Richman RM310 Operating Instructions Manual

3+1 burners gas grill
Hide thumbs

Advertisement

Quick Links

Download this manual
RM310
3+1 burners gas grill
1. Out door use only
2. This grill in not intended to be installed in or on
recreational vehicles and/or boats.
Dear customer,
Congratulations on your purchase of the RICHMAN 200 grill. This product has been developed on the
basis of the latest technical knowledge and produced using reliable and high quality components.
Please take a few minutes before starting operation of the gas grill unit and read the following operating
instructions. The instruction shall be marked directions to the installer to leave them with the consumer
and to the consumer to retain them for future reference.
Example only: SERIAL#______MFG. DATE________ PURCHASE DATE:________
Question, problems, missing parts? Before returning to your retailer, call our customer
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the RM310 and is the answer not in the manual?

Questions and answers

Related Manuals for Richman RM310

Summary of Contents for Richman RM310

  • Page 1 Dear customer, Congratulations on your purchase of the RICHMAN 200 grill. This product has been developed on the basis of the latest technical knowledge and produced using reliable and high quality components. Please take a few minutes before starting operation of the gas grill unit and read the following operating instructions.
  • Page 2 RM310 3+1 burners gas grill service department at 1-866-898-8187, M-F 9:00am-5:00pm. TABLE OF CONTENTS Safety Information………………………………………………………………………………………………………………………….…… Package Contents List…………………………………………………………………………………………………………………….…… Assembly Instructions…………………………………………………………………………………………………………………………. Regulator & Hose Instructions, Gas Tank Instructions………………………………………………………….……….… Operating instructions………………………………………………………………………………………………………………………… Cooking Tips………………………………………………………………………………………………………………………………..……… Care and maintenance………………………………………………………………………………………………………………..…… Troubleshooting…………………………………………………………………………………………………………………….…………… Warranty……………………………………………………………………………………………………………………………………..….…. Danger If you smell gas 1.
  • Page 3 RM310 3+1 burners gas grill Safety Information Warning Failure to comply with these instructions could result in a fire or explosion that could cause serious bodily injury, death or property damage. Spiders and small insects can spin webs and nest in the grill burner tubes during transit and warehousing which can lead to a gas flow obstruction resulting in a fire in and around the burner tubes.
  • Page 4 If the hose appears damaged, do not use the gas grill. Call 1-866-898-8187 for a Richman replacement gas hose assembly Warning The gas hose should be inspected after each use-look for any cuts, cracks, excessive wear or other damage.
  • Page 5 RM310 3+1 burners gas grill PRE-ASSEMBLY Read and perform the following pre-assembly instructions: □ Tools Required for Assembly include: ․protective work gloves ․protective eyewear ․Phillips Head Screwdriver (included in hardware pack in Parts Box) □ You will need assistance from another person to handle the grill head and other large, heavy parts.
  • Page 6 RM310 3+1 burners gas grill Package and Hardware Contents List DESCRIPTION DESCRIPTION Bot t l e O pener El ect r oni c I gni t er El ect r oni c I gni t er Hol der Fr i ebox Assem bl y...
  • Page 7 RM310 3+1 burners gas grill DESCRIPTION DESCRIPTION M ot or Base Lef t Vent Lef t Door M anual I gni t er St i ck Assem bl y Lef t Dr aw er Gar ease Box Ti ssue Hanger Hol der...
  • Page 8 RM310 3+1 burners gas grill DESCRIPTION SUS430 1/ 4"- i n. X12- m m Tr uss Head Scr ew w i t h l ocki ng w asher Q 235 1/ 4" - i n. X10- m m Tr uss Head Scr ew Q 235 5/ 32"...
  • Page 9 RM310 3+1 burners gas grill Parts Diagram...
  • Page 10 RM310 3+1 burners gas grill Assembly Instructions Step 1. Install Casters and Tank Bolt □ Place the Bottom Panel (34) upside down and attach the 4 Casters to the Caster Seats. Use care to install each Caster into the correct position.
  • Page 11 RM310 3+1 burners gas grill Step 3. Install Firebox Assembly to Case Body Assembly and connection of Electric Igniter □ Place the Firebox Assembly（1）on the Case Body Assembly and lock it up by 6 Truss Head Screws（B）. We recommend using 2 people to lift the Firebox Assembly (1) □...
  • Page 12 RM310 3+1 burners gas grill Step 5. Install Front Cart Beam and Vents □Attach the Front Cart Beam(23) to the front of Firebox Assembly(1) using Truss Head Screws(B) □ Using Flat Silicon Washer(E) and Stage Screws(D) lock Left Vent(19) and Right Vent(5) to the...
  • Page 13 RM310 3+1 burners gas grill Step 7. Install Left Drawer Assembly to Firebox Assembly. □ Loosely screw 2 Truss Head Screws with Locking Washer (A) into two holes on the left side of the firebox as shown. Slide the Left Drawer Assembly (20) over the heads of those screws and tighten.
  • Page 14 RM310 3+1 burners gas grill Step 9. Install Right Side Burner Assembly to Firebox Assembly. □ Loosely screw 2 Truss Head screws into the bottom two holes in the right side of the firebox as shown. Slide the Side Burner Assembly over the heads of those screws and tighten.
  • Page 15 RM310 3+1 burners gas grill Step 11. Install Door Handle and Door-hinge □Attach the Door Handle (13)to the Doors (14 & 27) using 2 Nuts(G) and the Door-hinge(32) at the bottom of the Door(14 & 27) 13 (2X) 14 (1X)
  • Page 16 RM310 3+1 burners gas grill Step 13. Place Flame Tamers, Cooking Grids, Warming Rack, Side Burner Cooking Grid and Grease Box into the Firebox Assembly □ Place the Flame Tamers (4) into the Firebox Assembly (1). □ Place the Cooking Grids (3) into the Firebox Assembly (1).
  • Page 17 RM310 3+1 burners gas grill Step 15. Place LP Cylinder into the Cabinet □Place the LP cylinder down into the tank support hole in the bottom of the cabinet. Use the tank bolt to secure the tank in a fixed position with tank valve faces to the front.
  • Page 18 LP gas tank. Only use the regulator and hose assembly supplied with your gas grill. Replacement regulators and hose assemblies must be those specified by Richman. Have your LP Gas dealer check the release valve after every filling to ensure it remains free of defects.
  • Page 19 RM310 3+1 burners gas grill Use of alcohol or drugs may impair the ability to assemble and operate the appliance. Keep a fire extinguisher readily accessible. In the event of an oil or grease fire, do not attempt to extinguish with water. Use a type B extinguisher or smother with dirt, sand, or baking soda.
  • Page 20 RM310 3+1 burners gas grill NO overhead combustible construction Notes about LP Gas Tank Exchange Programs Many retailers that sell grills offer you the option of replacing your empty LP gas tank through an exchange service. Use only those reputable exchange companies that inspect, precision fill, test and certify their tanks.
  • Page 21 RM310 3+1 burners gas grill If the bubbles occur, immediately turn off the gas supply on the valve of the gas cylinder. Tighten all connections again and repeat the test. If gas bubbles still occur, do not use the grill and contact your retailer.
  • Page 22 RM310 3+1 burners gas grill Hand Tighten Only. Do Not Use A Wrench. CAUTION: When the appliance is not in use the gas must be turned off at the tank. Flow Limiting Valves on LP Gas Tanks Your LP gas tank is equipped with a flow limiting valve that will restrict the flow of gas due to a sudden change in pressure.
  • Page 23 RM310 3+1 burners gas grill counterclockwise Operating instructions Warning Before using the gas grill, make sure that you have read and understood all safety instruction and warning in this manual! Set up This gas grill is only intended for outdoor use. Place the grill in a well-ventilated location.
  • Page 24 RM310 3+1 burners gas grill and set it to the IGNITE/HI position to ignite it. All burners can be used together or in any preferable combinations. Adjust the heat by turning the valve knob(s) between LO and IGNITE/HI position. Igniting the gas grill with a match 1.
  • Page 25 RM310 3+1 burners gas grill Appearance of the flame The burner flame should appear blue and stable as shown pictures. There should be no yellow sparks, loud noise nor should it be raised up from the nozzle. A yellow flame mans that there is not enough oxygen supply. Loud noises and a flame raised up from the nozzle means that there is too much oxygen.
  • Page 26 RM310 3+1 burners gas grill Cooking Tips Before using the gas grill, brush the grill grates with cooking or vegetable oil. Use a brush with a long handle. The juices from the food drip onto the heater during cooking and vaporize. The steam arising from this process contributes to the taste of the food.
  • Page 27 RM310 3+1 burners gas grill firebox. Cleaning the Grease Tray and Box To reduce the chance of fire, the grease tray and grease pan should be visually inspected before each grill use. Remove any grease and wash both with a mild soap and warm water solution.
  • Page 28 RM310 3+1 burners gas grill CAUTION: Heat, weathering, machine oils used in the manufacturing of stainless steel, and dirt can all cause exterior stainless steel surfaces to turn tan in color. In addition, the following products and naturally occurring substances in the outdoors will damage all stainless steel finishes. Use caution so they will not come in contact with your grill.
  • Page 29 RM310 3+1 burners gas grill Troubleshooting Problem Solution The grill does not ignite Ensure that the gas valves are open immediately. Check if sparks are produced when igniting the grill Push the temperature knob for 5 seconds before you turn it to ignite the grill.
  • Page 30 RM310 3+1 burners gas grill TUBE BURNERS: 1 year LIMITED warranty against perforation. COOKING GRIDS and FLAME TAMERS: 1 year LIMITED warranty: does not cover dropping, chipping, scratching, or surface damage. STAINLESS STEEL PARTS: 1 year LIMITED warranty against perforation; does not cover cosmetic issues like surface corrosion, scratches and rust.
  • Page 31 RM310 3+1 burners gas grill Replacement parts or repair labor costs for units operated outside the United States. Pickup and delivery of your product. Postage fees or photo processing fees for photos sent in as documentation. Repairs to parts or systems resulting from unauthorized modification made to the product.
  • Page 32 RM310 3+1 burners gas grill Assistance can be acquired by calling1-866-898-8187 Customer Service Email Address: customerservice@maxumholding.com Website Warranty Registration: www.maxumholding.com (RICHMAN Grills Tab)
