- Page 1 ATIM Cloud Wireless Analog sensor reading DINDA User Guide Concerned models: ACW/LW8-DINDA ACW/SF8-DINDA...
-
Page 2: Table Of Contents
OF C ABLES ONTENTS Document version history ........................2 Disclaimer ..............................2 Trademarks and copyright ........................2 Declaration of compliance ........................3 Environmental recommendations ......................3 Explosive atmosphere ............................3 Environment ................................ 3 Radio ..................................4 Technical specifications ........................... 5 Footprint and installation ........................ -
Page 3: Document Version History
Trademarks and copyright ATIM radiocommunications®, ACW ATIM Cloud Wireless® and ARM Advanced Radio Modem® are registered trademarks of ATIM SARL in France. The other trademarks mentioned in this document are the property of their respective owners. ATIM_ACW-DINDA_UG_FR_v1.5... -
Page 4: Declaration Of Compliance
Declaration of compliance All ACW Atim Cloud Wireless® products comply with the regulatory requirements of the R&TTE Directive (1999/5/EC), article 3: 1 SAFETY (Article 3.1a of the 1999/5/EC Directive) NF EN60950-1 Ed. 2006/A1:2010/A11:2009/A12:2011 (health) EN62479: 2010 (power <20mW) or EN62311:2008 (power > 20mW) 2 Electromagnetic compatibility (Article 3.1b of the 1999/5/EC Directive) -
Page 5: Radio
General hazard – Failure to follow the instructions presents a risk of equipment damage. Electrical hazard – Failure to follow the instructions presents a risk of electrocution and physical injury. Direct-current symbol WARNING: do not install this equipment near any source of heat or any source of humidity. WARNING: for your safety, it is essential that this equipment be switched off and disconnected from mains power before carrying out any technical operation on it. -
Page 6: Technical Specifications
Technical specifications Dimensions 90 x 57 x 67 mm Antenna External (SMA connector) -20°C to +55°C (operating) Temperature -40°C to +70°C (storage) Mounts to DIN-Rail Battery 1 x alimentation 10-30Vcc Frequency 865 – 870 MHz Power 25 mW (14 dBm) Sigfox: 100 bps Rate LoRaWan: 300 bit/s à... -
Page 7: Footprint And Installation
Footprint and installation Dimensions given in mm. ACW modems in ‘breaker’ format are attached to a DIN-rail. ATIM_ACW-DINDA_UG_FR_v1.5... -
Page 8: Set Up
Set up a. Positioning Install the modem at a minimum height of 2m and not glued to a wall, ideally offset by at least 20cm. For best results, it is advisable to move the antenna up and clear of any metal obstacle within a radius of 1 meter if possible. -
Page 9: Lights Meaning
Analogical input (Upper terminal): It is the analog input current or voltage that comes from the sensor. To choose a voltage or current reading, in addition to indicating it in the configurator (see Modem configuration section), it is necessary to switch the slide switch to the correct position. For use with a 0-10V sensor, it is necessary to switch the switch to the high position (SMA side). -
Page 10: 10/30V Digital Inputs
e. 10/30V digital inputs The digital inputs IN1 and IN2 have the following function: Either trigger the analogue measurement on each rising or falling edge, then send the measured value to the radio (Sigfox / LoRaWAN). These inputs must be controlled by a voltage between 10V and 30V for an active state. The consumption of these inputs is 30mA max at 30V and 10mA max at 10V. -
Page 11: Modem Configuration
Modem configuration Download and install the configuration software '' setupACW.exe '' at: http://www.atim.com/produit/atim-cloud-wireless-acw/ Connect the module to your computer with a USB cable then launch the software, do not forget to supply the ACW_RS in 10 / 30V. When you connect the module, the software window changes to allow you to access the main features. -
Page 12: Common Configuration (Calibration)
a. Common configuration (calibration) Note In the lower part, you can read in real time (periodic sampling of 2s) the value measured by the module. ✓ Analog measurement Here you can choose the type of measured value (current or voltage). You must also make this choice on the slide switch (see Set Up). -
Page 13: Periodic Mode Configuration (Sf8/Lorawan)
b. Periodic mode configuration (SF8/LoRaWAN) In this mode of operation, an analog measurement is performed and sent in radio every X time (X is a configurable value). ✓ Statement period This menu allows you to configure the elapsed time between 2 sending of data. This period is between 10min and 23h50min with a step of 10min. -
Page 14: Threshold Mode Configuration (Sf8/Lorawan)
c. Threshold mode configuration (SF8/LoRaWAN) In this operating mode, an analog measurement is performed every X time (X is a configurable value). In the case where the measured value is not between the two thresholds (configurable) the value will be transmitted in radio. - Page 15 Note When a threshold is reached, it changes value, 5% greater for the low threshold and 5% smaller for the high threshold. 5% of the range of measurement. For example, if the min value is -2 and the max value is 14, Se will be 5% of 16 ATIM_ACW-DINDA_UG_FR_v1.5...
- Page 16 Operating example In this example the 'Sampling period' is set every hour and only one 'temperature sent' is set to 13h. The min value is 0 and the max value is 10. The threshold values could be 5V and 8V (black curve). This means that if the measured value is outside thresholds (5V and 8V), the thresholds will be changed to 5% and will become 5.5V and 7.5V (curve in gray).
-
Page 17: Frames Formatting
Frames formatting The first byte is a header, it defines the following data present in the frame. The useful elements therefore vary according to the type of frame sent. The frames to the ACW-DA modem are : TYPE DESCR. FORMAT DE LA TRAME octet 0 octet 0 octet 1... - Page 18 The data is decoded as follows: Logic level digital inputs Octet 1 Input 1 Input 2 Voltage Value Octets 2 & 3 V(V) = VOLTAGE * (( 10-0 ) / 64240) Current Value Octets 2 & 3 C(mA) = CURRENT * (20-4)/47584 Example of a received frame (hex) 1920C4510000FFFF00000000 ‘Frame type’...
-
Page 19: Help
Modem LED does not flash • Check if the power supply is properly connected to the modem • Configure the modem using the USB configurator Technical Support For any information or technical problems, you can contact our technical support: https://www.atim.com/en/support-2/technical-support/ ATIM_ACW-DINDA_UG_EN_v1.5...
