M650 Multifunction SCADA Meter
User Manual
September 27, 2017
ML0035 Document Revision O
© 2017 by Bitronics, LLC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Bitronics 50 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Novatech Bitronics 50 Series

Summary of Contents for Novatech Bitronics 50 Series

  • Page 1 M650 Multifunction SCADA Meter User Manual September 27, 2017 ML0035 Document Revision O © 2017 by Bitronics, LLC...
  • Page 2 ML0035 September 22, 2017 Copyright 2017 Bitronics, LLC...

  • Page 3: Table Of Contents

    TABLE OF CONTENTS   50 SERIES MANUAL SET ..........................6   VERSION HISTORY (ABRIDGED) ........................ 6   CERTIFICATION............................. 7   INSTALLATION AND MAINTENANCE ......................7   WARRANTY AND ASSISTANCE ........................7   AUTHORIZED REPRESENTATIVE IN THE EUROPEAN UNION ..............8  ...
  • Page 4   4.0 OPERATION ............................36 4.1 Display ..............................36   4.1.1 Overview – Buttons Functions ......................48   4.1.2 Keypad Functions for Display Mode ....................49   4.1.3 Display Error Messages ......................... 50   4.2 Serial Port ............................. 51   4.2.1 RS485 Connections ........................
  • Page 5 A2 Ethernet Troubleshooting ........................99   A3 Display Screens – Visual Representations ..................100   ML0035 September 22, 2017 Copyright 2017 Bitronics, LLC...

  • Page 6: Series Manual Set

    50 SERIES MANUAL SET ML0035 M650 Family User Manual ML0036 50 Series DNP3 Protocol ML0037 50 Series Modbus Protocol ML0038 M350 Family User Manual ML0039 M651 Family User Manual ML0040 M653 Family User Manual VERSION HISTORY (ABRIDGED) V1.010 2010-03-25 M650M3x51x models with firmware download capability V1.030 2010-05-14 Add 0-1mA, add per-phase power demands to protocols V1.040...

  • Page 7: Certification

    CERTIFICATION Bitronics LLC certifies that the calibration of our products is based on measurements using equipment whose calibration is traceable to the United States National Institute of Standards Technology (NIST). INSTALLATION AND MAINTENANCE Bitronics LLC products are designed for ease of installation and maintenance. As with any product of this nature, installation and maintenance can present electrical hazards and should be performed only by properly trained and qualified personnel.

  • Page 8: Authorized Representative In The European Union

    AUTHORIZED REPRESENTATIVE IN THE EUROPEAN UNION NovaTech Europe BVBA Kontichsesteenweg 71 2630 Aartselaar Belgium T +32.3.458.0807 F +32.3.458.1817 info.europe@novatechweb.com COPYRIGHT NOTICE This manual is copyrighted and all rights are reserved. The distribution and sale of this manual is intended for the use of the original purchaser or his agents. This...

  • Page 9: Safety Section

    SAFETY SECTION This Safety Section should be read before commencing any work on the equipment. Health and safety The information in the Safety Section of the product documentation is intended to ensure that products are properly installed and handled in order to maintain them in a safe condition.
  • Page 10 If there is unlocked access to the equipment, care should be taken by all personnel to avoid electric shock or energy hazards. Voltage and current connections should be made using insulated crimp terminations to ensure that terminal block insulation requirements are maintained for safety. To ensure that wires are correctly terminated, the correct crimp terminal and tool for the wire size should be used.

  • Page 11: Warning: Emissions - Class A Device (En55011)

    Fiber optic communication Where fiber optic communication devices are fitted, these should not be viewed directly. Optical power meters should be used to determine the operation or signal level of the device. WARNING: EMISSIONS – CLASS A DEVICE (EN55011) This is a Class A industrial device. Operation of this device in a residential area may cause harmful interference, which may require the user to take adequate measures.

  • Page 13: Description & Specifications

    1.0 DESCRIPTION & SPECIFICATIONS 1.1 Introduction The M650 family of multifunction SCADA meters provides a range of measurement and communications capabilities for 3-phase metering. They offer an outstanding display, superior communications flexibility and easy setup. The following Model M650 Multifunction Meter types are covered in this manual: B3 - Multifunction Standard, alphanumeric 3-Phase M3 - Multifunction Advanced, alphanumeric 3-Phase 1.2 Features...
  • Page 14 Input Signals – Measurement Inputs Configuration All Input Options 3 Inputs. 3 Phase Currents (IA, IB, IC). Current Nominal Input Option 1 1A ac Inputs Input Option 5 5A ac Input Option C 5A ac with split-core CTs Range Input Option 1 0 to 2A rms continuous at all rated temperatures Input Option 5 0 to 10A rms continuous at all rated temperatures...
  • Page 15 Input Signals – Measurement Inputs Voltage 2.5kV rms 1min, input-to-case (ground) Withstand 2kV rms 1min, input-to-input Frequency 45-65 Hz Sampling System Sample Rate 64 samples per cycle Data Update Rate Amps, Volts Available every 100 ms Watts, VAs, VARs, Available every 100 ms Number of Bits ML0035 September 27, 2017...
  • Page 16 Accuracy Accuracies are specified at nominal Frequency and 25C, (unless otherwise noted). Unless noted, all values are true RMS and include Harmonics to the 31st (minimum). Voltage AC: Better than 0.1% of reading (20 to 150 V rms, input-to-case). (+/- 25ppm/DegC) Voltage Aux Only included with...
  • Page 17 Environmental Operating Temperature -40C to 70C Relative Humidity 0-95% non-condensing Measurement Inputs CAT III (Distribution Level) Refer to definitions below. (VTs, CTs) Installation/Measurement Category Pollution Degree Pollution Degree 2 Refer to definitions below. Enclosure Protection Front Panel: IP 20, Rear: IP 20 (to IEC60529: 2001) When equipment is mounted in an appropriately rated protective enclosure to NEMA or IP protection classifications, as required for the installation.
  • Page 18 Physical Connections Protective 10-32 Studs for connection with protective earth ground. Recommended Torque: 12 In-Lbs, Conductor 1.36 N-m Terminal Cable temperature rating: 85C minimum Current Internal Isolation - Current Input Option 1 or 5. 10-32 Studs for current inputs. Recommended (CT) Torque: 12 In-Lbs, 1.36 N-m Cable temperature rating: 85C minimum...

  • Page 19: Standards And Certifications

    Definitions: Enclosure Category 2: Enclosures where no pressure difference relative to the surrounding air is present. Installation Category II (Overvoltage Category II) or CAT II: Equipment is intended for connection to the fixed installation of a building. The power supply to the electronic equipment is separated from other circuits, usually by a dedicated transformer for the mains power supply.
  • Page 20 UL61010-2-30, Edition 1 – Issue Date 2012/05/11 Safety Requirements for Electrical Equipment for Measurement, Control, and Laboratory Use – Part 2: Particular Requirements for Testing and Measuring Circuits CSA C22.2 No. 61010-1-12-CAN/CSA, Edition 3, Issue Date 2012/05/01 CAN/CSA Safety Requirements for Electrical Equipment for Measurement, Control, and Laboratory Use –...
  • Page 21 EN 55011: 2016 EN 61000-6-4: 2007 + A1:2011 (IEC date 2010 Group 1, Class A Frequency: 150 kHz – 30 MHz Conducted Emissions, Telecommunication port (Ethernet port) EN 55022: 2010 + AC: 2011 EN 55032: 2012 + AC: 2013 EN 55032: 2015 + AC: 2016-07 Group 1, Class A Frequency: 150 kHz –...
  • Page 22 EN 61000-4-8: 2010 Amplitude: 30A/m Frequency: 50 and 60 Hz AC Supply Voltage Dips and Short Interruptions EN 61000-4-11: 2004 Surge Withstand Capability Test For Protective Relays and Relay Systems ANSI/IEEE C37.90.1: 2002 (2.5 kV oscillatory wave and 4 kV EFT) ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...

  • Page 23: Physical Construction & Mounting

    2.0 PHYSICAL CONSTRUCTION & MOUNTING The M650 meters are packaged in rugged aluminum case specifically designed to meet the harsh conditions found in utility and industrial applications. The Front panel view is shown in Figure 1. The mechanical dimensions are shown in Figure 2.
  • Page 24 Figure 2 - Mounting and Overall Dimensions M650 (back panel may vary as a result of options ordered) ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...

  • Page 25: Installation

    2.1 Installation WARNING - INSTALLATION AND MAINTENANCE SHOULD ONLY BE PERFORMED BY PROPERLY TRAINED OR QUALIFIED PERSONNEL. 2.2 Initial Inspection Bitronics instruments are carefully checked and "burned in" at the factory before shipment. Damage can occur however, so please check the instrument for shipping damage as it is unpacked.

  • Page 26: Cleaning

    Several instruments may be mounted on a 19" Rack panel if desired. Three units will fit side by side on a standard 5.25" high panel. Figure 2 indicates the dimensions of the panel hole cutout. Leave adequate space surrounding the instrument when determining mounting arrangements.

  • Page 27: Back Panel & Wiring

    3.0 BACK PANEL & WIRING The rear views of the M650 are shown in figures 3A and 3B with the option port shown (removable terminal block at the top), which may be selected at order time, as either, the serial communication option, the 0-1mA analog transducer output option, or the 4- 20mA analog transducer output option.

  • Page 28: Auxiliary Power

    Figure 3B – Rear View M650 (shown with 6 position terminal block for External Split-Core CTs – Current Input Option C) 3.1 Auxiliary Power The M650 meters are powered by connections to L1(+) and L2(-). A Blue LED Power (PWR) indicator is provided on the rear panel to indicate that the unit is powered ON. It is located on the right of the rear panel.

  • Page 29: Specifications (Per Section 1.3)

    Refer to the order guide to verify whether the meter is made with this monitoring option. ‘V Aux’ will appear on the display as a measurement for meters equipped with this monitoring option. 3.1.1 Specifications (per section 1.3) Power Supply Input (Auxiliary) Voltage – terminals L1(+) and L2(-) Nominal: 48-250V dc, 69-240V ac (50/60Hz) Operating Range:...

  • Page 30: Serial Ports (See Section 4.2)

    driver. 12 inch-pounds (1.36 N-m) is recommended, MAXIMUM torque is 15 inch- pounds (1.69 N-m). Current inputs, option 5: 5 Amp input with internal current isolation transformer, constructed with 10-32 studs as the current terminals. (See Figure 3A for the physical construction shown for the current terminals).

  • Page 31: Network Settings

    full-duplex). If needed, adapters are available to convert the LC to ST connectors, the same that are used in the Bitronics 70 Series. 3.5.1 Network settings The M650 meters come preconfigured for interconnection to an HTML web server with default settings for IP address, SUBNET mask, and ROUTER (GATEWAY) address. Network Default (Preconfigured) Settings IP Address Subnet mask...
  • Page 32 The M650 uses the following port numbers for each type of protocol: Protocol Port Number DNP3 20000 (TCP, UDP) HTML 80 (TCP) Modbus 502 (TCP) Determining the IP Address if unknown: Although the IP address can be obtained via the display, for versions that don’t have a display (M651, M661, PPX II), Bitronics has created a utility program to request the IP address for a specific MAC address on an Ethernet network.

  • Page 33: Indicators - Ethernet (Act) & Serial Leds

    to poll the 1st IPv4 interface, inarp -v 50series CTRL-C stops the scan to poll the IPv4 interface associated with 192.168.1.1, use inarp -v -i 192.168.1.1 50series or to poll a specific mac, use inarp -v -i 192.168.1.1 00:D0:4F:03:00:15 The inarp utility is Copyright (c) 2011 by Bitronics, LLC. All rights reserved. Portions of inarp are Copyright (c) 1999 - 2005 NetGroup, Politecnico di Torino (Italy), and Copyright (c) 2005 - 2010 CACE Technologies, Davis (California)
  • Page 34 Choose File button and use the File Open dialog window to select the configuration file you just saved. Click the Submit button. If the “Configuration upload success” message appears, the configuration file is confirmed to have saved correctly. Once the configuration file is saved to your computer, or even if you don’t need to save the configuration, you should restore the meter to the factory defaults.
  • Page 35 cache. A useful keyboard shortcut common to Internet Explorer, Firefox and Chrome is CONTROL + SHIFT + DELETE, which will take you directly to the relevant dialog panel. Carefully select the items to be cleared. Be sure to check the boxes that clear “temporary internet files”, “cache”...

  • Page 36: Operation

    4.0 OPERATION 4.1 Display The M650 meters can display several per-phase and total quantities for the circuit being monitored. In order to make all quantities available, the display scrolls from quantity to quantity approximately every 5 seconds. The quantities are refreshed once a second.
  • Page 37 INSTANTANEOUS DISPLAY SCREENS Format Quantity 00000 Phase A Amperes 00000 Phase B Amperes 00000 Phase C Amperes AmpsΦ 00000 Residual Amperes  Unused  Unused AmpsR 00000 Phase A Volts 00000 Phase B Volts 00000 Phase C Volts xVolts 00000 Phase A-B Volts 00000 Phase B-C Volts...
  • Page 38 00000 Phase A VAs 00000 Phase B VAs 00000 Phase C VAs xVA Φ 00000 Phase A PF 00000 Phase B PF 00000 Phase C PF PF Φ 10. 00000 Total VAs 00000 3Φ PF  Unused xVAsPF 11. 00.000 Frequency ...
  • Page 39 16. 000.00 VA hours (Most significant half) 000.00 VA hours (Least significant half)  Unused kVAh 17. 00000 Watt hours Net (Most significant half) 00000 Watt hours Net (Least significant half) Unused  kWh NET 18. 00000 Total Watts 00000 3Φ...
  • Page 40 DEMAND DISPLAY SCREENS Format Quantity 19. 000.00 Phase A Amps Demand 000.00 Phase B Amps Demand 000.00 Phase C Amps Demand Amps Dmd 20. 00000 Phase A Maximum Amperes Demand 00000 Phase B Maximum Amperes Demand 00000 Phase C Maximum Amperes Demand Amps MAX 21.
  • Page 41 27. 00000 Phase A-B Minimum Volts Demand 00000 Phase B-C Minimum Volts Demand 00000 Phase C-A Minimum Volts Demand xV MIN 28. 00000 Total Maximum Watt Demand 00000 Total Watts (Also on Screen 7) 00000 Total Minimum Watt Demand xW     29.
  • Page 42 HARMONIC SUMMARY DISPLAY SCREENS Format Quantity 31. 00000 Phase A Fundamental Amperes 00000 Phase B Fundamental Amperes 00000 Phase C Fundamental Amperes Fnd Amps 32. 00000 Fundamental Residual Amperes  Unused  Unused FndN  Amps 33. 00000 Phase A Fundamental Volts 00000 Phase B Fundamental Volts 00000...
  • Page 43 38. 00.000 K-Factor Phase A (Current) 00.000 K-Factor Phase B (Current) 00.000 K-Factor Phase C (Current) K-Factor - WYE meters only x - indicates blank, (k)ilo, (M)ega, or (G)iga ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 44 HARMONIC SUMMARY DISPLAY SCREENS (Cont’d) Format Quantity 39. 0.0000 Phase A Displacement PF 0.0000 Phase B Displacement PF 0.0000 Phase C Displacement PF DispPF Φ 40. 00000 3Φ Displacement PF  Unused  Unused DispPF T 41. 000.00 Phase A Fundamental Demand Amps 000.00 Phase B Fundamental Demand Amps 000.00...
  • Page 45 46. 000.00 Phase A Minimum Average Watts 000.00 Phase B Minimum Average Watts 000.00 Phase C Minimum Average Watts xW Min 47. 000.00 Phase A Average VARs 000.00 Phase B Average VARs 000.00 Phase C Average VARs xVAR Avg 48. 000.00 Phase A Maximum Average VARs 000.00 Phase B Maximum Average VARs...
  • Page 46 SecVolts 54. 00000 Phase A-B Secondary Volts 00000 Phase B-C Secondary Volts 00000 Phase C-A Secondary Volts SecVolts 55. 000.00 Auxiliary Voltage  Unused  Unused V aux - Screen available on WYE meters only x - indicates blank, (k)ilo, (M)ega, or (G)iga ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 47 The screens that are displayed in the scrolling mode can be programmed (ENABLED/DISABLED) by the user. This programming can be done by using the front panel buttons of the device or through the web server. Enable/Disable Display Mode Screens via the front buttons on Display: The Screens can be enabled or disabled (refer to Section 5.5) via the front display buttons by entering the setup mode section and going to the Screen Enable menu (1.6, Scrn Ena).

  • Page 48: Overview - Buttons Functions

    4.1.1 Overview – Buttons Functions Figure 5 – Button functions for Display Mode Figure 6 – Button functions in Set-up Mode ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...

  • Page 49: Keypad Functions For Display Mode

    4.1.2 Keypad Functions for Display Mode Measurements screens may be stepped through manually by pushing the up and down arrow keys. Pushing the Toggle (Exit) key turns the scroll function off and on. When the scroll function is activated, the measurement screens will automatically step through the user- defined screens.

  • Page 50: Display Error Messages

    Button Display Mode Function Setup Mode Function Combination Home Designate the displayed (Enter) and Toggle screen as “Home Screen” (Exit) keys Resets are found in setup menu 4.1.3 Display Error Messages Error messages from self test are shown on the display. The table below summarizes the errors and the messages displayed: SELF TEST RESULT SUMMARY FOR 50 SERIES DEVICES Fault...

  • Page 51: Serial Port

    4.2 Serial Port This port when ordered can be set to RS-232 or RS-485, and support baud rates up to 115200. Set-up of the Serial Port can be accomplished by using a web browser connected to the Ethernet port, or via the front display buttons (Setup menu - Serial).
  • Page 52 Figure 7 - Typical RS-485 Cable Wiring ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 53 Figure 8 – RS-232 Cable Wiring Diagram ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...

  • Page 54: Functional Description

    5.0 FUNCTIONAL DESCRIPTION 5.1 Configuration Setup of the M650 meters is most easily performed using the web interface via the Ethernet service port. Basic configuration can also be handled from the front display by entering the setup mode. 5.2 HTML Web Server The M650 incorporates an internet-compatible HTML web page.

  • Page 55: Using The M650 With A Bitronics Analog Output Converter

    A user has five attempts to enter the correct password. If unsuccessful, the unit will be locked out for 5 minutes before another attempt can be made. 5.4 Using the M650 with a Bitronics Analog Output Converter The M650 may be used with any of the Bitronics AOC units (NAO8101, NAO8102, NAO8103, or NAO8104).

  • Page 56: Navigating The M650'S Setup Menu From The Front Panel

    5.5 Navigating the M650’s setup menu from the front panel ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 57 SCRN ENA  [Amps Φ]  Amps A, B C  Amps R]  Amps Reidual  [kVolts Φ]  Volts AN, BN, CN  [kVolts]  Volts AB, BC, C  [Watts Φ]  WattsA, B,C  [kVARΦ]  VARs A, B, C  [kW∙kVAR]  Total Watts∙ Total VARs  [kVAΦ]  VAs A, B, C  [PFΦ]  Power Factor A, , C  [kVA∙PF]  Total VAs ∙ 3Φ PF  [Hz]  Frequeny  [kWh]  kWatt‐Hour Normal(+)  [‐kWh]  kWatt‐Hours Reverse(‐)  [+kVARh]  kVAR‐Hous Laggin(+)  [‐kARh]  kVA‐Hours Leading(‐)  [kVAh]  kVA‐Hours  [kWhNE]  kWatt‐Hours Net  [kW∙PF∙Hz]  Total Watts ∙ 3Φ PF ∙ Frequency  [AmpsDmd]  Demand Amps A,B,C  [AmpsDmd  axDmand Amps A,B,C ...
  • Page 58 ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 59 ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 60 How to Enter an Integer:  Increment highlighted digit by 1.    ENTER  Highlight Previous/Next digit.     Exit to menu  EXIT      How to Enter a Floating Point Number:  Increment highlighted digit by 1.    ENTER  Shifts decimal point one place to right. Decimal moves to  left‐most digit when right‐most digit is passed.    Highlight Next digit. Highlights left‐most digit when right‐ most digit is passed.    Exit to menu  EXIT     How to Enter an IP address:  Increment highlighted digit by 1.    ENTER  Highlight Previous/Next digit. Numbers scroll left  and right to follow highlighted digit.    Exit to Network menu  EXIT    - 60 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...

  • Page 61: Performing Set-Up Through The Web

    5.6 Performing set-up through the web page interface This section will assume you are able to use the factory default IP address of 192.168.0.171 to connect to the web page using an HTML web server. If this is not the case you may need to refer to section 3.5.1 (Network settings) and the previous section (Navigating the M650’s setup menu from the Front panel) to change your network configuration settings.
  • Page 62 Data page: Two views – Instantaneous and Demands - 62 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 63 Resets page: From this page select the quantity to be reset and click apply. Optionally, Energy values can be reset to specific non-zero values by entering the desired reset value in the appropriate field as a whole number and clicking Apply. Any fields that are left blank will be reset to zero.
  • Page 64 Contact Page: - 64 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 65 Settings Page Selections: From the Settings page screen you can select one of the following selections: Identity– This page allows the user to enter information that is necessary to identify the meter. It gives an identity to a particular M650. Each M650 should have different information entered for its identity.
  • Page 66 Identity: - 66 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 67 Input: - 67 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 68 Network: Serial Port (if option ordered): - 68 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 69 Analog Output (if option ordered): Protocol Selection (if Option ordered): First select between Modbus or DNP3. You will then select Optimal Resolution (default) or Primary Units. Next you will choose a session. Under Type, there will be 4 different selections for Modbus and 3 for DNP3. Under Modbus the options are Disabled, TCP, ASCII, or RTU.
  • Page 70 Modbus DNP3 - 70 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 71 DNP Serial DNP TCP - 71 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 72 Modbus RTU - 72 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 73 Modbus TCP - 73 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 74 Screen Enable: - 74 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 75 Custom Display Screen Settings: Two Sections – Build/Edit and Summary The Custom Display Screen Configuration page contains two sections: the Build/Edit panel and the Summary panel. One custom display screen is built at a time in the Build/Edit panel and is then added to the Summary panel, which presents a list of all the custom screens that have been built.
  • Page 76 The order of the screens can be changed by selecting a screen from the list and clicking on the up or down arrows. Load/Store Device Settings: - 76 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 77 Password Security Settings: Firmware Upload: - 77 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...

  • Page 78: Measurements

    6.0 MEASUREMENTS Basic measurement quantities are calculated and updated every 100 ms. These quantities include RMS Amperes and RMS Volts, Watts, VARs, VAs, Power Factor, all harmonic-based measurements (such as fundamental-only quantities), Energy, and Frequency, and Phase Angle. Note: For all of the following measurements, it is important to keep in mind that the specific protocol used to access the data may affect the data that is available, or the format of that data.

  • Page 79: Voltage Channels

    6.3 Voltage Channels All voltage inputs are measured relative to a common reference level (essentially panel ground). See Appendix 1 for input connection information. Common mode signals can be removed by signal processing algorithms, instead of the more traditional difference amplifier approach. This greatly simplifies the external analog circuitry, increases the accuracy, and allows measurement of the Neutral-to-Ground voltage at the panel.

  • Page 80: Geometric Va Calculations

    true Watts. The per-element VAs are calculated from the product of the per-element Volts and Amps. The per-element VARs are calculated from fundamental VARs. In any connection type, the Total Watts and Total VARs is the arithmetic sum of the per-element Watts and VARs.
  • Page 81 Figure 9 - Sign Conventions for Power Measurements (P is Power, Q is VARS and S is VA) - 81 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...

  • Page 82: Compensated Watts And Vars (Line And Transformer Loss Compensation)

    6.7 Compensated Watts and VARs (Line and Transformer Loss Compensation) The total Watt and Var losses can be calculated using five user entered parameters and measured current and voltage values. These losses are added or subtracted to/from the measured Total Watts and Total Vars when accumulating Energy.   ...

  • Page 83: Energy

    B, C, and D. Users who do not intend to use system losses should simply set E equal to zero. A detailed application note on loss compensation in the 50 Series can be found in the documentation library of the Novatech website, www.novatechweb.com. 6.8 Energy Separate values are maintained for both positive and negative Watt-hours, positive and negative VAR-hours, and VA-hours, for each feeder.

  • Page 84: Frequency

    6.9 Frequency The M650 monitors the change in Phase Angle per unit time using the Phase Angle measurement for the fundamental generated by the FFT. The System Frequency is the frequency of the input used for synchronizing the sampling rate. 6.10 Demand Measurements The traditional thermal demand meter displays a value that represents the logarithmic response of a heating element in the instrument driven by the applied signal.

  • Page 85: Ampere And Fundamental Ampere Demand

    Demand Quantity Phase Reference Function Total VARs (A, B, C, Total) Phase, Total Present, Max, Min Total VAs (A, B, C, Total) Phase, Total Present, Max, Min 6.10.1 Ampere and Fundamental Ampere Demand Present Ampere Demands are calculated via the instantaneous measurement data used to calculate the per-phase Amperes.

  • Page 86: Demand Resets

    are set equal to the Present Total Watt, VAR, and VA Demand values. A demand reset does not change the value of the Present Total Watt, VAR, and VA Demands. 6.10.4 Demand Resets The demand values are reset in 3 groups: current, voltage, and power. This can be accomplished via the front display or from a web browser.

  • Page 87: Fundamental Current

    Alternatively, Current Harmonic Distortion can be  measured as Demand Distortion, as defined by IEEE-519/519A. Demand Distortion differs from    traditional Harmonic Distortion in that the denominator of the distortion equation is a fixed value. This fixed Equation 3 - Current TDD denominator value is defined as the average monthly peak demand.

  • Page 88: Fundamental Voltage

    6.11.4 Fundamental Voltage Fundamental Volts are the nominal component (50/60Hz) of the waveform. The M650 measures the magnitude of the fundamental phase-to-neutral and phase-to-phase volts. These measurements can be used in conjunction with the distortion measurements to obtain the magnitudes of harmonics, in other words, convert from percent to volts.

  • Page 89: Phase Angles

    6.11.7 Phase Angles The M65x measures the Fundamental Phase Angles for all Currents, Line-to-Neutral Voltages, and Line-to-Line Voltages. The Phase Angles are in degrees, and all are referenced to the V Voltage, which places all Phase Angles in a common reference system.

  • Page 90: List Of Available Measurements & Settings

    6.13 List of Available Measurements & Settings Please note that not all measurements are available in every M65x model (demand and harmonic values only in M3). Available Measurements Amps A, B, C, Residual Heartbeat Average 3-phase Amps K-factor Amps A Average 3-Phase Volts (L-L, L-N) K-factor Amps B Average Volts AN, BN, CN, AB, BC, CA...

  • Page 91: Instantaneous Measurement Principles

    6.15 Instantaneous Measurement Principles The M650 measures all signals at an effective rate of 64 samples/cycle, accommodating fundamental signal frequencies from 45 to 65Hz depending on model. Samples of all bus signals are taken using a 16-Bit A/D converter, effectively creating 64 "snapshots"...

  • Page 92: Analog Transducer Output Option

    7.0 ANALOG TRANSDUCER OUTPUT OPTION 7.1 Introduction The Transducer Output options (0 -1 mA or 4-20 mA) feature 3 separate outputs each with two terminals, one of which is common to all three outputs and one which provides a unique return path for each output. 7.2 Specifications Outputs: 3 bi-directional,...
  • Page 93 Figure 10 – 0-1mA Transducer Output Connections - 93 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 94 Figure 11 – 4-20mA Transducer Output Connections - 94 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...

  • Page 95: Appendix

    APPENDIX A1 CT/VT Connection Diagrams Please note that there is an option on the Settings/Input page to invert the CT Polarity (see screen shot clip below). This option is the equivalent of swapping the connections in the connection diagrams below at the HI and LO terminals for each CT input, that is, swapping 7 and 10, 8 and 11, 9 and 12.
  • Page 96 Figure 12 - Signal Connections – M650 - 96 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 97 Figure 12 - Signal Connections – M650 - 97 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 98 Figure 13 - 50 Series External Split-Core Signal Connections - 98 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 99 A2 Ethernet Troubleshooting If the Link LED fails to illuminate, this is an indication that there is trouble with the connection and communication will not proceed without solving the problem. If a copper connection is used between the M650 and the hub/switch, check the following items: Verify that the connectors are fully engaged on each end.
  • Page 100 A3 Display Screens – Visual Representations - 100 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 101 - 101 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 102 - 102 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 103 - 103 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 104 - 104 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 105 - 105 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 106 - 106 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 107 - 107 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 108 - 108 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 109 - 109 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 110 - 110 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 111 - 111 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 112 - 112 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 113 - 113 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 114 - 114 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 115 Revision Date Changes 3/15/2010 Original Issue E. DeMicco 4/15/2010 New web screen shots, fiber Ethernet E. DeMicco option, corrections 6/21/2010 Manual references, transducer output, E. DeMicco new setup map, configurable display setup, demand screen in data view 2/24/2011 Secondary volts screens, default and E.
  • Page 116 5/8/14 Added new Declaration of Conformity E. DeMicco document; updated firmware information Added information on password attempts and lockout. 3/24/16 Added information on password E. DeMicco attempts/lockouts; updated Declaration of Conformance with addition of D650 display 12/24/16 Updated firmware revision history: added E.
  • Page 117 - 117 - ML0035 September 27, 2017 Copyright 2017 Bitronics, LLC...
  • Page 118 Bitronics, LLC 261 Brodhead Road,Bethlehem, PA. 18017 (610) 997-5100 Fax (610) 997-5450 www.novatechweb.com /bitronics...
