- Page 1 Kenwood Radio Series TK-x80, -x90, -x150, and -x180 to IP-224 Remote Adapter Panel F.01U.321.735 Rev. 02 2018|03...
- Page 2 Reproduction, in whole or in part, without prior written permission from Bosch is prohibited. Technical Support: *All other trademarks are property of their respective owners. Knowledge Database . http://knowledge.boschsecurity.com/ LiveChat ..... www.telex.com/us/dispatch/support ARRANTY OTICE LIMITED E-mail ....TelexDispatchtechsupport@us.bosch.com OR WARRANTY AND SERVICE INFORMATION REFER TO Web .............
-
Page 3: Table Of Contents
Table of Contents 1.0 Introduction....................5 2.0 Hardware Requirements ................5 3.0 Software Requirements ................5 4.0 Supported Features..................6 5.0 Cable Diagram....................7 5.1 TK-x80 Model Cable Assembly ................7 5.2 TK-x90 Model Cable Assembly ................7 5.3 TK-x150/-x180 Model Cable Assembly..............8 6.0 Radio Setup.................... - Page 4 F.01U.321.735...
-
Page 5: Introduction
Kenwood TK-x80, TK-x90, TK-x150, or TK-x180 series radios • 3.0 Software Requirements C-Soft version 6.500 or later • IP-224 version 2.300 or later • Telex System Manager (TSM) 2.300 or later • Windows 7 (32-bit or 64-bit) • Windows 8.1 • F.01U.321.735... -
Page 6: Supported Features
Kenwood Radio Series 4.0 Supported Features TK-x80, -x150, and -x180 Supported Features Feature Analog Support Feature Analog Support Channel/Talkgroup Emergency Acknowledgement Zone Change Encryption On/Off GPS Read Group Call GPS Trigger On/Off Private Call Monitor On/Off Radio Call Alert ANI Decode Radio Check Emergency Decode Radio Enable/Disable... -
Page 7: Cable Diagram
Kenwood Radio Series 5.0 Cable Diagram 5.1 TK-x80 Model Cable Assembly IP-224 to TK-x80 audio and serial cable connections. This cable is manufactured from a Kenwood KCT-19 accessory cable. Signal IP-224 DB-37 KCT-19 Accessory Connector Ground PTT Common 5.2 TK-x90 Model Cable Assembly IP-224 to TK-x90 audio and serial cable connections. -
Page 8: Tk-X150/-X180 Model Cable Assembly
Kenwood Radio Series 5.3 TK-x150/-x180 Model Cable Assembly IP-224 to TK-x150/-x180 audio and serial cable connections. Signal IP-224 DB-37 TK-XXXX Radio DB-25 Ground PTT Common 12 Aux Input 4 (Programmable) 20 Aux Output 1 (Programmable) There are differences between the TK-x150 and TK-x180 radio’s DB-25 connectors: •... -
Page 9: Radio Setup
2. Configure the Scan Information window to set up the scan functionality. 6.1.2 TK-x80 Series Radio Hardware Modifications To modify the radio settings, do the following: 1. Move R94 to R24 position For more information, see the Kenwood TK-80 series manual, section 1.3. NOTE: F.01U.321.735... -
Page 10: Tk-X90 Series Radio Configuration
Kenwood Radio Series 6.2 TK-x90 Series Radio Configuration 6.2.1 TK-x90 Series Radio Programming To configure the radio, do the following: 1. From the edit menu, select Function Port. The Function Port window appears. 2. Verify the Input tab is open. 3. -
Page 11: Tk-X90 Series Radio Hardware Modifications
Kenwood Radio Series 6.2.2 TK-x90 Series Radio Hardware Modifications The radio ships with pin 13 in DATA. The internal configuration for pin 13 must be modified. To modify the radio settings for pin 13, do the following: 1. Set pin 13 by relocating R641 to R640 for mic signal input. For more information, see the manufacturer’s technical manual Accessory NOTE: Terminal Function section (R640 R641 Function). - Page 12 Kenwood Radio Series 3. From the Com 1 drop down menu, select Data F.01U.321.735...
-
Page 13: Ip-224 Setup
Kenwood Radio Series IP-224 Setup These configuration instructions use TSM (Telex System Manager) to configure the IP-224; however the IP-224 can also be configured using web browser configuration windows. The TSM application and manual can be downloaded at http://www.telex.com/us/dispatch/downloads or is... -
Page 14: Multicast Configuration
Kenwood Radio Series 7.2 Multicast Configuration The Multicast page is used to configure the Line Type, Serial Type, Multicast Addresses, and Multicast Port numbers. To configure Multicast settings, do the following: 1. From TSM, click the Multicast Setup tab. The Multicast page appears. 2. -
Page 15: Hardware Configuration
Kenwood Radio Series 7.3 Hardware Configuration The Hardware Setup page is used to configure the Line I/O connector. Because the Auto Configuration is enabled on the General page, all I/O settings have been configured as needed to control the Kenwood radio selected by the Serial Type drop down menu on the Multicast Setup page. -
Page 16: Per Line Configuration
Kenwood Radio Series 7.4 Per Line Configuration The Per Line Setup page is used to view Line Type and Serial Mode. The Configure buttons allow entry to the individual line’s configuration page. F.01U.321.735... -
Page 17: Per Line Function Tone Configuration
Kenwood Radio Series 7.4.1 Per Line Function Tone Configuration The Function Tone page is used to enable function tones and configure what System/Zone and Channel information should be serially sent to the radio. To configure the Per Line Function Tone, do the following: 1. -
Page 18: Lam/Cor Configuration
Kenwood Radio Series 7.4.2 LAM/COR Configuration The LAM/COR page is used to configure the COR and LAM (VOX) operation. COR is the preferred method for generating RX packets, but when the radio is configured for a trunking format and go-ahead tones need to be heard at dispatch, LAM is the only alternative. -
Page 19: Options Configuration
Kenwood Radio Series 7.4.3 Options Configuration The Options page is used to configure the various options supported by the radio type. Freq Update w/PTT Check Box If selected, the Freq Update w/PTT check box forces a channel change with each PTT. -
Page 20: Gain Configuration
Kenwood Radio Series Scan List If selected, the Scan List check box indicates C-Soft’s scan list is synchronized with the radio’s scan list. All models can be used in scan mode, but the TK-x90 does not pass the NOTE: active channel number back to the console. 7.5 Gain Configuration The Gain Setup page is used to configure the input and output audio levels for line 1 and line 2 I/O ports. - Page 21 Kenwood Radio Series Notes: F.01U.321.735...
- Page 22 Suggestions or comments: Contact technical support with suggestions or comments concerning this application guide. Technical Support: Email: TelexDispatchtechsupport@us.bosch.com Fax: 1-402-467-3279 Phone: 1-800-898-6723 Bosch Security Systems, Inc 8601 East Cornhusker Highway Lincoln, Nebraska 68507...
