ACER X223W Go to cover page 1.1 SCOPE This document defines the design and performance requirements for an 20/22W inch diagonal , flat panel monitor .The display element shall be a WSXGA (1680x1050) resolution TFT-LCD (Thin Film Transistor Liquid Crystal Display).16.7M color(RGB 6bits+FRC) images are displayed on the panel.Video input signals are...
Minimum range Note 1) Note 1) 75Ω to Ground ACER X223W Go to cover page The three video inputs consist of Red ,Green , and Blue signals, each with its own coaxial cable terminated at the monitor. These video signals are analog levels, where 0...
ACER X223W Go to cover page 126.96.36.199 Abnormal Signal Immunity The monitor shall not be damaged by improper sync timing , pulse duration , or absence of sync , or abnormal input signal amplitude ( video and/ or sync too large or too small) , or any other anomalous...
Inrush Current Hot Start Cycle Under Voltage Line Transient ACER X223W Go to cover page The monitor shall contain provisions to “stretch” the video signal, so that an input signal from the computer in any resolution smaller than 1680 x 1050 is automatically expanded to fill the entire screen.
ACER X223W Go to cover page 1.3.8 Display Communications Channel The monitor assembly shall provide a display communications channel that conforms to VESA DDC2Bi hardware requirements. This configuration shall contain the 128-byte EDID file as specified by VESA EDID standard.The monitor should not write to...
1. Product Specification (continued) Optical Characteristics Depends on the LCD supplier's spec. Details refer to QA Inspection Spec. Minimum Separation N / A 15 mm 15 mm 15 mm 25.4 mm 25.4 mm Not applicable ACER X223W Go to cover page...
ACER X223W Go to cover page 4.1 Assembly procedures: Connect the cable between power board(P802) and interface board (P301) Connect the function key cable into interface board(P306) Connect the FFC cable into interface board P301 P802 Take a bracket chassis base on a protective cushion and stick an insulator on the specific position, take a power board and turn it over.
Angel < 5 degrees Plug 8 lamp cables to the connectors of power board.(Both of right and left sides) ACER X223W Use a Phillips-head screwdriver screwed the No.1~4 screws on both side and assemble the LCD panel and bracket chassis module.
ACER X223W Go to cover page Put a ear over n he ssembled nit nd ress on force echanisms ocked nd irmly attached Assemble the stand upper side to the rear cover through the way of screwing 4 screws till both units firmly attached.
,power cable on specific positions as photo below. USER’S MANUAL STAND Move previous assembled parts into the carton then stick Vista and feature label on the carton then packing the carton FEATURE LABEL VISTA LABEL D-SUB CABLE ACER X223W Go to cover page...
ACER X223W Go to cover page 4.2 Disassembly procedures Open the carton with a proper tool. FEATURE LABEL VISTA LABEL Take out all accessories including D-SUB cable power cable, DVI cables, user’s manual, and stand base and packing material from the carton.
Work your way along the front bezel to disengage all the locking mechanism. ACER X223W Unhook the key function board from rear bezel, disconnect the key function cable Use a Hex-head screwdriver unscrewed 4 screws to...
ACER X223W Go to cover page Use a Phillips-head screwdriver unscrewed the No.1~4 screws to disassemble the LCD panel and bracket chassis module. (No1~4 screw size=M3x6; Torque=3~4KGFxCM). Unplug 4 lamp cables (No. 1~4). Take out lamp cables right through the No.1 and 2 square holes and separate the bracket chassis module and LCD panel apart.
Use a Phillips-head screwdriver unscrewed the No.1~4 screws to disassemble the power board. (No1 screw size=M4x8; No2~4 screw size=M3x6; Torque=9~10KGFxCM). Disconnect the FFC, P301, and function key cables to connectors of interface board. P301 P802 P306 ACER X223W Go to cover page...
ACER X223W 5. Troubleshooting Go to cover page 5.1 No.display of screen (Screen is black, color of LED is amber) Does OSM display when you push PROCEED buttom. Proceed "No OSM display" section. When a signal isn't being inputted, it is indicated with "No Signal Input".
2) Reconnect the video cable. 3) Change the video cable. Check if the LCD video signal cable is connected between the Interface Board and LCD module. Next Page ACER X223W Go to cover page Failure Point The LCD video signal cable is disconnected.
ACER X223W Go to cover page 5.2 Nothing display on screen (screen is black, color of LED is blue) continued Continue Check the 5V power supply for P304 pin 1, 2, 3 Check the input voltage level whether was changed when pressed function...
Failure Point 1) printed wire broke between P301 pin2, R303 and I305 pin 88. 2) I305 is failure. Failure Point 1) printed wire broke between P301 pin3, R301 and I305 pin86. 2) I305 is failure. ACER X223W Go to cover page...
ACER X223W Go to cover page 5.4 Abnormal screen for VGA signal from computer input on Check the R, G, B input video respectively that their level is 0.0 5. Troubleshooting (continued) Check the R, G, B video P302 of video connector.
2) Printed wire broke among P306 pin5,R372, and I305 pin89. 3)C386,C388 ,C389,C390 are short. Failure Point 1) Function key wire disconnection. 2) Function key wire is failure. 3) Function key board is failure. ACER X223W Go to cover page...
ACER X223W Go to cover page 5.6 Abnormal plug and play operation for VGA Confirm the host computer supplies DDC2B mode. Check the voltage on P302 pin9 that is power Check the voltage on I303 pin8 that is power DC 5 V.
5. Troubleshooting (continued) level. Failure Point Video cable is failure. level. Failure Point 1) Printed wire broke between P302 pin13 and I305 pin27. 2) FB309, R321 are short. 3) D307 or R324 or C327 is short. ACER X223W Go to cover page...
ACER X223W Go to cover page 5.8 Checking the resolution change IC movement Check +3.3V supply on I305 pin8, pin14, pin16, pin24 , pin32, pin49, pin56, pin75, pin98 Check +1.8V supply on I305 pin 51, 66, 82, 34. Check X301 14.318MHz clock input to I305 pin96 and pin97 at TTL level.
1) Printed wire broke between P301 pin5, pin6, and I302 pin3. Failure Point I302 is failure. Q305 pin1. Failure Point Printed wire broke between I302 pin2, pin4 and Q305 pin1. Failure Point D326 is failure. ACER X223W Go to cover page...
