- Page 1 Quantum Tool Recognition User manual...
-
Page 2: Table Of Contents
Quantum - Tool recognition Content Content Introduction General Support Approved areas of use Environment Technical Description System overview Main parts Technical data TRM Technical data HUB Funktion Start using Quantum ToolRec Start the Quantum hub Quantum App Service Maintenance Maintenance schedule... -
Page 3: Introduction
Introduction Introduction General Quantum Tool Recognition is a system for wireless toolrecognition on excavators. This is the only usage intended for this product. All other usages of this machine, without written permission from SVAB, are strictly prohibited. This document gives instructions how to do installation work on a Quantum Tool Recognition system. -
Page 4: Support
- Tool recognition on excavator - Provide input signal to compatible systems Quantum shall only be used for approved areas of use and functions as mentioned above. SVAB will not take part in injuries or accidents that occurs due to unauthorized use. -
Page 5: Environment
Quantum - Tool Recognition Introduction Environment As part of our environmental commitment, we strive for our products to have as little environmental impact as possible throughout the lifecycle. This means there are things to consider during the installation. • All assembly / disassembly must be done according to national requirements and local regulations. -
Page 6: Technical Description
Benämning P-0000963 Quantum hub P-0000966 P-0001345 Cable supply Quantum Hub P-0001346 Cable Quick coupler signal Quantum Hub P-0000585 Connecting cable Digging system P-0000723 M12 Connector male, straight 5 - pole Quantum App (Google Play/App store) 200586 Jumper cable M8, 0,3 m... -
Page 7: Main Parts
Quantum - Tool Recognition Technical Description Main parts Quantum hub The hub consists of following main parts: 000503 CAN1 / 8-36 VDC CAN2 Diodes Name plate TRM (tool Recognition Module) The TRM consists of following main parts: Screw Cover Seal... -
Page 8: Technical Data Trm
Quantum - Tool Recognition Technical Description Technical data TRM 84 mm Dimensions System Unit Remark Mass Material PC/PBT Operating temp - 40 + 70 Storage temp - 40 + 85 Voltage feed Battery time år Up to 5 years, depending on degree of... -
Page 9: Technical Data Hub
Quantum - Tool Recognition Technical Description Technical data HUB System Enhet Kommentar Vikt Material Driftstemp - 20 + 70 Förvaringstemp - 20 + 85 Spänningsmatn 12/24 CAN motstånd Software selectable 120 Ω, 600 Ω, not terminated IP-klassning IP50 Bluetooth Description... -
Page 10: Funktion
The information about the position of a tool or machine is also shared by other users who have a Bluetooth connection with any Quantum HUB or TRM device. It is enough for someone who has the Quantum app installed on their smartphone to pass a HUB or TRM and get connected via Bluetooth to update the location in the cloud. -
Page 11: Start Using Quantum Toolrec
Quantum starts when the machines electronics is activated by the ignition. Start the Quantum hub Power up the machine Quantum hub will start and the diodes will start to flash. The LEDs are called (from the left): LED 1, LED 2, LED 3, LED 4. LED 1 (Heartbeat), LED 2(TOOLREC-searching), LED 3 (quickcoupler), LED 4 (TOOLREC-status) Check that LED 1 is flashing green. -
Page 12: Quantum App
Quantum App Registration of users, machines and tools Register an user Download the SVAB Quantum app from App Store or Google Play. Start by creating a new user. Enter user information and password. Click ”Next”. You need to accept the licence agreeent in order to get to the next step in the registration. - Page 13 Quantum - Tool Recognition Start using Quantum ToolRec Add a pre-registred machine Go to ”Machines” to register a new machine. Please note that the machine must be running in order for the system to function Press the + sign to scan for and register machines.
- Page 14 Quantum - Tool Recognition Start using Quantum ToolRec Register a new machine If the machine hasn’t been registered before, it needs to registered from start. Go to ”Machines” to register a new machine Please note that the machine must be running in order for the system to...
- Page 15 Quantum - Tool Recognition Start using Quantum ToolRec To edit given information, press ”Edit”. From here, you can change name or add or change a picture if desired . Press ”Save” when you are done. The tool will be added to your list.
- Page 16 Connect a tool Start the machine. Activate quick coupler and lock to a tool. Quantum Toolrec will now start to scan for and connect to the tool in the app. You can verify that the tool is connected to your machine under ”Working tools”.
- Page 17 Quantum - Tool Recognition Start using Quantum ToolRec Change tools Activate the quick coupler and release the tool. Lock on to the new tool. Qunatum ToolRec will start a new scan and connects to the tool. Sida 18 Doc-0001374, Rev B...
- Page 18 Quantum - Tool Recognition Start using Quantum ToolRec Under ”Map” the position of each machine and tool is shown. Sida 19 Doc-0001374, Rev B...
-
Page 19: Service
Quantum - Tool Recognition Start using Quantum ToolRec Service Under ”Service” you can enter service intervals and measures for your machine or for your tool. These will end up under ”Notifications” when it’s time to perform a measure. You can also see the operating time for your machine or tool. -
Page 20: Maintenance
Quantum - Tool Recognition Maintenance Maintenance Maintenance sche- dule Description Maintenance Interval Remark REplace battery 5 yrs Replace cover When necessary Replace TRM When necessary Maintenance instructions Prepartions before maintenance Make sure that the machine is turned off and the excavator boom is lowered. - Page 21 Remove the seal between the cover and lower part. Replace battery in the unit. Make sure to only use original batteries from SVAB. The unit willnot work with ordinary 1.5 V batteries. Install new seal [1] between cover and lower part.
- Page 22 Quantum - Tool Recognition Maintenance Replace TRM The TRM-module should be mounted on the tool in room temperature for best result. The temperature may not go under - 10 grader C. The module is delivered with the battery, sealing and screws on the side.
-
Page 23: Recommended Spare Parts
Quantum - Tool Recognition Maintenance Recommended spare parts Part Description P-0001366 P-0000967 Battery kit Recycling Replaced parts are recycled according to local laws and regulations or are returned to SVAB. Sida 24 Doc-0001374, Rev B...
