- Page 1 Kwik-Trench Mini-Trencher KT100 OPERATORS MANUAL WITH MAINTENANCE AND PARTS INFORMATION 1.800.227.7515 LITTLEBEAVER.COM P.O. Box 840, Livingston, TX 77351 Phone: 936.327.3121 Fax: 936.327.4025 MFG BY: Little Beaver, Inc. 0418 sales@littlebeaver.com...
- Page 2 10 days after receipt of replacement parts. Be sure to prepay the shipping charges, we will not accept collect or COD packages. Our mailing address... LITTLE BEAVER, Inc. 2009 South Houston P. O. Box 840 Livingston, Texas 77351...
- Page 3 SAFETY ALERT SYMBOL The symbol shown above is used to call your attention to instructions concerning your personal safety. WATCH THIS SYMBOL — It points out important safety precautions. It means — ATTENTION! BECOME ALERT! YOUR PERSONAL SAFETY IS INVOLVED! Read the message that follows and be alert to the possibility of Personal Injury or Death! WARNING: The Engine Exhaust from this product contains chemicals known to...
-
Page 4: Table Of Contents
TABLE OF CONTENTS OPERATORS MANUAL Page # Customer Service Information Safety Alert, Warranty and Machine Information Table of Contents Safety Instructions Maintenance and Lubrication, Clutch Maintenance and Lubrication, Cutter Hub Assembly Instructions Trenching Instructions PARTS MANUAL Page # Clutch/Cutter Hub Assembly P-2 &... -
Page 5: Safety Instructions
SAFETY INSTRUCTIONS DANGER: Failure to observe safety instructions and reasonable safety practices can cause Property Damage, Serious Bodily Injury and/or Death. BE CAREFUL!! WATCH OUT FOR BYSTANDERS!! DANGER: NEVER dig trenches where there is a possibility of underground power cables or other hazards. -
Page 6: Maintenance And Lubrication, Clutch
MAINTENANCE and LUBRICATION DANGER: NEVER run engine inside building or enclosed area. Exhaust gases contain carbon monoxide, an odorless and deadly poison. Engines are shipped without oil or gasoline. Refer to MANUFACTURER'S INSTRUCTIONS for proper procedures and recommended fluids. IMPORTANT DO NOT drop the machine off the back of a vehicle, this may cause damage to the body and frame. - Page 7 MAINTENANCE and LUBRICATION Cont... CUTTER HUB: REMOVING THE CUTTER HUB: Should it ever be necessary to remove the cutter hub, remove the three (3) cap screws and insert two (2) 1/4" - 20 cap screws into the threaded holes in the bushing flange.
-
Page 8: Assembly Instructions
TRENCHER ASSEMBLY INSTRUCTIONS: Install three (3) tires with valve stem facing out. Insert bolt through tire wheel and frame axle. Attach nut to bolt. Tire pressure should be 40 lbs. PSI. Remove two (2) bolts from open neck of frame. Insert the push handle, re-install bolts. Attach lift hand lever. -
Page 9: Trenching Instructions
TRENCHING INSTRUCTIONS: NOTE: If in hard ground, roots and other problem areas. DO NOT try and force machine. Let the cutting blade do the cutting. Over pushing may cause the blade to bog-down. Put trencher in position. Set the steel chain for digging depth. If the chain is left unhooked, the full depth of eight inches will be obtained. - Page 10 PARTS INFORMATION NOTES:...
-
Page 11: Clutch/Cutter Hub Assembly
CLUTCH/CUTTER HUB ASSEMBLY ITEM # PART # DESCRIPTION KT4-1032 Shoulder Bolt, Socket Hd., 1/2 x 1 3/4 KT4-1031 Spring, Die KT4-1017 Friction Plate KT4-1029 Clutch Facing KT4-1014 Disc KT4-1026 Nylon Bearing KT4-1071 Dowel Pin, 1/4" x 5/8" KT4-1013 Blade Holder KT4-1015A Blade (Specify 1,2,3,4,5,6 or 7) 12"... -
Page 12: Frame Assembly
FRAME ASSEMBLY KT100 - 13 - 12 Page P-2 0798... - Page 13 FRAME ASSEMBLY KT100 ITEM # PART # DESCRIPTION KT-011 Push Handle Assy. (w/ handle grips) KT-010 Handle Grips KT-032 Chain, 5/16, 8 links KT-106 Height Adjustment Handle (w/ handle grip) 30194 Handle Grip KT-108 Frame Assembly KT-206 Kick Plate KT-234...
- Page 14 THINK SAFETY FIRST P.O. BOX 840 LIVINGSTON, TEXAS 77351 PH# 936/327-3121 FAX# 936/327-4025 Web: www.littlebeaver.com E-Mail: sales@littlebeaver.com...
