- Page 1 866.332.2403 (TOLL FREE); 7am – 7pm Pacific Time, Monday-Saturday ASSEMBLY INSTRUCTIONS FOR THE BENCH SWING SETS...
- Page 2 P| 1 Bench Swing Sets www.ForeverRedwood.com...
- Page 3 P| 2 Bench Swing Sets www.ForeverRedwood.com...
- Page 4 P| 3 Bench Swing Sets www.ForeverRedwood.com...
- Page 5 P| 4 Bench Swing Sets www.ForeverRedwood.com...
- Page 6 Step 2: Put the Quick Links (I) and the Springs (J) in the hanger’s support. After that, put the chains (K). Take a few minutes to adjust the chain height to your preference. Quick Link P| 5 Bench Swing Sets www.ForeverRedwood.com...
- Page 7 Step 4: Attach the diagonal supports (4) to the posts and to the support with 3/8´´ x 7´´ bolts (A). Each part has a series of numbers that indicate where to attach the part with the corresponding number. 3/8´´ x 7´´ Bolts Note: If your Swing Set doesn´t include roof, then go to step 9. P| 6 Bench Swing Sets www.ForeverRedwood.com...
- Page 8 Step 6: Attach the roof panels (6) to the roof supports with 5/16´´ x 4´´ bolts (E) and to the diagonal supports with 3´´ deck screws (F). Each part has a series of numbers that indicate where to attach the part with the corresponding number. 5/16´´ x 4´´ Bolts 3´´ Deck Screws P| 7 Bench Swing Sets www.ForeverRedwood.com...
- Page 9 Step 8: Use 2 ½´´ deck screws (G) to attach the roof board (7) to the posts. Each part has a series of numbers that indicate where to attach the part with the corresponding number. 2 ½´´ Deck Screws P| 8 Bench Swing Sets www.ForeverRedwood.com...
- Page 10 Step 10: Attach the backrest (10) to the armrests with 5/16´´ x 3 ½´´ bolts (A) and 4´´ x 3/8´´ eyebolts (I). Each part has a series of numbers that indicate where to attach the part with the corresponding number. 4´´ x 3/8´´ Eye Bolts 5/16´´ x 4´´ Bolts 5/16´´ x 3 ½´´ Bolts P| 9 Bench Swing Sets www.ForeverRedwood.com...
- Page 11 Step 11: Finally, use quick links (I) to join the bench swing to the chains (K). P| 10 Bench Swing Sets www.ForeverRedwood.com...
- Page 12 Option A – Without Swing Roof Option B – With Swing Roof P| 11 Bench Swing Sets www.ForeverRedwood.com...
- Page 13 This completes the Swing assembly. Hope you enjoy your set for many decades. If you ever have a problem or a question, don't hesitate to call us (866 332 2403) or email us. We are here to support you. P| 12 Bench Swing Sets www.ForeverRedwood.com...
