Merlin@home™ Transmitter
Model EX1100
Quick Start Guide
Send Your Information
1
Place the wand, green side towards you, over
your implant.
2
Quickly press and release the Start button. The
transmitter beeps.The Stars icon lights up.
3
Quickly press and release the Start button again.
The transmitter beeps.
4
Read
The Read icon lights up, the transmitter is read-
ing your implant.
Advertisement
Table of Contents
Related Manuals for St. Jude Medical Merlin@home EX1100
Summary of Contents for St. Jude Medical Merlin@home EX1100
- Page 1 Merlin@home™ Transmitter Model EX1100 Quick Start Guide Send Your Information Place the wand, green side towards you, over your implant. Quickly press and release the Start button. The transmitter beeps.The Stars icon lights up. Quickly press and release the Start button again. The transmitter beeps.
- Page 2 Send When the Tower icon lights up, you can remove your wand. The transmitter dials out and sends information about your implant. Sometimes this process takes a while. You can leave. Do not use the phone line while the Tower icon is lit. Done When the Stars icon lights up, your information is successfully sent.
- Page 3 Can’t send information 1. Check your wall jack and phone connector. 2. Turn off any fax, computer, or TV that shares your phone line. 3. Press the Start button to continue. Call your clinic 1. Press the Start button to stop the beeping. 2.
