Ingersoll-Rand BRITON 2003V.SES Installation Procedure

SIZE 1-4 ADJUSTABLE BACKCHECK CLOSER
PULL SIDE - REGULAR APPLICATION ( FIG. 1 )
ANGLE OF OPENING 180° SUBJECT TO HINGE & SURROUNDING STRUCTURE
R.H. DOOR
2
FIT MAIN ARM ASSEMBLY TO MECHANISM (90°)
3
4
OPEN DOOR TO ENGAGE SECONDARY ARM STRIP AND TUBE
5
CLOSE DOOR AND SET SECONDARY ARM AT 90° TO DOOR FACE
SECURELY TIGHTEN CLAMP BOLT WITH SPANNER
LATCH
3 2
1
2
DOOR SPEED
1
C
A
B
C
PEEL TEMPLATES OFF BACKING PAPER
POSITION ON DOOR/FRAME
1
PILOT DRILL 7 HOLES
FIT BACKPLATE (3 SCREWS)
FIT BRACKET ASSEMBLY (2 SCREWS)
PEEL OFF TEMPLATES
90° 90°
SECURELY TIGHTEN FIXING SCREW
LOCATE MECHANISM ASSEMBLY ON
BACKPLATE AND SECURE (2 SCREWS)
90° 90°
BACKCHECK
3
IF NECESSARY ADJUST
6
POWER AND DOOR SPEEDS
C
STANDARD OPTIONAL
COVER COVERS
FIT COVER TO CLOSER
7
FOLLOWING STEPS SHOWN
(2 SCREWS)
L.H. DOOR
1
2
3
4
5
POWER ( FIG.1 )
4mm
FACTORY SET TO SIZE 3
NUMBER
CLOSER
OF TURNS
POWER SIZE
(APPROX)
1 -6
2 -3
3 0
6
4 +5
A
B
7
C
WARNING
DOOR CLOSER POWER #1 & 2 AND THOSE SUPPLIED
WITH MECHANICAL HOLD OPEN DEVICES MUST NOT BE
INSTALLED ON FIRE / SMOKE DOORS.
CLOSER
POWER
DOOR
SIZE
#1
20kg
750
MAX
#2
40kg
850
MAX
#3
60kg
950
MAX
#4
80kg
1100
MAX
2110/103/00
ISSUE A
