MOTORIZED TREADMILL
Art No. T3000
Owner's Manual

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T3000 and is the answer not in the manual?

Questions and answers

Related Manuals for Justfit T3000

Summary of Contents for Justfit T3000

  • Page 1 MOTORIZED TREADMILL Art No. T3000 Owner’s Manual...

  • Page 2: Safety Instructions

    Safety Instructions • To ensure the best safety of the exerciser, regularly check it on damages and worn parts. • If you pass on this exerciser to another person or if you allow another person to use it, make sure that that person is familiar with the content and instructions in these instructions.
  • Page 3 rming 15 sec conds for each 0 seconds 0 seconds 5 seconds 0 seconds 0 seconds 0 seconds 25 seco onds for ea ach leg 0 seconds 0 seconds 5 seco onds x 3 t times 0 seconds 20 seco onds for ea ach leg 5 times...
  • Page 4 Hard dware Packi ing Li When you u open the e carton, y you will fi nd the be low spare e parts: Tools Parts Li O. DES. Specif fication No O. DES. Specif ication N Main Fram Left Uprigh ht Tube Cove 5 Flat washe Right Uprig...
  • Page 5 Assem mbly I Instru u ction STEP 1. STEP 2.
  • Page 6 Assem mbly I Instru uction STEP 3 STEP 4 #95 5...
  • Page 7 Assem mbly I Instru u ction STEP 5. X X 4...
  • Page 8 Assem mbly I Instru u ction STEP 7. Pulling U Put your r hand on A position then lift up the ba se frame t till hearing the sound d that the pressure e bar B is locked in to the tube.

  • Page 9: Technical Parameter

    Technical Parameter 1690*705*1345mm BUILT UP SIZE(mm) POWER As the rating label showing Maximum 1075*750*1465mm FOLDABLE SIZE(mm) As the rating label showing output power RUNNING BOARD 450*1300mm 1-18KM/H SPEED RANGE SIZE(mm) MAX USER 64KG 130KG NET WEIGHT WEIGHT 1 LCD WINDOW WITH Speed, Time, Distance, Calories, Pulse BLUE BACKGROUND Grounding Methods...

  • Page 10: Window Display

    Console Instructions WINDOW DISPLAY: 1.“SPEED “ window: Display the speed, the speed range is 1.0—18km/h.. 2. ”INCLINE/PULSE” window: Display incline value from 0-16 under default mode. Display the runner’s heart beat when the runner holds handle pulse with two hands. The system can calculate the runner’s heart beat and show in this window, the range is 50-200 beats/min ( This data is just for reference, can’t be as the medical data).

  • Page 11: Button Function

    5. ”CAL” window: Display runner’s calories worked out. it will count from 0 to 999, when up to 999, it will count again from 0; when count down, it will count from the setting data to 0, when down to 0, the machine will stop smoothly and show ‘ End ’, and enter into the situation waiting for operation after 5 seconds.

  • Page 12: Manual Mode

    3. After start-up, you can use “SPEED+”、 “SPEED -” or speed quick buttons to adjust the speed up or down you can use ”INCLINE+/INCLINE-“ button or incline quick buttons to adjust the incline up or down. THE OPERATION OF EXERCISE PROCESS: 1.

  • Page 13: Inner Install Program

    INNER INSTALL PROGRAM Press “PROGRAM” button “DIS” window will display P1-P15 to choose the program you like. Setting of running time, then the distance window display is glittering. Display the advance setting time10:00, press “SPEED+”, “SPEED-” or “INCLINE+”, “INCLINE-“ to set up the exercise time what you need.

  • Page 14: Program Exercise Chart

    PROGRAM EXERCISE CHART Each program will divide into 10 grade for the exercise time and each time sect has the speed accordingly. PROGRAM EXERCISE CHART TIME INTERVAL=SETTING TIME/10 PROGRAM TIME SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED INCLINE SPEED...

  • Page 15: Range Of Program

    RANGE OF PROGRAM Initial Initial Data Set Range Display Range TIME(MIN:SECOND) 0:00 15:00 5:00-99:00 0:00－99:59 SPEED(K/h) 1.0-18 1.0-18 INCLINE(SECTION) 0-16 0-16 DISTANCE(KM) 0.5-99.9 0.00－99.9 PULSE(hypo/min) 50-200 CALORIE(THERM) 10-999 0－999 BODY TESTER: At the beginning state, press “ PROGRAM” continuity entering FAT body fat tester, press “...

  • Page 16: Safety Lock Function

    SAFETY LOCK FUNCTION: Pull out the safety pulling rope, then the treadmill will stop immediately. All the windows display“―――”，the buzzer will make 3 sound “B—B—”,now the treadmill must stop. Attach the magnet end of the safety pulling rope to the computer, the treadmill will be at the beginning of running.

  • Page 17: Exercise Instructions

    EXERCISE INSTRUCTIONS WARM UP STAGE If you are over 35 years old, or not very healthy, also it’s your first time exercise, please consult with your doctor or professional person. Before you use the motorized treadmill, please learn how to control the machine, know well how to start, stop, adjust the speed and so on, don’t stand on the machine at this time.

  • Page 18: Exercise Frequency

    EXERCISE FREQUENCY: The cycle time: 3-5times/Week, 15-60mints/Times. Make up the schedule of workout scientific, not only for your hobby. You can control the running intensity through adjusting the velocity and incline of treadmill. We suggest that you don’t set the incline at first; improve the incline is the effective way to strengthen the exercise’s intensity.

  • Page 19: Maintenance Instructions

    MAINTENANCE INSTRUCTIONS Warning: Unplug the treadmill before cleaning or repairing the treadmill. Clean: Cleaning all the time will prolong the treadmill using life. Get rid of the dust all the time to keep the components clean. Clean the two exposed sides of the running belts will avoid the dust getting under the belt.
  • Page 20 We suggest you purchase the lubricant from our local distributors or contact our company directly. Note: For other maintenance, please get a specialized person to operate. 1． To have a better maintenance over the treadmill and prolong its life, we suggest you power off for ten minutes in every two hours.
  • Page 21 Explo o ded d d rawin n g...

  • Page 22: Parts List

    Parts list Q’TY DESC. SPEC. Base Frame Main Frame Incline Frame Computer Bracket Motor Bracket Left Upright tube Right Upright tube Filter option Inductance option Front Roller Rear Roller Cylinder Bushing Plastic pad Moving wheel plug Moving wheel Running board Console bottom cover PCB board with panel Oval inner plug...
  • Page 23 Parts list DESC. SPEC. Q’TY AC single wire Brown 350 AC single wire Blue 350 Safety key DC motor Incline motor MCB board Transformer Power socket Square switch Overloard protecting Running belt Motor belt Foam Handpulse with incline Handpulse with speed Black rubber cushion Blue rubber cushion Blue rubber cushion...
  • Page 24 Parts list DESC. SPEC. Q’TY Bolt M8*15 Bolt M8*20 Bolt M8*30 Bolt M8*45 Bolt M8*40 Bolt M8*40 Bolt M8*70 Bolt M8*80 Bolt M10*30 Bolt M10*45 Bolt M10*60 Bolt M8*45 Bolt ST3.5*12 Bolt M6*55 Bolt M6*35 Bolt M6*25 Bolt M5*12 Bolt M5*8 Bolt ST4.2*12...
