Veriton 9100

Service Guide
Service guide files and updates are available
on the AIPG/CSD web; for more information,
please refer to
http://csd.acer.com.tw
PART NO.: 49.32K04.001
DOC. NO.: SG360-0102A
PRINTED IN TAIWAN

Advertisement

Table of Contents
loading

Related Manuals for Acer Veriton 9100

Summary of Contents for Acer Veriton 9100

  • Page 1: Veriton 9100

    Veriton 9100 Service Guide Service guide files and updates are available on the AIPG/CSD web; for more information, please refer to http://csd.acer.com.tw PART NO.: 49.32K04.001 DOC. NO.: SG360-0102A PRINTED IN TAIWAN...

  • Page 2: Revision History

    Revision History Please refer to the table below for the updates made on Veriton 9100 service guide. Date 03/13/2001 Chapter 3 Chapter 1 Chapter Revise "Remove the five screws holding the power supply", and add the picture under " Removing the power supply".
  • Page 3 Copyright Copyright © 1999 by Acer Incorporated. All rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language or computer language, in any form or by any means, electronic, mechanical, magnetic, optical, chemical, manual or otherwise, without the prior written permission of Acer Incorporated.
  • Page 4 Conventions The following conventions are used in this manual: Screen messages NOTE WARNING CAUTION IMPORTANT Denotes actual messages that appear on screen. Gives bits and pieces of additional information related to the current topic. Alerts you to any damage that might result from doing or not doing specific actions.
  • Page 5 DIFFERENT part number code to those given in the FRU list of this printed Service Guide. You MUST use the list provided by your regional Acer office to order FRU parts for repair and service of customer machines.

  • Page 7: Table Of Contents

    Disasembling the Veriton 9100 ........
  • Page 8 Jumper Setting ..........66 Chapter 6 FRU (Field Replaceable Unit) List Veriton 9100 Exploded Diagram 69 Appendix A Model Definition and Configuration...
  • Page 9 Table of Contents...

  • Page 10: System Specifications

    System Specifications Overview The Veriton 9100 supports Intel bus. Chapter 1 ® Willamette processor based IBM PC/AT compatible system with PCI/AGP Chapter 1...

  • Page 11: Features

    Features Performance ® Intel Willamette processors, with supporting CPU clock up to 1.5GHz. Two Direct Rambus channel optimized for 400 MHz. Maximum of 512 MB Rambus DRAM within 4 RIMM slots up to 1GB. Integrated LAN Controller (82801BA). 3.5-inch and 5.25-inch floppy disk drives. CD-ROM/DVD-ROM drive High capacity, Enhanced-IDE hard disk Power management features...
  • Page 12 Human-centric design and ergonomics Slim desktop form factor Separate computer stand and rubber stands for quick and easy positioning Space-saver solution Accessible I/O ports Easy-to-open housing design for quick upgrade Chapter 1...

  • Page 13: Front Panel-Veriton 9100

    Front Panel-Veriton 9100 The computer’s front panel consists of the following: Label Icon CD-ROM/DVD-ROM tray Stop/Eject Butto Skip/Forward Button Hard disk drive activity light-emitting diode (LED) System activity LED Power LED Power switch CD-ROM/DVD-ROM LED Volume Tuner CD-ROM/DVD-ROM Headphone/Earphone port 5.25-inch drive bays...
  • Page 14 Label Icon 3.5-inch floppy disk drive Floppy disk drive LED Floppy disk drive eject button Speaker-out/Line-out port Microphone-in port * USB ports * The system has two microphone-in ports (front and rear). However, you can not use both of them at the same time.

  • Page 15: Rear Panel-Veriton 9100

    Rear Panel-Veriton 9100 Label Icon Color Description Power cord socket White Network port Burgundy Parallel/printer port Gold Game/MIDI port CTR/LCD monitor port Power supply Green PS/2 mouse port Purple PS/2 keyboard port Teal or Turquoise Serial port Chapter 1...
  • Page 16 Label Icon Chapter 1 Color Description Black USB ports Lime Audio-out/Line-out jack Light blue Audio-in/Line-in jack Microphone-in port * Expansion slots...

  • Page 17: System Block Diagram

    System Block Diagram 1.5VAGP IDE Primary UltraDMA/33/66/100 IDE Secondary USB 1 USB 2 USB 3 USB 4 AMC’97 STAC9700 423-Pin Socket Processor 100MHz Pentium 4 1064MB/s 100MHz 2RIMM Modules 400MHz 2RIMM 400MHz Modules 66MHz 33MHz PCI CNTRL ICH2 PCI ADDR/DATA 82801BA 82562ET Kinnereth...

  • Page 18: Main Board Layout

    Main Board Layout Power connector Power connector IDE 2 HDD connector Power connector IDE 1 HDD connector FDD connector Fan 3 connector Battery USB 2 connector Buzzer AGP power connecto AGP Pro slot Intel 82801BA chipset Power LED , Reset button connector BIOS chipset ACPI LED connecto IrDA connector...

  • Page 19: Keyboard

    Keyboard The keyboard has full-sized keys that include separate cursor keys, two Windows keys, and twelve function keys. Programmable keys The programmable keys help you directly access a URL (Web site) or launch any program, files, or application in your system. The fifth key is set to launch the media player. If you want to configure the settings of each key right click on the Magic Keyboard icon located on the desktop.

  • Page 20: Multimedia Keys

    Multimedia keys Allow you to play, pause, stop, step forward, or step back a song or movie conveniently using your keyboard. Icons Volume control/Mute The volume control/Mute knob controls the speaker volume. Turn it clockwise or counterclockwise to adjust the volume. Press it to toggle between mute and sound. Cursor keys The cursor keys, also called the arrow keys, let you move the cursor around the screen.

  • Page 21: Windows Keys

    Windows keys The keyboard has two keys that perform Windows-specific functions. Windows logo key Application key Description Start button. Combinations with this key perform special functions, such as: Windows + Tab: Activate the next Taskbar butto Windows + E: Explore My Compute Windows + F: Find Document Windows + M: Minimize All Shift + Windows + M: Undo Minimize All...

  • Page 22: Hardware Specifications And Configurations

    Hardware Specifications and Configurations Processor Item Type Slot Speed Minimum operating speed Voltage BIOS Item BIOS code programmer BIOS version BIOS ROM type BIOS ROM size BIOS ROM package Support protocol Boot from CD-ROM feature Support to LS-120 drive Support to BIOS boot block feature No NOTE: The BIOS can be overwritten/upgraded using the AFLASH utility (AFLASH.EXE).
  • Page 23 This section has two table lists, system memory specification and the possible combinations of memory module. System Memory Item Memory socket numbe Support memory size per socket Support maximum memory size Support memory type Support memory speed Support memory voltage Support memory module package Support to parity check feature Support to Error Correction Code (ECC...
  • Page 24 Audio Interface Item Audio controller Audio controller resident bus Audio function control Mono or stere Resolution Compatibility Music synthesizer Sampling rate MPU-401 UART support Microphone jack Headphone jack Package IDE Interface Item IDE controller IDE controller resident bus Number of IDE channel Support IDE interface Support bootable CD-ROM Floppy disk drive Interface...
  • Page 25 Parallel Port Item Parallel port controller Parallel port controller resident bus Number of parallel ports Support ECP/EPP Connector type Parallel port function control Optional ECP DMA channel (in BIOS Setup) Optional parallel port I/O address (via BIOS Setup) Optional parallel port IRQ (via BIOS Setup) Serial Port Item...
  • Page 26 Memory Address Map Address 000000 - 07FFFF 080000 - 09FFFF 0A0000 - 0BFFFF 0C0000 - 0C7FFF 0C8000 - 0DFFFF 0E0000 - 0EFFFF 0F0000 - 0FFFFF 100000 - UPPER LIMIT UPPER LIMIT - 4GBytes Note : UPPER LIMIT means the maximum size of installed memory. The Main Memory Maximum size are 768M Bytes.
  • Page 27 I/O Address Map Hex Range 000-00F 020-021 040-043 060-060 061-061 070-071 081-08F 0A0-0A1 0C0-0DF 0F0-0FF 170-177 1F0-1F7 278-27F 2F8-2FF 378-37F 3F0-3F5 3F6-3F6 3F7-3F7 3F8-3FF 0CF8 0CFC 778-77A IRQ Assignment Map IRQx IRQ0 Timer IRQ1 Keyboard IRQ2 Cascade Interrupt Control IRQ3 Serial Alternate IRQ4 Serial Primary...
  • Page 28 DRQ Assignment Map DRQx DRQ0 DRQ1 DRQ2 DRQ3 DRQ4 DRQ5 DRQ6 DRQ7 NOTE: N - Not be used. Main Board Major Chips Item North Bridge South Bridge Super I/O controller Audio controller LAN controlle HDD controller Keyboard controller Environmental Requirements Item Temperature Operating...
  • Page 29 Switching Power Supply 300W Input Frequency 47 -63H 47 -63H Input Voltage 100 - 120 VRMS 200 - 240 VRMS Input Current 10A / 9A* 5A / 4.5A* (This is for 300 power supply) NOTE: * 9A & 4.5A are for Model : DPS-300 GB-1D Output Requirements +12V -12V...

  • Page 30: Power Management Functions

    Power Management Functions Device Standby Mode Independent power management timer for hard disk drive devices (0-15 minutes, time step=1 minute). Hard disk drive goes into Standby mode (for ATA standard interface). Disable V-sync to control the VESA DPMS monitor. Resume method: device activated (Keyboard for DOS, keyboard & mouse for Windows). Resume recovery time: 3-5 sec.

  • Page 31: System Utilities

    Chapter 2 System Utilities Most systems are already configured by the manufacturer or the dealer. There is no need to run Setup when starting the computer unless you get a Run Setup message. The Setup program loads configuration values into the battery-backed nonvolatile memory called CMOS RAM. This memory area is not part of the system RAM.

  • Page 32: Entering Setup

    Entering Setup To enter Setup, press the key combination Ctrl-Alt-Esc during the POST (Power-on self-test). NOTE: You must press Ctrl-Alt-Esc simultaneously while the system is booting. The Setup Utility main menu then appears: The above screen is the BIOS Utility Basic Level screen. It allows you to view and change only the basic configuration of your system.

  • Page 33: Product Information

    Product Information The screen below appears if you select Product Information from the main menu: The Product Information menu contains general data about the system, such as the product name, serial number, BIOS version, etc. These information is necessary for troubleshooting (maybe required when asking for technical support).

  • Page 34: Disk Drives

    Disk Drives Select Disk Drives from the main menu to configure the drives installed in your system. The following screen shows the Disk Drives menu: The following table describes the parameters found in this menu. Parameter Date Time IDE Primary Master IDE Primary Slave IDE Secondary Master IDE Secondary Slave...
  • Page 35 Parameter Drive A Drive B Floppy 3 Mode Support Video Halt On Base Memory Extended Memory Total Memory Chapter 2 Description Allows you to configure your floppy drive A. Allows you to configure your floppy drive B. Allows your floppy drive(s) to run in 3 modes including 2.88 MB mode.

  • Page 36: Ide Primary Master/Slave And Ide Secondary Master/Slave Setup

    IDE Primary Master/Slave and IDE Secondary Master/Slave Setup The following screen appears if you select any of the IDE drive parameters: The following table describes the parameters found in this menu. Parameter IDE HDD Auto- Auto-detects your hard disk drive. Detection IDE Primary Master Displays the device type...

  • Page 37: Advanced Bios Features

    Advanced BIOS Features The following screen shows the Advanced BIOS Features. The following table describes each Advanced BIOS Features parameter. Settings in boldface are the default and suggested settings. Parameter Virus Warning CPU L1 & L2 Cache CPU L3 Cache CPU Fast-Strings Quick Power On Self Test Silent Boot...
  • Page 38 Parameter Swap Floppy Drive Boot Up Floppy Seek Boot Up NumLock Status Gate A20 Option Typematic Rate Setting Typematic Rate (Chars/Sec) Typematic Delay (Msec) Security Option OS Select for DRAM > 64 MB Report No FDD for Win 95 Description This item allows you to swap floppy drives.

  • Page 39: Advanced Chipset Features

    Advanced Chipset Features The following screen shows the Advanced Chipset Features. The following table describes each Advanced Chipset Features parameter. Settings in boldface are the default and suggested settings. Parameter System BIOS Cacheable Video BIOS Cacheable Video RAM Cacheable Memory Hole at 15M-16 Delayed Transaction AGP Aperture Size (MB) Delay Prior to Thermal...

  • Page 40: Integrated Peripherals

    Integrated Peripherals The following table describes each Integrated Peripherals parameter. Settings in boldface are the default and suggested settings. Parameter On-Chip Primary IDE On-Chip Secondary IDE IDE Primary Master PIO IDE Primary Slave PIO IDE Secondary Master PIO IDE Secondary Slave PIO Description These parameters let you enable or disable the IDE devices connected to the primary and secondary IDE...
  • Page 41 Parameter IDE Primary Master UDMA IDE Primary Slave UDMA IDE Secondary Master UDMA IDE Secondary Slave UDMA USB controller USB Keyboard Support USB Mouse Support Init Display First AC97 Audio AC97 Mode Onboard/ CNR LAN Selection IDE HDD Block Mode Power On function Onboard FDD Controller Onboard Serial Port 1...
  • Page 42 Parameter UR2 Duplex Mode TxD, RxD Polarity Active Use IR Pins Onboard Parallel Port ECP Mode Use DMA Game Port Address Midi Port Address Midi Port IRQ Description Selects the speed of UR2 Duplex Mode. Selects the speed of TxD, RxD Polarity Active. Use IR Pins as IR-Rx2Tx2 or RxD2, TxD2 This item controls the onboard parallel port address an interrupt.

  • Page 43: Power Management Setup

    Power Management Setup The Power Management menu lets you configure the system power-management feature. It works only under APM mode. IMPORTANT:If an ACPI-aware operating system such as Windows 98 or Windows 2000 is installed in ACPI mode, the operating system will use the ACPI interfaces. Then the settings in Power Management page is non-effective.
  • Page 44 Parameter Power Management Video Off Method Video Off In Suspend Suspend Type MODEM Use IRQ Suspend Mode HDD Power Down Sort-Off by PWR-BTTN Power-On by Ring USB KB Wake-up from S3 Primary IDE 0 Primary IDE 1 Secondary IDE 0 Secondary IDE 1 Description This function allows you to set the default...
  • Page 45 Parameter FDD, COM, LPT port PCI PIRQ [A-D]# Power Management Mode Table Mode Max Saving 1 hou Min Saving 1 min Chapter 2 Description To enable or disable the detection of FDD, COM port, and LPT port activities for powe down state transition.

  • Page 46: Pnp/Pci Configurations

    PnP/PCI Configurations The table below describes each PnP/PCI configuration parameter. Settings in boldface are the default and suggested settings. Parameter Reset Configuration Dat Resources Controlled By IRQ Resources IRQ 3 (COM2) IRQ 4 (COM1) IRQ 5 (Network/Sound or Others IRQ 7 (Printer or Others) IRQ 9 (Video or Others) IRQ 10 (SCSI or Others) IRQ 11 (SCSI or Others)
  • Page 47 Parameter PCI/VGA Palette Snoop Chapter 2 Description This parameter permits you to use the palette snooping feature if you installed more than one VGA card in the system. The PVI/VGA palette snoop function allows the control palette register (CPR) to manage and update the VGA RAMDAC (Digital Analog Converter, a color data storage) of each VGA card installed in the system.

  • Page 48: Frequency Control

    Frequency Control The following table describes the parameters found in this menu. Parameter Processor Processor Spee CPU Clock Ratio Description Indicates the type of processor installed in your computer. Indicates the processor speed. The Intel Pentium is designed to have a different Internal (Core) and External (Bus) frequency.

  • Page 49: System Security

    System Security The Setup program has a number of security features to prevent unauthorized access to the system and its data. Supervisor Password To set a password: At the prompt, type your password. Your password can be up to 8 alphanumeric characters. When you type the characters, they appear as asterisks on the password screen box.

  • Page 50: User Password

    User Password To set a password: At the prompt, type your password. Your password can be up to 8 alphanumeric characters. When you type the characters, they appear as asterisks on the password screen box. After typing the password, press Enter. At the next prompt, re-type your password and press Enter again to confirm the new password.

  • Page 51: Load Default Settings

    Load Default Settings You need to reload the BIOS default settings every time you make changes to your system hardware configuration (such as memory size, CPU type, hard disk type, etc.); otherwise, BIOS will keep the previous CMOS settings. Selecting this option displays the following dialog box: Choosing Yes enables BIOS to automatically detect the hardware changes that you have made in your system.

  • Page 52: Exiting Setup

    Exiting Setup To exit the BIOS utility, simply press Esc. The following dialog box appears: Select Yes to exit Setup. Select No to return to the main menu. If you have made changes in the parameter settings, you will be asked if you want to keep the changes made to the BIOS.

  • Page 53: Machine Disassembly And Replacement

    Machine Disassembly and Replacement This chapter contains 2 separate step-by-step procedures on how to disassemble the Veriton 9100 desktop computer for maintenance and troubleshooting. To disassemble the computer, you need the following tools: Wrist grounding strap and conductive mat for preventing electrostatic discharge...

  • Page 54: Disasembling The Veriton 9100

    Disassembling the Veriton 9100 Opening the Housing This section tells you how to open the housing cover when you need to install additional components inside the system unit. CAUTION: Before you proceed, make sure that you have turned off the system and all peripherals connected to it.

  • Page 55: Removing The Front Panel

    Removing the Front Panel Removing the Housing Cover 45. Release the 6 latches as shown below that holds the front panel and then it from the housing. Chapter 3...

  • Page 56: Removing A Dimm

    Removing a DIMM Removing the Housing Cover 45 Press the latches on both sides of the DIMM socket outward, to release the DIMM. Then gently lift the DIMM out to remove it. Removing the Processor Follow these steps to remove the processor: Removing the Housing Cover 45 Detach the fan/ heatsink cable connector .

  • Page 57: Installing The Processor

    Installing the Processor Put the fan/ heatsink on the retention mechanism, and install one side of the clip on the retention mechanism. Push one side of the clip to be locked on the retention mechanism. Do the same procedure for the other side of the clip. Pull the socket lever up to release the processor pins from the socket holes.

  • Page 58: Removing The Hard Disk

    Removing the Hard Disk Follow these steps to remove the hard disk drive: Removing the Housing Cover 45 Remove the four screws that hold the hard disk drive to the disk frame. Set the screws aside. Detach the power and disk drive cables from the hard disk drive, then detach the hard disk from the drive frame.

  • Page 59: Removing The Cd-Rom/Dvd-Rom/Cd-Rw Drive

    Disconnect the power connector and the diskette drive cable, then remove the diskette drive from the housing. Removing the CD-ROM/DVD-ROM/CD-RW Drive Follow these steps to remove the CD-ROM drive: Removing the Housing Cover 45 Remove the four screws holding the CD-ROM drive Disconnect the power connector, CD-ROM drive cable, and audio cable, then remove the CD-ROM drive from the housing.

  • Page 60: Removing The Pci And Agp Expansion Cards

    Removing the PCI and AGP Expansion Cards Remove the screw on the bracket of the expansion card. Set the screw aside, you will need it when replacing the expansion card. Gently pull out the expansion card to remove it from the expansion slot. NOTE: When you turn on the system, BIOS automatically detects and assigns resources to the PCI or AGP devices.

  • Page 61: Removing The System Main Board

    Removing the System Main Board Put the housing to lying position with the open area facing upward. Remove the seven screws holding the main board and then remove the main board from the housing. Removing the Power Supply Disconnect the power supply power connector from the main board. Remove the five screws holding the power supply, and then remove the power supply from the housing..

  • Page 62: Removing The Intrusion Alarm

    Removing the Intrusion Alarm Remove the screw that secures the intrusion alarm and then remove it from the housing. Chapter 3...

  • Page 63: Troubleshooting

    Troubleshooting This chapter provides troubleshooting information for the Veriton 9100: Power-On Self-Test (POST) Index of Error Messages Index of Error Codes and Error Beeps Index of Error Symptoms Undetermined Problems Chapter 4 Chapter 4...

  • Page 64: Power-On Self-Test (Post)

    Power-On Self-Test (POST) Each time you turn on the system, the Power-on Self Test (POST) is initiated. Several items are tested during POST, but is for the most part transparent to the user. The Power-On Self Test (POST) is a BIOS procedure that boots the system, initializes and diagnoses the system components, and controls the operation of the power-on password option.

  • Page 65: Post Error Messages List

    POST Error Messages List If you cannot run the diagnostics program tests but did receive a POST error message, use “POST Error Messages List” to diagnose system problems. If you did not receive any error message, look for a description of your error symptoms in “Error Symptoms List”...
  • Page 66 BIOS Messages IDE Drive 0 Error IDE Drive 1 Error IDE Drive 2 Error IDE Drive 3 Error IRQ Setting Error Expansion ROM Allocation Fail I/O Resource Conflict(s Memory Resource Conflict(s) PCI Device Error PS/2 Pointing Device Interface Error PS/2 Pointing Device Error DMI Table Was Destroyed Pres Ctrl + Alt + Esc key to enter Setup or F1 key to continue...

  • Page 67: Error Symptoms List

    Error Symptoms List NOTE: To diagnose a problem, first find the error symptom in the left column. If directed to a check procedure, replace the FRU indicated in the check procedure. If no check procedure is indicated, the first Action/ FRU listed in right column is the most likely cause.
  • Page 68 Error Symptom Diskette drive read/write error. Diskette drive LED comes on for more than 2 minutes when reading data. Diskette drive LED fails to light, and the drive is unable to access for more than 2 minutes. Diskette drive test failed. NOTE: Ensure hard disk drive is configured correctly in BIOS Setup, cable/jumper are set correctly before diagnosing any hard disk drive problems.
  • Page 69 Error Symptom CD/DVD-ROM drive can play audio CD but no sound output. Real-time clock is inaccurate. Audio software program invokes but no sound comes from speakers. Modem ring cannot wake up system from suspend mode. Data/fax modem software program invokes but cannot receive/send data/fax Fax/voice modem software program invokes but has no sound output.
  • Page 70 Error Symptom Execute “Load BIOS Default Settings” in BIOS Setup to confirm ports presence before diagnosing any parallel/serial ports problems. Serial or parallel port loop-back test failed. Printing failed. Printer problems. Some or all keys on keyboard do not work. Pressing power switch does not turn off system.

  • Page 71: Undetermined Problems

    Check all cables and connectors for proper installation. If the jumpers, switches and voltage settings are correct, remove or disconnect the following, one at a time: 10. Non-Acer devices External devices Any adapter card (modem card, LAN card or video card, if installed)
  • Page 72 Chapter 4...

  • Page 73: Jumper And Connector Information

    Chapter 5 Jumper and Connector Information Jumpers and Connectors Refer to the following figure for the location of the jumpers and connectors on the main board: Main board Chapter 5...

  • Page 74: Connector Description

    Connector Description Connector No. Battery BUZ1 Buzzer PS/2 mouse (upper) and keyboard (lower) ports Parallel (upper), VGA (lower right) and serial port 1 (lower left) ports Power connecto Network (upper) and USB (lower) ports Power connecto MIDI/game (upper), line-out (left), line-in (middle), and mic-in (right) ports IDE 1 HDD connector CN10...

  • Page 75: Jumper Setting

    Jumper Setting Jumper Spread Spectrum Disabled 2-3* Enabled Host Clock 133MH 2-3* 100MH JP12 CMOS clea 1-2* Normal Clear CMOS JP13 Fourth USB Function 1-2* USB2 CNR2 JP14 Fourth USB Function 1-2* USB2 CNR2 JP16 CPU speed 1-2* Normal Mode Safe Mode JP17 Onboard Lan EEPRO...
  • Page 76 Audio Board Connector No. Audio connector-connects to the AUDIO2 connector of the mainboard USB connector-connects to the USB2 connector of the mainboard CN2 and CN3 USB ports Microphone-in port Audio-out port Description Chapter 5...

  • Page 77: Fru (Field Replaceable Unit) List

    FRU parts for repair and service of customer machines. NOTE: To scrap or to return the defective parts, you should follow the local government ordinance or regulations on how best to dispose it, or follow the rules set by your regional Acer office on how to return it.

  • Page 78: Veriton 9100 Exploded Diagram

    Veriton 9100 Exploded Diagram Chapter 6...
  • Page 79 256,OD IC CPU WILLAMETTE 1.3GHZ/400FS CPU FANSINK WILLAMETTE ASSY N/B HEATSINK + CLIP TEHAMA RIMM MODULE 64M 800MHZ NON-ECC FDD 1.44 JU-256A046P ACER HDD 30G U5 SG/ST330621A SVC123 HDD 40G U5 SG/ST340823A SVC123 CD-RW 8/4/32X LG/CED 8080B AC Part No.
  • Page 80 Picture Cable Main Board Partname IDE CABLE,40PIN,3C CABLE, 40PIN FDD CABLE,34PIN,2 CABLE, 2PIN CABLE, 4PIN CABLE, 4PIN CABLE, 6/5PIN USB CABLE,10PIN MAINBOARD/S80X Description C.A 40P 3C 150+300MM IDE 50.92207.031 C.A 40P 3C 150+300M 50.92207.041 ATA66 H61 C.A 34P 2C 350MM FDD 50.54A08.001 M19A/FU W.A.
  • Page 81 Picture Board VGA BOARD AUDIO BOARD Power Supply POWER SUPPERY 300W DELTA/ DPS-300KB Case/Cover/Bracket assembly RIGHT PANEL LEFT PANEL UPPER CASE 1-10 LOWER CASE Chapter 6 Partname Description VGA GEFORCE2 MX 32MB CRT ONLY S58M AUDIO/USB BOARD SPS 300W DELTA/DPS- 300KB-1A CVR R SECC T-.8 LX45 CVR L SECC T-.8 H80...
  • Page 82 Picture 1-11 ASSEMBLYBEZEL LED HOLDER MODULE Screws 1-17 SCREW SCREW HDD SCREW 1-3, KEY LOCK SCREW 1-18 FDD SCREW SCREW Miscellaneous parts FDD FRAME PLATE NAME RUBBER Keyboard KEYBOARD,104KEYS,USB,US,DA RFON KEYBOARD 105 KEY Pointing device MOUSE LOGITEC Partname Description ASSY BEZEL D002 H80 (VERITON) ASSY HLD LX45 SCRW MACH PAN M2*10L...
  • Page 83 Picture Partname Description Part No. Speake SPEAKER,USB,CHARMING/V-1 SPK USB POWER 90.38H12.001 CHARMING/V-1 Chapter 6...
  • Page 84 Chapter 6...

  • Page 85: Appendix A Model Definition And Configuration

    Model Definition and Configuration Veriton 9100 The Veriton 9100 Model No. Define: Trade Mark: Brand Name: Acer Description: Acer Veriton Series, Willamette Socket 423 Based PC System Model No: VT9100 Product Name: Veriton 9100 Appendix A Appendix A...
  • Page 86 Appendix A...

  • Page 87: Appendix B Test Compatible Components

    Appendix B Test Compatible Component This computer’s compatibility is tested and verified by Acer’s internal testing department. All of its system functions are tested under MS DOS V6.22, Microsoft Windows ME (EN/TW), Microsoft Windows 2000 Professional environment. Refer to the following lists for components, adapter cards, and peripherals which have passed these tests.

  • Page 88: Ms Dos V6.22 Environment Test

    MS DOS V6.22 Environment Test Item Processor Memory Cache Graphics card Optical device Mode Mouse Keyboard Specifications Pentuim 4 1.3GHz Pentuim 4 1.3GHz 128 MB 256 MB 384 MB 512 MB In CPU nVIDIA RIVA TNT2 M64 32M SDR nVIDIA GeForce 2 MX 32M SDR 12X DVD-ROM 48X CD-ROM 8X/4X/32X CD-RW...

  • Page 89: Microsoft Windows Me (En/Tw) Environment Test

    Microsoft SideWinder Precision Pro USB Primax RAPTOR 3D USB Gamestick HP Desk Jet 895C USB Printer Logitech Pagescan USB Charming USB Powered Speaker Acer USB Video Capture Kit (DVC-V6) AcerScan Prisa 310U iomega ZIP 100 USB HP Desk Jet 695C Epson Stylus Color 440...

  • Page 90: Microsoft Windows 2000 Professional Environment Test

    Onboard Sigma Tel Ac97 Creative Sound Blaster PCI 64 Onboard 8281 3COM 3C905C-TX HP Desk Jet 895C USB Printer Logitech Pagescan USB Charming USB Powered Speaker Acer USB Video Capture Kit (DVC-V6) AcerScan Prisa 310U iomega ZIP 100 USB Appendix B...

  • Page 91: Appendix C Online Support Information

    This section describes online technical support services available to help you repair your Acer Systems. If you are a distributor, dealer, ASP or TPM, please refer your technical queries to your local Acer branch office. Acer Branch Offices and Regional Business Units may access our website. However some information sources will require a user i.d.
  • Page 92 Appendix C...

  • Page 93: Index

    removing 56 Assignment Map 22 Audio controller 20 Audio Board 72 Audio Interface 20 Audio-in/Line-in port 12 Audio-out/Line-out port 12 Basic level 28 BIOS Setup 27 Entering Setup 28 Setup Utility 28 BIOS Utility Disk Drives 30 Exiting Setup 48 Load Default Settings 47 Power Management 39 Product Information 29...
  • Page 94 removing 54 Housing 50 Opening the 50 Humidity 24 I/O Address Map 23 IDE Interface 20 IDSEL 22 Interface audio 20 IDE 20 Video 19 IRQ Assignment Map 23 Jumper and Connector Information 69 Jumpers 69 keyboard 15 cursor keys 16 lock keys 16 windows-keys 17 Load Default Settings 47...
  • Page 95 Serial Port 21 Serial port 11 socket memory 19 Socket 370 18 Suspend Mode 26 Switching Power Supply 102W 25 Symptoms List 63 Audio 65 CD/DVD-ROM Drive 64 Diskette Drive 63 Keyboard 66 Memory 63 Modem 65 Monitor 65 Other 66 Parallel Port 66 Power Supply 66 Processor / Processor Fan 63...
  • Page 96 Index...
