iPixel LED Light S010060CB3SB7 Installation Instructions

R
iPixel LED Light Co

Product Description

This is a new chip again from worldsemi family , based on
WS2812B and WS2813.
To solve the chip breakdown and Strip's Voltage drop ,
now we welcome WS2815.
The Flex is 60 Pixel/ LED per meter ,and 5 m in a roll we
provide black and white color board.
same as our other addressable tapes, it's cut-able per unit
LED with a large soldering Pad
which makes easy to re-solder again.


60Pixel 12V Addressable LED Strip



the PCB printed +12V DI ,BI, GND , both DI and BI
means signal but it's only required to link the DI
cable to your controller.
this PCB made by 3Ounce copper for more reliable
application.
3 M tape attached on backside of strip.
again we suggested you power it every 5 meters even
it's 12V addressable.
.
,
Ltd
