READ INSTRUCTIONS CAREFULLY: Read and follow all instructions. Place instructions in a safe
place for future reference. Do not allow anyone who has not read these instructions to assemble,
light, adjust or operate the heater.
Installer: Leave this manual with the appliance. Consumer: Retain this manual for future reference.
UNVENTED LP-GAS FIRED ROOM HEATER
WARNING: If the information in this manual is not followed exactly, a fi re or explosion may result causing
property damage, personal injury, or loss of life.
- Do not store or use gasoline or other fl ammable vapors and liquids in the vicinity of this or any other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Shut off gas supply
• Do not try to light any appliance
• Do not touch an electrical switch; do not use any phone in your building.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fi re department.
- Installation and service must be performed by a qualifi ed installer, service agency, or the gas supplier.
WARNING: This is an unvented gas-fi red heater. It uses air (oxygen) from the room in which it is installed.
Provisions for adequate combustion and ventilation air must be provided. Refer to Fresh Air for Combustion and
Ventilation section on page 4 of this manual.
WARNING: Improper installation, adjustment, alteration, service or maintenance can cause injury or property
damage. Refer to this manual for correct installation and operational procedures. For assistance or additional
information consult a qualifi ed installer, service agency, or gas supplier.
This appliance may be installed in an aftermarket permanently manufactured (mobile) home, where not prohibited
by local codes. This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not
convertible for use with any other gas.
Unvented Liquid Propane Fired Room Heater
OPERATING INSTRUCTIONS
AND OWNER'S MANUAL
Plaque Heaters
HSVFRD10LPTS
HEATSTAR, 4560 W. 160
TH
ST., CLEVELAND, OHIO 44135 · 800-251-0001
Blue Flame Heaters
HSVFBF10LPTS
1
Installation Instructions and Owner's Manual
Model #
HSVFBF10LPTS
HSVFRD10LPTS
2016 - CB
Advertisement
Table of Contents
Related Manuals for HeatStar HSVFBF10LPTS
Summary of Contents for HeatStar HSVFBF10LPTS
- Page 1 This appliance is only for use with the type of gas indicated on the rating plate. This appliance is not convertible for use with any other gas. 2016 - CB HEATSTAR, 4560 W. 160 ST., CLEVELAND, OHIO 44135 · 800-251-0001 Unvented Liquid Propane Fired Room Heater...
-
Page 2: Table Of Contents
WARNINGS IMPORTANT: Read this owner’s manual carefully and completely before trying to assemble, operate, or service this heater. Improper use of this heater can cause serious injury or death from burns, fi re, explosion, electrical shock, and carbon monoxide poisoning. Young children should be carefully supervised •... -
Page 3: Specifications
SPECIFICATIONS MODEL HSVFRD10LPTS HSVFBF10LPTS BTU (Available) 10,000 10,000 Type of Gas LP-Gas Only LP-Gas Only Ignition Electronic Pulse (AA Battery) Electronic Pulse (AA Battery) Pressure Regulator Setting 10 Inches of Water 10 Inches of Water Inlet Gas Pressure (Maximum) 14 Inches of Water... -
Page 4: Thermostatic Control
SAFETY DEVICE atmosphere have a continuous water vapor retarder with a rating of one perm (6 x 10 kg per pa-sec-m This heater has a pilot with an Oxygen Depletion or less with openings gasketed or sealed and Sensor (ODS) safety shut off system. The ODS/pilot b. -
Page 5: Installation
3. Add the Btu/hr of all the fuel-burning appliances in the space such as, Vent–free heater, Gas water heater, Gas furnace, Vented gas heater, Gas fi replace logs, and Other gas appliances* 12” *Do not include direct-vent gas appliances. Direct- vent draws combustion air from the outdoors and Or remove vents to the outdoors. -
Page 6: Fastening Heater To Wall
WARNING: A qualifi ed service person must install • Where there is easy access for operation, heater. Follow all local codes. inspection, and service. • CHECK GAS TYPE In the coldest part of the room. Use only LP-gas. If your gas supply is not LP-gas, do CAUTION: If you install the heater in a home garage: not install heater. - Page 7 Attaching to Wall using Anchor: For attaching mounting bracket to hollow walls (wall areas between studs) or solid walls (concrete or masonry) (2) Screws Note: Wall anchors, mounting screws, and spacer (2) Screws are in hardware package. The hardware package is provided with heater.
-
Page 8: Connecting To Gas Supply
*A CSA/AGA certifi ed equipment shutoff valve with 1/8” NPT tap is an acceptable alternative to test gauge Screw Screw connection. Purchase the CSA/AGA certifi ed equipment hole hole shutoff valve from your dealer. IMPORTANT: Install an equipment shutoff valve in an accessible location. -
Page 9: Operating Your Heater
OPERATING YOUR HEATER Pressure FOR YOUR SAFETY READ BEFORE LIGHTING Regulator WARNING: If you do not follow these instructions exactly, a fi re or explosion may result causing property damage, personal injury or loss of life. 3/8” NPT Pipe Nipple Heater A. - Page 10 • Do not use this appliance if any part has been 9. To select the desired heat level, turn the underwater. Immediately call a qualifi ed service temperature setting knob to desired comfort technician to inspect the appliance and to setting from 1 to 5.
-
Page 11: Cleaning And Maintenance
CLEANING AND MAINTENANCE CLEANING HEATER CABINET Air passageways WARNING: Turn off heater and let cool before servicing. • Use a vacuum cleaner or pressurized air to CAUTION: You must keep control areas, burner and clean circulation air passageways of heater clean. Inspect Exterior these areas of heater before use. -
Page 12: Troubleshooting
TROUBLESHOOTING NOTE: All troubleshooting items are listed in order of operation and likely occurrence. WARNING: Only a qualifi ed service person should service and repair heater. CAUTION: Never use a wire needle, or similar object to clean ODS/pilot. This can damage ODS/pilot unit. Make sure grille guard is in place before running heater. - Page 13 OBSERVED SYMPTOM POSSIBLE CAUSE REMEDY Heater shuts off in use (ODS operates) 1. Not enough fresh air is available 1. Open window and/or door for ventilation 2. Low line pressure 2. Contact local gas company 3. ODS/pilot is partially clogged 3.
-
Page 14: Parts List And Diagram
PARTS LIST AND DIAGRAM MODEL: HSVFBF10LPTS ITEM PART DESCRIPTION ITEM PART DESCRIPTION 80040 Wire Guard 80020 Regulator Connection 80051 Front Panel 80058 Floor Mounting Feet 80038 Glass 80052 Back Panel 80024 Reflector 80036 Wall Mounting Bracket 80026 Reflector Back Panel... - Page 15 PARTS LIST AND DIAGRAM MODEL: HSVFRD10LPTS ITEM PART DESCRIPTION ITEM PART DESCRIPTION 80040 Wire Guard 80020 Regulator Connection 80051 Front Panel 80058 Floor Mounting Feet 80024 Reflector 80052 Back Panel 80030 Burner Assembly 80036 Wall Mounting Bracket 80056 ODS Pilot Assembly w/ Thermocouple (LP) 80028 Heat Shield 80032...
-
Page 16: Warranty
DIRECT FROM THE FACTORY AND MUST BE INSTALLED BY A QUALIFIED SERVICE AGENCY. REPLACEMENT PARTS ORDERING INFORMATION: PURCHASING: Accessories may be purchased at any HEATSTAR local dealer or direct from the factory FOR INFORMATION REGARDING SERVICE Please call Toll-Free 866-447-2194 www.mrheater.com...
