Summary of Contents for Montgomery Ward MW12000
- Page 1 Window AC 12000BTU Instruction Manual MODEL: MW12000 Item No.: 718911 Montgomery Ward Customer Service 115V~, 60Hz, 1060W 1112 7th Avenue, Monroe, WI 53566 8:00 am to Midnight, Monday through Friday Wards.com 1 3848 Wards.com 1 3848 • • • •...
-
Page 2: Table Of Contents
18. Do not unplug air conditioner when it is operating. THIS APPLIANCE IS FOR HOUSEHOLD USE ONLY 19. Use care when removing the filter. Do not touch metal parts of unit when remov- © 2015 Montgomery Ward, Inc. All rights reserved. Wards.com 3848 •... -
Page 3: 3-Prong Plug
Installation Important Safeguards (cont’d) (cont’d) ing filter. 20. Before cleaning, turn power OFF and unplug from electrical outlet. 21. Do not insert body parts or tools into the inlet or outlet grills during operation. 22. Do not ingest water drained from air conditioner. 23. - Page 4 Installation Installation (cont’d) (cont’d) Remove air conditioning unit and accessories from box. Save box to use for stor- age of unit during the winter or when not in use for long periods of time. 1. Guide Panel Assembly: Install the curtain (Item H) into the curtain sash (Item G) with the middle clip on the inside of the curtain sash.
- Page 5 Installation Installation (cont’d) (cont’d) CAUTION: Hold unit firmly until window sash is lowered to top channel behind the 3. Guide Panels: upper guide. Personal injury or property damage may result if the air conditioner falls from the window. Extend the curtains in the guide panels and slide them down into the T-shaped groove on the left and right sides of the unit.
-
Page 6: Ac Removal
AC Removal Installation (cont’d) To remove air conditioner, turn power OFF and disconnect power cord. Remove the 7. Secure Guide Panels: 5 screws installed in the top and bottom of the guide panels. Close guides and with a firm grip on the unit tilt outward to allow any condensation to drain out. Fasten the top of the guide panels to the sash with 3 screws (Item B). - Page 7 Operating Instructions Operating Instructions (cont’d) (cont’d) Control Panel Functions: Remote Control: Power - Use to turn AC ON and OFF. To use the remote control, you must be within 20 feet of the unit with a clear line of sight. CAUTION: After powering off the AC or switching from cooling to fan, wait a mini- Remove batteries when control is not in use for long periods of time.
-
Page 8: Cleaning And Care
Cleaning and Care Operating Instructions (cont’d) Remote Control (cont’d) WARNING: Turn AC OFF and remove plug from outlet prior to cleaning. Increase Temperature Air Filter Cleaning: – Timer Increase See instructions Only works in Cool Mode. Press- under Control Panel Functions. ing and holding will increase temp The air filter should be checked at least twice a month to see if cleaning is needed. -
Page 9: Troubleshooting
Cleaning and Care Troubleshooting (cont’d) WARNING: Turn AC OFF and remove plug from outlet prior to cleaning. Before calling service, try these troubleshooting tips. Front Grill Removal: Problem Possible Cause Remedy Wall plug is loose or Confirm that plug is firmly 1. - Page 10 Troubleshooting (cont’d) Problem Possible Cause Remedy Air filter may be dirty. Clean filter. Refer to Cleaning and Care section. AC is cooling but room Temperature on unit Increase temperature. is still warm. is too warm. Air flow is restricted. Remove any obstacles (drapes, furniture, etc.) from in front of unit.
- Page 11 Please send returns to: Within this warranty period, Montgomery Ward will repair or replace, at its option, defective parts of this Montgomery Ward, Inc. product at no charge, provided the product is returned, Attn: Customer Returns freight prepaid with proof of purchase to Montgomery Ward.
