Summary of Contents for Nortek Control SpeakerCraft HRSi
- Page 1 SpeakerCraft HRSi / XTEQi HRSi-8 / HRSi-10 / HRSi-12 / XTEQi-12 HRSi XTEQi INSTALLATION GUIDE...
-
Page 2: Table Of Contents
Warning: The device meets the exemption from the routine evaluation limits in section 2.5 of RSS 102, and users can obtain Canadian information on RF exposure and compliance from the Canadian Representative Product Solutions Group at Tel: (519) 763-4538. SpeakerCraft HRSi / XTEQi... -
Page 3: Important Safety Information
mportant afety nformatIon Read these instructions Keep these instructions CAUTION Heed all warnings RISK OF ELECTRIC SHOCK Follow all instructions DO NOT OPEN Do not use this apparatus near water Clean only with dry cloth. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, Do not block any ventilation openings. -
Page 4: Unpacking
Dealer . mplIfIer anel eatureS ➊ STATUS ➒ ➋ ➑ 100-120V~ 220-240V~ L/LFE ➐ ➏ OPTIONAL WIRELESS RECEIVER LOW LEVEL POWER USB POWER FUSE T8AL/250V 500mA 100-120V~60Hz 6A ➌ 220-240V~50Hz 3A HRSi ➍ ➎ SpeakerCraft HRSi / XTEQi... - Page 5 Power Indicator. This light is illuminated blue when the subwoofer is turned on and playing. It illuminates red when the subwoofer is in on, but in Standby mode. Low-Level Inputs. These connect with RCA type cables from the line-level outputs of your receiver or preamp.
- Page 6 12. Balanced OUT (XTEQi-12 only). These connect with Balanced type cables to daisy-chain additional subwoofers or powered speakers. These outputs are pass-thru, meaning they will pass through the same audio signal that is fed into the Balanced IN. SpeakerCraft HRSi / XTEQi...
-
Page 7: Subwoofer Placement
ubwoofer lacement Subwoofer placement can greatly influence its performance . All rooms are different, but the loudest output will likely occur if the subwoofer is placed in a corner of the room on the same wall as the front channel speakers . You may need to experiment with more than one location, always testing the sound from the primary listening position until you find the right balance and consistency in the bass performance . -
Page 8: Connecting Your Subwoofer (Lfe)
If you have a Home Theater processor or receiver, it probably has an independent subwoofer volume and crossover control . If so, you should set the subwoofer’s volume control to 50, the crossover to LFE, and use the processor’s subwoofer level and frequency controls for adjustments . SpeakerCraft HRSi / XTEQi... -
Page 9: Connecting Your Subwoofer (Stereo)
onnectIng your ubwoofer tereo 2-Channel Ampli er LFE/ Stereo Output STATUS 100-120V~ 220-240V~ L/LFE OPTIONAL WIRELESS RECEIVER LOW LEVEL POWER USB POWER FUSE T8AL/250V 500mA 100-120V~60Hz 6A 220-240V~50Hz 3A HRSi HRSi Subwoofer (back) If your processor or receiver does not have a Sub/LFE output, but has a stereo output, you can connect a stereo RCA type cable from the stereo output to the Low Level red and white inputs on the back on the subwoofer . -
Page 10: Configuring Your Subwoofer
Bluetooth must be turned on to configure the subwoofer with the smartphone companion app. Peripherals- Device name- Displays the current subwoofer name. Can also be used to set a new subwoofer name. Peripherals- Scan for devices. Scans for other subwoofers. SpeakerCraft HRSi / XTEQi... -
Page 11: Crossover
Crossover Crossover. Selects the low pass filter frequency and is adjustable from 42Hz to 500Hz. Variable/LFE toggle. Toggles between using the app to select the low pass filter frequency and the AV Receiver selecting the low pass filter frequency. Slope. Adjusts the slope of the crossover frequency. The higher the value, the steeper the cutoff. -
Page 12: Delay
Frequency, Gain and Q of 4 independent EQs . Select the EQ you would like to adjust using the radio buttons labeled “EQ1, EQ2, EQ3, EQ4” then choose the frequency, amount of gain or cut and Q using the sliders . SpeakerCraft HRSi / XTEQi... -
Page 13: Using Auto Eq
Using Auto EQ Auto EQ is used to compensate for and correct for acoustic room anomalies that can cause inferior bass performance . Auto EQ takes a series of measurements in and around your primary listening position, makes complex calculations and applies those acoustic corrections- all from the comfort of your listening area . -
Page 14: Specifications
Communication Type Bluetooth Low Energy Crossover Frequency 40-500Hz Dimensions (L x W x H) mm / inches 19 .2"x18 .1"x17 .7" (488mm x 460mm x 450mm) Voltage 100-120VAC or 220-240VAC Selectable Cabinet 1” High Gloss MDF SpeakerCraft HRSi / XTEQi... -
Page 15: Limited 2-Year Warranty
ImIted arranty Nortek Security & Control, LLC (“Nortek Security & Control”) warrants to the original retail purchaser only that this product will be free of manufacturing defects in material and workmanship for the following periods and subject to the limitations and exclusions set forth below: 2-Year Warranty This warranty is not transferable to subsequent purchasers of the product. -
Page 16: Attention: To Our Valued Customers
ttentIon alued uStomerS To ensure that consumers obtain quality pre-sale and after-sale support and service, products are sold exclusively through authorized dealers . This warranty is VOID if the products have been purchased from an unauthorized dealer . Nortek Security & Control offers a variety of accessories to make your installation of this and other products easy, economical, and professional .
