- Page 1 LAVA STS Quick Installation Guide ™ Rev. C05...
-
Page 2: Getting Started
Modulation (i.e. RBM) technology when coupled with the LAVA Tablet Manager Application (LTM). The LAVA eSTS extended features rely on the LAVA product working in unison with the LTM application, therefore the installation of LTM is mandatory prior to using a LAVA eSTS product. -
Page 3: Software Setup
1. Download LAVA Software Release Package The LAVA Software Release Package may be downloaded from a web link in the form of a zip file, and therefore needs to be extracted/unzipped. The zip file can be extracted from a web browser on the mobile device or a PC, using one of many online extraction tools that are freely available. - Page 4 LAVA Computer MFG Inc. LAVA eSTS Family Quick Start Guide - Rev C05 4. Install and open LTM.apk Click on the LTM.apk file icon in order to install it. Once LTM has been installed on your device, you will receive a pop-up message providing the option to open the application.
- Page 5 In General Settings (Figure 6), the Product Family must be set according to the LAVA product being used (in this case, eSTS). The Protection Type must also be set according to the mobile device being used. For a list of mobile devices and their suggested Protection Types, select the link located in the Protection Type menu.
- Page 6 LAVA Computer MFG Inc. LAVA eSTS Family Quick Start Guide - Rev C05 7. Once you are satisfied with your configured settings, click “Apply” in the top right corner of the screen. Then, click the arrow in the top left corner of the screen (Figure 8: Buttons to apply changes and return to home screen) to return to the LTM homepage.
-
Page 7: Hardware Setup
Samsung USB Charger & & Charging Cable (included with the mobile device evice) Figure 9: Typical connection of LAVA e : Typical connection of LAVA eSTS to mobile device 2 Vulcan St. Toronto, ON Tel: +1 416 674-5942 www.lavasimulcharge.com www.lavasimulcharge... - Page 8 “Micro-B USB Aux 5V”. Note: For VC units, when connecting the LAVA product to the supply, ensure the wiring is such that the center pin is positive. If the polarity is reversed the damage to the LAVA product is immediate.
- Page 9 7. After establishing a connection with the mobile device, the Green eSTS status LED light will begin blinking on and off to indicate whether the eSTS product is in a charge cycle (eg. Green LED is mostly on and briefly off) or discharge cycle (eg. Green LED is briefly on and mostly off).
-
Page 10: Concluding Steps
LAVA Computer MFG Inc. LAVA eSTS Family Quick Start Guide - Rev C05 Concluding Steps Step 1. Enable Screen Brightness Management (optional) If you would like to install or learn more about the Screen Brightness Management feature, refer to the “Advanced LTM Settings” document. This step is strongly recommended, but optional. - Page 11 More connection settings > Ethernet). Figure 13: More configuration settings on mobile device After establishing a connection with the eSTS, if the Ethernet option is greyed out or unavailable, the mobile device likely does not support a wired connection. If this is the case there is likely nothing that can be done to enable this feature on your mobile device.
- Page 12 LAVA Computer MFG Inc. LAVA eSTS Family Quick Start Guide - Rev C05 Assuming that the Ethernet option is available it may be necessary to enable or disable the wired connection on your mobile device. This can be done by ensuring the Ethernet option is enabled or disabled on the Ethernet page.
- Page 13 LAVA Computer MFG Inc. LAVA eSTS Family Quick Start Guide - Rev C05 Most mobile devices will have DHCP enabled by default. If your network does not have a valid DHCP server, you will need to manually configure an IP Address for the device. Check with your network administrator before using static IP settings.
-
Page 14: Technical Support
(2) this device must accept any interference received, including interference that may cause undesired operation. Lava Computer MFG Inc. 908 Niagara Falls Blvd. #629. N Lava Computer MFG Inc. 908 Niagara Falls Blvd. #629. North Tonawanda NY 14120-2060 2 Vulcan St. Toronto, ON Tel: +1 416 674-5942 www.lavasimulcharge.com...
