Summary of Contents for Lava nSTS
- Page 1 LAVA STS Quick Installation Guide ™ Rev. A05...
-
Page 2: Getting Started
LAVA nSTS Family Quick Start Guide - Rev A05 Getting Started Congratulations on the purchase of a LAVA nSTS product! LAVA’s nSTS product family makes it possible to simultaneously charge select Micro USB Samsung mobile devices while working with various USB peripherals such as printers, mice, keyboards, and even external hard drives. -
Page 3: Hardware Setup
Samsung USB Charger & Charging C & Charging Cable (included with the mobile device mobile device) Figure 1: Standard connection o : Standard connection of LAVA nSTS to mobile device 2 Vulcan St. Toronto, ON Tel: +1 416 674-5942 www.lavasimulcharge.com www.lavasimulcharge... - Page 4 “Micro-B USB Aux 5V”. Note: For VC units, when connecting the LAVA product to the supply, ensure the wiring is such that the center pin is positive. If the polarity is reversed, the damage to the LAVA product is immediate.
- Page 5 More connection settings > Ethernet). Figure 2: More connection settings on mobile device If, after establishing a connection with the nSTS, the Ethernet option is greyed out or unavailable, the mobile device likely does not support a wired connection. If this is the case, there is likely nothing that can be done to enable this feature on your mobile device.
- Page 6 LAVA Computer MFG Inc. LAVA nSTS Family Quick Start Guide - Rev A05 Assuming that the Ethernet option is available, it may be necessary to enable or disable the wired connection on your mobile device. This can be done by ensuring the Ethernet option is selected (i.e.
- Page 7 LAVA Computer MFG Inc. LAVA nSTS Family Quick Start Guide - Rev A05 Most mobile devices will have DHCP enabled by default. If your network does not have a valid DHCP server, you will need to manually configure an IP Address for the device.
-
Page 8: Technical Support
(2) this device must accept any interference received, including interference that may cause undesired operation. Lava Computer MFG Inc. 908 Niagara Falls Blvd. #629. North Tonawanda NY 14120 Lava Computer MFG Inc. 908 Niagara Falls Blvd. #629. North Tonawanda NY 14120-2060 2 Vulcan St.
