Operating Manual
--SFN19 Flooring Coil Nailer--
IMPORTANT INFORMATION
NOTE: Please read and fully understand the instructions in this
manual before operating the pneumatic power tool. Carefully read
through this OPERATOR'S MANUAL to ensure efficient, safe
operation. It is recommended that the Manual be kept readily
available as an important reference when using this tool.
Advertisement
Table of Contents
Related Manuals for Spotnails SFN19
Summary of Contents for Spotnails SFN19
- Page 1 Operating Manual --SFN19 Flooring Coil Nailer-- NOTE: Please read and fully understand the instructions in this manual before operating the pneumatic power tool. Carefully read through this OPERATOR'S MANUAL to ensure efficient, safe operation. It is recommended that the Manual be kept readily available as an important reference when using this tool.
- Page 2 WARNING: The warnings, cautions and instructions discussed in this instruction manual cannot cover all possible conditions and situations that may occur. It must be understood by the operator that common sense and caution are factors which cannot be built into this product but must be supplied by the operator.
- Page 3 WARNING: The operating instructions shall draw attention to the following a) Only those fasteners listed in the operating instructions may be used in the fastener driving tools; NOTE: The fastener driving tool and the fasteners listed in the operating instructions must be seen as one unit system in terms of technical safety.
-
Page 4: Safety Information
SAFETY INFORMATION WARNING: BEFORE USING THE TOOL, READ CAREFULLY AND UNDERSTAND THE FOLLOWING SAFETY INSTRUCTIONS.FAILURE TO FOLLOW WARNING COULD RESULT IN DEATH OR SERIOUS INJURY. 1. WEAR SAFETY GLASSES OR GOGGLES. Danger to the eyes always exists due to the possibility of dust being blown up by the exhausted air or of a fastener flying up due to the improper handling of the tool. - Page 5 6. DO NOT USE THE WRONG FITTINGS. The connector on the tool must not hold pressure when air supply is disconnected. If a wrong fitting is used, the tool can remain charged with air after disconnecting and thus will be able to drive a fastener even after the line of air is disconnected, possibly causing injury. 7.
- Page 6 15. DO NOT DRIVE FASTENERS ON THE TOP OF OTHER FASTENERS. Driving fasteners of the top of other fasteners may cause deflection fasteners which could cause injury. 16. REMOVING THE FASTENERS AFTER COMPLETING OPERATION If fasteners are left in the magazine after the completion of operation, there is the danger of a serious accident occurring prior to the resumption of operation, should the tool be handled carelessly, or when connecting the air removes all fitting.
-
Page 7: Technical Data
TECHNICAL DATA Type of tool SFN19 Construction Coil Nailer 11-1/8”X4-1/4”X10-1/8” Dimensions 248mmX108mmX260mm Weight (without fasteners) 1.60kgs (3.50lbs.) Actuation mode Contact/Single-sequential actuation Magazine capacity 200 nails (plastic sheet collated nails) Maximum allowable pressure 120psi (8.3bar) Recommended pressure range 70psi to 100psi (5bar to 7bar) Fasteners Only the nail sizes shown in the table below can be driven with this nailer. - Page 8 NAILER CONNECTION AND OPERATION NOTE: The information contained in this manual is designed to assist you in the safe operation of the nailer. Some illustrations in this Manual may show details or attachments that are different from those on your nailer. Air Supply, Connections and Operating Pressure Read section titled SAFETY.
- Page 9 Tool Connection and Operation Lubricator • The lubricator supplies an oil mist to the tool. • Inspect the lubricator before operation to be sure the supply of lubricant is adequate. • If an inline lubricator is not used, a few drops of pneumatic oil will need to be added to the tool inlet before each use.
-
Page 10: Instruction For Operation
INSTRUCTION FOR OPERATION 1. Before operation (1) Wear safety glasses & ear protection (2) Do not connect the air supply (3) Inspect screw tightness (4) Check operation of the contact arm & trigger are moving smoothly (5) Connect the air supply (6) Check for air-leakage. -
Page 11: Maintenance And Inspection
2. Remove all nails. 3. Remove the jammed nail with a slotted head screwdriver or pin punch. 4. In case of frequent jams, contact a Spotnails stockist. A qualified person should perform repair and maintenance Periodic maintenance to be performed: •... - Page 12 PARTS LIST-SFN19 CODE Description CODE Description 394501 BOLT M6X20 (Loctite) 394555 TRIGGER STEM 394502 BUSHING 394556 O-RING 2.5X1.4 394503 EXHAUST COVER 394557 TRIGGER VALVE SPRING 394504 EXHAUST FILTER (A) 394558 O-RING 8.6X1.9 394505 EXHAUST FILTER (B) 394559 TRIGGER VALVE BUSHING...
- Page 13 TOOL SCHEMATIC-SFN19...
