read the following operating
instructions. The instruction shall be marked directions to the installer to leave them with the consumer
and to the consumer to retain them for future reference.
Example only: SERIAL#______MFG. DATE________ PURCHASE DATE:________
Question, problems, missing parts? Before returning to your retailer, call our customer
service department at 1-866-898-8187, M-F 9:00am-5:00pm.
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the RM200 and is the answer not in the manual?

Questions and answers

Related Manuals for Richman RM200

Summary of Contents for Richman RM200

  • Page 1 Dear customer, Congratulations on your purchase of the RICHMAN 200 grill. This product has been developed on the basis of the latest technical knowledge and produced using reliable and high quality components. Please take a few minutes before starting operation of the gas grill unit and read the following operating instructions.
  • Page 2 RM200 2 burners gas grill TABLE OF CONTENTS Safety Information………………………………………………………………………………………………………………………….…… Package Contents List…………………………………………………………………………………………………………………….…… Assembly Instructions…………………………………………………………………………………………………………………………. Regulator & Hose Instructions, Gas Tank Instructions……………………………………………………..…….… Operating instructions………………………………………………………………………………………………………………………… Cooking Tips………………………………………………………………………………………………………………………………..……… Care and maintenance………………………………………………………………………………………………………………..…… Troubleshooting…………………………………………………………………………………………………………………….…………… Warranty……………………………………………………………………………………………………………………………………..….…. Danger If you smell gas 1. Do not store or use gasoline or 1.
  • Page 3 RM200 2 burners gas grill Safety Information Warning Failure to comply with these instructions could result in a fire or explosion that could cause serious bodily injury, death or property damage. Spiders and small insects can spin webs and nest in the grill burner tubes during transit and warehousing which can lead to a gas flow obstruction resulting in a fire in and around the burner tubes.
  • Page 4 If the hose appears damaged, do not use the gas grill. Call 1-866-898-8187 for a Richman replacement gas hose assembly Warning The gas hose should be inspected after each use-look for any cuts, cracks, excessive wear or other damage.
  • Page 5 RM200 2 burners gas grill PRE-ASSEMBLY Read and perform the following pre-assembly instructions: □ Tools Required for Assembly include: ․protective work gloves ․protective eyewear ․Phillips Head Screwdriver (included in hardware pack in Parts Box) □ You will need assistance from another person to handle the grill head and other large, heavy parts.
  • Page 6 RM200 2 burners gas grill Package and Hardware Contents List DESCRIPTION DESCRIPTION Firebox Assembly Case Body Right Side Panel Warming Rack Door Cooking Grids Right Vent Condiment Tray Flame Tamers Door Handle Side Table A Bottom Panel Side Table Swivel Locking Caster...
  • Page 7 RM200 2 burners gas grill DESCRIPTION DESCRIPTION Grease Tray Handle 1/4-in. x 10-mm Truss Head Screw with locking washer 1/4-in. x 10-mm Truss Head Screw Grease Tray 5 / 32 -in. x 10-mm Truss Head Screw 5 / 32 -in. Nut Left Vent 1/4-in.
  • Page 8 RM200 2 burners gas grill Parts Diagram...
  • Page 9 RM200 2 burners gas grill Assembly Instructions Step 1. Install Casters and Tank Bolt □ Place the Bottom Panel (14) upside down and attach the 4 Casters to the Caster Seats. Use care to install each Caster into the correct position.
  • Page 10 RM200 2 burners gas grill Step 3. Install Door Handle □Attach the Door Handle(13) to the Door(11) using 2 Nuts. 11(1X) 13(1X) D(2X) Step 4. Install Door □ Attach the Door (11) to the Case Body Right Side Panel (10) as shown picture...
  • Page 11 RM200 2 burners gas grill Step 5. Install Firebox Assembly to Case Body Assembly □Place the Firebox Assembly on the Case Body Assembly. We recommend using 2 people to lift the Firebox Assembly (1) 1(1X) E(4X) Step 6. Install Vents and Side Table Holder □...
  • Page 12 RM200 2 burners gas grill Step 7. Install Side Table □ Attach the Side Table(7) on the Side Table Holder A(6) and B(8) using 8 Stage Screws(H) H(8X) Step 8. Left up Side Table □ Against the Side Table (7) to the Firebox Assembly (1) and hang it up by Stage Screws.
  • Page 13 RM200 2 burners gas grill Step 9. Install Grease Tray □ Attach the Grease Tray Handle (17) to the Grease Tray (18) using 2 Truss Head Screws. □ Slide the Grease Tray (18) along two sides of Firebox Assembly from the back of the Firebox Assembly.
  • Page 14 RM200 2 burners gas grill Step 11. Place Flame Tamers, Cooking Grids, and Warming Rack into the Firebox Assembly □ Place the Flame Tamers (5) into the Firebox Assembly (1). □ Place the Cooking Grids (3) into the Firebox Assembly (1).
  • Page 15 RM200 2 burners gas grill Step 13. Electronic Ignition Battery Installation □ Unscrew the electronic igniter cap. Place the “AA” Battery into the igniter with the positive (+) end up. Screw the electronic igniter cap back into place. Step 14. Place LP Cylinder into the Cabinet □Place the LP cylinder down into the tank support hole in the bottom of the cabinet.
  • Page 16 RM200 2 burners gas grill Step 15. Congratulations – Assembly is now Complete □Remove any additional labels or packing material from the grill except the CSA label. Be sure to clean all foam packing material out of all areas. □Please proceed to and read the remaining sections of the Operator’s Manual prior to hooking up your LP cylinder or operating your grill.
  • Page 17 LP gas tank. Only use the regulator and hose assembly supplied with your gas grill. Replacement regulators and hose assemblies must be those specified by Richman. Have your LP Gas dealer check the release valve after every filling to ensure it remains free of defects.
  • Page 18 RM200 2 burners gas grill Warning A. Do not store a spare LP gas tank under or near this appliance. B. Never fill the tank beyond 80 percent full; C. If the information in “(a)”and “(b)” is not followed exactly, a fire causing death or serious injury may occur.
  • Page 19 RM200 2 burners gas grill Test all connections for gas leaks before first use, at the beginning of each new season, or when gas cylinder was changed. Make sure procedure is carried our in well ventilated area and never in a presence of flame, sparks or heat source.
  • Page 20 RM200 2 burners gas grill 5. Center the nipple of the regulator into the cylinder valve. 6. Turn the black nut clockwise until it stops. Hand Tighten Only. Do Not Use A Wrench. CAUTION: When the appliance is not in use the gas must be turned off at the tank.
  • Page 21 RM200 2 burners gas grill of dust cap on the cylinder valve outlet that is provided with the cylinder of propane valve. Other types of caps or plugs may result in leakage. 2. Always transport your cylinder in an upright position.
  • Page 22 RM200 2 burners gas grill HIGH HIGH HIGH Open the valve of the gas cylinder. Keep your face and body as far away from the grill as possible while igniting. Push and turn the valve knob to the IGNITE/HI position, press the ignition button down, until you hear a click.
  • Page 23 RM200 2 burners gas grill Appearance of the flame The burner flame should appear blue and stable as shown pictures. There should be no yellow sparks, loud noise nor should it be raised up from the nozzle. A yellow flame mans that there is not enough oxygen supply. Loud noises and a flame raised up from the nozzle means that there is too much oxygen.
  • Page 24 RM200 2 burners gas grill from this process contributes to the taste of the food. Set the temperature knobs to the desired positions in order to reach your desired results. A more consistent result can be reached with the cover closed. In this case however, the temperature should be set to LO.
  • Page 25 RM200 2 burners gas grill when the lid is opened. Visually inspect the inside of the grill lid before each grill use. Remove any grease and wash with a mild soap and warm water solution. Annual Cleaning of the Grill Interior Burning-off excess food after every cookout will keep it ready for instant use.
  • Page 26 RM200 2 burners gas grill bromine), lawn fertilizer, ice melting salts, sea or salt water, urine, bird droppings, and tree sap. Failure to comply with these instructions may result in a hazardous situation which, if not avoided, may result in injury.
  • Page 27 RM200 2 burners gas grill Troubleshooting Problem Solution The grill does not ignite Ensure that the gas valves are open immediately. Check if sparks are produced when igniting the grill Push the temperature knob for 5 seconds before you turn it to ignite the grill.
  • Page 28 RM200 2 burners gas grill Upon consumer supplying proof of purchase as provided herein, Manufacturer will repair of replace the parts which are proven defective during the applicable warranty period. Parts required to complete such repair or replacement shall be free of charge to you except for shipping costs, as ling as the purchaser is within the warranty period from the original date of purchase.
  • Page 29 MAXUM Holding Co., LTD(USA) 13931 Central Avenue Suite 200 Chino, CA. 91710 All consumer returns, parts orders, general questions, and troubleshooting Assistance can be acquired by calling1-866-898-8187 Customer Service Email Address: customerservice@maxumholding.com Website Warranty Registration: www.maxumholding.com (RICHMAN Grills Tab)
