  • Page 3 Rev C ©Copyright Topcon Positioning Systems, Inc. February, 2012 All contents in this manual are copyrighted by Topcon. All rights reserved. The information contained herein may not be used, accessed, copied, stored, displayed, sold, modified, published, or distributed, or otherwise reproduced...
  • Page 4 Terms and Conditions Thank you for buying this Topcon product. This manual has been prepared to assist you with the care and operation of the product and its use is subject to these Terms and Conditions and those more fully set forth in the Operator’s/User’s Manual.

  • Page 5: Table Of Contents

    Table of Contents Introduction ............1-1 X63 3D Excavator Indicate System ........1-2 X62 2D Excavator Indicate System ........1-5 TS-1 Sensor Installation ........2-1 TS-1 Sensor Orientation ............2-2 Body Sensor Mounting ............2-4 Boom Sensor Mounting ............2-5 Secondary Boom Sensor Mounting (Optional) ....
  • Page 6 Table of Contents Sensor Filtering ..............3-35 Verifying X63/X62 Setup ......... 4-1 Verifying Range of Motion ..........4-1 Verifying Elevation Accuracy ..........4-2 Verifying Main Antenna to Boom Length ......4-5 Verifying Aux Antenna to Boom Length ......4-7 Verifying the Main Antenna ..........4-12 Verifying Main Antenna Height .........

  • Page 7: Introduction

    Chapter 1 Introduction This manual discusses how to install and calibrate the X63 GPS excavator indicate system for 3D control and the X62 excavator indicate system for 2D control. The TS-1 tilt sensors (9174-0000) used in the Topcon excavator systems measure the pitch and roll angle of various machine elements (Figure 1-1).
  • Page 8 Introduction 3D Excavator Indicate System Topcon’s X63 excavator indicate system contains the TS-1 tilt sensors, GX-60 Display, MC-R3 Controller, and two GPS antennas for 3-dimensional control of the machine. Boom Boom Boom Body Sensor Sensor Sensor Sensor Stick Stick Stick...
  • Page 9 Sitting in the cab facing forward, the sensor angles are 0° straight ahead (horizontal), +90° straight up, and -90° directly down (Figure 1-2). Figure 1-2. Angle Convention Used For TS-1 Sensors The Main and Auxiliary antennas provide positional and heading information.
  • Page 10 Introduction Figure 1-4 shows the basic cabling connections for the X63/X62 system. When installing components, use the Topcon supplied fuse or fused power from the machine of the same rating. System ground must be connected to the frame side of the ground disconnect switch, not directly to the NOTICE negative battery terminal.
  • Page 11 Figure 1-5. TS-1 Tilt Sensors and LS-B10W on Excavator Figure 1-4 on page 1-4 shows the basic cabling connections for the X62 system. When installing components, use the Topcon supplied fuse or fused power from the machine of the same rating.
  • Page 12 Introduction POWER LS-B10W LASER RECEIVER AND BRACKET SENSOR TERMINATOR BODY BOOM STICK BUCKET TS-1 TILT SENSORS Figure 1-6. Basic Cable Connections for X62 X63/X62 Installation and Calibration Manual...

  • Page 13: Sensor Installation

    Chapter 2 TS-1 Sensor Installation Each TS-1 sensor contains a 3-axis 360° sensor element which must be configured depending on the mounting position. The TS-1 tilt sensors can be mounted in many orientations as long as they are parallel to the axis being measured (Figure 2-1). Locate surfaces that protect the sensor from physical damage and are convenient for cable routing.

  • Page 14: Ts-1 Sensor Orientation

    These directions assume the mounting surface is at zero degrees. Table 2-1. Marker Direction Options Mounting Surface Marker Direction Options Back Right Down Forward Right Forward Right Left Forward Right Forward Forward Right X63/X62 Installation and Calibration Manual...
  • Page 15 TS-1 Sensor Orientation Mounting each tilt sensor within +/- 20° of the pivot centerline is a good practice. Though not necessary for system performance, squaring the sensors to each part of the machine makes for a cleaner looking installation. All tilt sensor orientation is determined when the sensor is horizontal (zero degrees).

  • Page 16: Body Sensor Mounting

    The recommended mounting location is up, on top of the body, with the arrow pointing forward toward the direction of travel (Figure 2-2) Boom Pivot Body Sensor Mount Body Sensor Parallel to Boom Pivot Figure 2-2. Body Sensor Mounting X63/X62 Installation and Calibration Manual...

  • Page 17: Boom Sensor Mounting

    Boom Sensor Mounting Up Mounting (Recommended) Side Figure 2-3. Body Sensor Mounting Examples Boom Sensor Mounting For the boom sensor, locate a convenient surface parallel to the boom center. The recommended mounting location is up (on the top of the boom) with the arrow pointing forward toward the direction of travel (Figure 2-4 on page 2-6).

  • Page 18: Secondary Boom Sensor Mounting (Optional)

    Correct Up Location Side Location (Recommended) Incorrect Taper Location Figure 2-4. Boom Sensor Mounting Secondary Boom Sensor Mounting (Optional) See the previous section “Boom Sensor Mounting” on page 2-5 for secondary boom sensor mounting locations. X63/X62 Installation and Calibration Manual...

  • Page 19: Stick Sensor Mounting

    Stick Sensor Mounting Stick Sensor Mounting Locate a convenient surface to mount the sensor. Mounting the TS-1 close to the top of the stick will help prevent damage during digging. The recommended mounting location is on the left side of the stick with the arrow pointing forward toward the direction of travel, when the stick is extended (Figure 2-5 on page 2-7).

  • Page 20: Bucket Sensor Mounting

    NOTICE Because this varies widely, such specific protection is not included in the Topcon kit and must be supplied by the installer. The recommended location of the sensor is on the left side of the bucket with the arrow pointing forward, toward the direction of travel.

  • Page 21: Dog-Bone Sensor Mounting (Optional)

    Dog-bone Sensor Mounting (Optional) Correct Incorrect Incorrect Side Location Figure 2-6. Bucket Sensor Mounting Dog-bone Sensor Mounting (Optional) An alternative location for the bucket sensor is the dog-bone. This location may offer additional protection compared to mounting the sensor directly on the bucket. If possible, placing the sensor on the inside of the dog-bone will provide additional protection.
  • Page 22 The recommended location of the sensor is on the left side of the dog- bone with the arrow pointing forward, toward the direction of travel. Correct Side Location Figure 2-7. Dog-bone Sensor Mounting Example X63/X62 Installation and Calibration Manual 2-10...

  • Page 23: Tilt Bucket Sensor Mounting (Optional)

    Tilt Bucket Sensor Mounting Tilt Bucket Sensor Mounting (Optional) If using tilt bucket, an additional sensor may be mounted to the bucket (Figure 2-8). Tilt bucket sensor mounting differs from all other sensors. Determine the location and orientation of the sensor with the bucket hanging vertically.
  • Page 24 TS-1 Sensor Installation Notes: X63/X62 Installation and Calibration Manual 2-12...

  • Page 25: Machine Calibration

    Chapter 3 Machine Calibration Before calibrating TS-1 sensors, note the following: When the system is first powered on, it may take several minutes for the GX-60 to discover (detect) NOTE each sensor. Check sensor’s serial numbers before installing. The last two digits of the serial number determine NOTE the sensor CAN address, and must be unique to each machine.

  • Page 26: Measuring Machine Lengths

    NOTICE Take each measurement twice to ensure accuracy. Table 3-1. Machine Measurements Measurements To Screen Shot Take Boom Pivot Line Boom Center Line Antenna Positions Boom Center Boom Pivot Line Antenna Heights X63/X62 Installation and Calibration Manual...
  • Page 27 Measuring Machine Lengths Table 3-1. Machine Measurements (Continued) Measurements To Screen Shot Take Boom Length Stick Length Bucket Width and Length (repeated for each bucket) Notice: Select one bucket and calibrate the machine. When the system is known to be working correctly with the bucket sensor, add additional buckets.
  • Page 28 Machine Calibration Table 3-1. Machine Measurements (Continued) Measurements To Screen Shot Take Dog-bone Lengths Tilt Bucket Length X63/X62 Installation and Calibration Manual...

  • Page 29: Entering Sensor Information

    Power up the system and allow several minutes for the 3DMC software to detect the sensors. Before calibrating the sensors on a X63/X62 system, set up each sensor in 3DMC. You will need the following information: • the last three digits of the sensor’s serial number •...
  • Page 30 Repeat steps 4 and 5 for the remaining sensors. 7. Press Next to access the Stick Sensor screen. Sensor ID Figure 3-2. Select Stick Sensor ID 8. Repeat steps 4 and 5 for the stick sensor. X63/X62 Installation and Calibration Manual...
  • Page 31 Entering Sensor Information 9. Press Next to access the Stick Sensor screen. Sensor ID Figure 3-3. Select Bucket Sensor ID 10. Repeat steps 4 and 5 for the bucket sensor. for the machine elements. Step 2: Set sensor orientations 1. Navigate to the Excavator Frame/Sensor screen. 2.
  • Page 32 Machine Calibration 6. Press Next and repeat steps 2 and 3 for the bucket sensor. Figure 3-5. Enter Sensor Orientation X63/X62 Installation and Calibration Manual...

  • Page 33: Calibrating The Sensors

    Calibrating the Sensors Calibrating the Sensors Once the sensors are named (3DMC V7.06 and older only), assigned to a machine element, and the orientation is selected, calibrate each sensor using 3DMC. A sensor calibration can be performed at any time. The best practice is to perform the machine calibrations as ordered in this manual.
  • Page 34 2. Curl the stick and bucket in as close as possible to reduce tipping errors. 3. Rotate the body parallel to the tracks (position 1). 4. In 3DMC, tap Topcon LogoControlMachine setup. Select the applicable machine file for the job and press Edit. Press Next to navigate to the Excavator Frame/Sensors screen.

  • Page 35: Boom Sensor Calibration

    Calibrating the Sensors 8. Set the Pitch and Roll to half the displayed values (for example, 13.1 / 2 = 6.55 and 0.2 / 2 = 0.1). Displayed Values Calculated Values (actual readings) (half of Displayed Values) Figure 3-8. Set Pitch and Roll Value to Half of Displayed Values 9.
  • Page 36 (Figure 3-9). Figure 3-9. Place Laser to Strike Center of Boom Pivot 5. In 3DMC, tap Topcon LogoControlMachine setup. 6. Select the applicable machine file for the job and press Edit. Press Next to navigate to the Excavator Frame/Sensors screen.
  • Page 37 Calibrating the Sensors 9. Once the boom Pitch value is set to zero, set the boom Roll value to match the body Roll value. Roll Value Matches Body Figure 3-11. Set Boom Roll Value to Match Body Roll Value If the body Pitch and Poll has not changed from when the body sensor was calibrated, enter the NOTICE recorded body Roll value for the boom Roll value.

  • Page 38: Secondary Boom Sensor Calibration (Optional)

    Make sure to check the Secondary Boom check box. See “Boom Sensor Calibration” on page 3-11 for details on calibrating the secondary boom sensor. Figure 3-12. Secondary Boom Check Box X63/X62 Installation and Calibration Manual 3-14...

  • Page 39: Stick Sensor Calibration

    2. Align the boom-stick pivot and the bucket pivot. Figure 3-13. Stick at -90° 3. In 3DMC, tap Topcon LogoControlMachine setup. Select the applicable machine file for the job and press Edit. Press Next to navigate to the Excavator Stick screen.
  • Page 40 5. Set the Pitch to -90.0° and press Ok (Figure 3-14). Figure 3-14. Set Pitch Value to -90.0 6. Move the stick up in the air until the Pitch reads Zero (0.0°). Figure 3-15. Pitch 0.0° X63/X62 Installation and Calibration Manual 3-16...
  • Page 41 Calibrating the Sensors 7. Set the stick Roll value to match the body Roll value. Roll Value Matches Body Figure 3-16. Set Stick Roll Value to Match Body Roll Value If the body Pitch and Roll values have not changed from when the body sensor was calibrated, enter the NOTICE recorded body Roll value for the stick Roll value.

  • Page 42: Bucket Sensor Calibration

    Bucket Calibration” on page 3-31. 1. Align the boom-stick pivot and the bucket teeth. 2. In 3DMC, tap Topcon LogoControl Machine setup, select the applicable machine file for the job, and press Edit. 3. Press Next to navigate to the Bucket Sensor Mounting screen.
  • Page 43 Calibrating the Sensors Figure 3-17. Set the Pitch Value to -90.0° 6. Once the bucket Pitch value is set to -90.0°, position the bucket at zero (0.0°), and then set the bucket Roll value to match the body Roll value. Press Ok. Roll Value Matches Body Figure 3-18.

  • Page 44: Bucket Edge Calibration

    These calibrations must also be performed for each individual bucket when using multiple buckets. 1. With the bucket plumb, press Calibrate. Press Ok at the confirmation. When done, press Next. Figure 3-19. Calibrate Bucket Edge X63/X62 Installation and Calibration Manual 3-20...
  • Page 45 Calibrating the Sensors 2. Move the bucket so that the bottom of the bucket lays flat on the ground, and press Finish. Figure 3-20. Calibrate Bucket Base If setting up multiple buckets of any kind, please refer to “Multiple Bucket Calibration” on page 3- NOTICE P/N 7010-0697 3-21...

  • Page 46: Multiple Bucket Calibration

    “Bucket Sensor Calibration” on page 3-18 will remain the same for the sensor. 1. In 3DMC, tap Topcon LogoControlMachine setup. Select the applicable machine file for the job and press Edit. 2. Press Next to navigate to the Excavator Buckets screen (Figure 3-21).
  • Page 47 Calibrating the Sensors 3. Enter the bucket Width and Length. Press Next (Figure 3-21). Figure 3-22. Enter Bucket Lengths If setting up a tilt bucket, select the Tilt bucket check box, and refer to “Tilt Bucket Calibration” on NOTE page 3-31 for information on calibration the tilt bucket sensor.

  • Page 48: Bucket Edge Calibration

    These calibrations must also be performed for each individual bucket when using multiple buckets. 1. With the bucket plumb, press Calibrate. Press Ok at the confirmation. When done, press Next. Figure 3-24. Calibrate Bucket Edge X63/X62 Installation and Calibration Manual 3-24...
  • Page 49 Calibrating the Sensors 2. Move the bucket so that the bottom of the bucket lays flat on the ground, and press Finish. Figure 3-25. Calibrate Bucket Base P/N 7010-0697 3-25...

  • Page 50: Dog-Bone Sensor Calibration

    1. Position the machine on a stable surface free of obstructions and rotate the body parallel to the tracks. 2. In 3DMC, tap Topcon LogoControl Machine setup, select the applicable machine file for the job, and press Edit. 3. Press Next to navigate to the Bucket Sensor Mounting screen.
  • Page 51 Calibrating the Sensors 5. Set the dog-bone (elements 3-4) horizontal using a builders level. Once elements 3 and 4 are level, set the Pitch value to zero (0.0°), and then set the Roll value to match the body roll. Press OK, and then press Next.
  • Page 52 Figure 3-27. Set Pitch Value to Zero Figure 3-28. Determine Stick Angle Difference The dog-bone sensor is normally mounted on the left side, though the Excavator DogBone screen NOTICE depicts the sensor mounted on the right side. X63/X62 Installation and Calibration Manual 3-28...

  • Page 53: Bucket Edge Calibration

    Calibrating the Sensors Bucket Edge Calibration Perform the following bucket edge calibration procedures for all bucket types. These calibrations must also be performed for each individual bucket when using multiple buckets. 1. With the bucket plumb, press Calibrate. Press Ok at the confirmation.
  • Page 54 2. Move the bucket so that the bottom of the bucket lays flat on the ground, and press Finish. Figure 3-30. Calibrate Bucket Base If setting up multiple buckets of any kind, please refer to “Multiple Bucket Calibration” on page 3- NOTICE X63/X62 Installation and Calibration Manual 3-30...

  • Page 55: Tilt Bucket Calibration

    Calibrating the Sensors Tilt Bucket Calibration 1. In 3DMC, tap Topcon LogoControlMachine setup. Select the applicable machine file for the job and press Edit. 2. Press Next to navigate to the Excavator Buckets screen (Figure 3-21). Press New. Figure 3-31. Add New Bucket 3.
  • Page 56 5. Adjust the bucket until the tilt pin is horizontal. 6. Using a carpenter’s level, adjust the bucket tilt until the bucket is level. 7. In 3DMC, select the sensor’s Orientation based on this position (Figure 3-33). Figure 3-33. Select Tilt Sensor Orientation X63/X62 Installation and Calibration Manual 3-32...

  • Page 57: Bucket Edge Calibration

    Calibrating the Sensors 8. With the bucket in this position, set both the Pitch and Roll values to Zero (Figure 3-34). Figure 3-34. Set Pitch and Roll to Zero Bucket Edge Calibration Perform the following bucket edge calibration procedures for all bucket types.
  • Page 58 2. Move the bucket so that the bottom of the bucket lays flat on the ground, and press Finish. Figure 3-36. Calibrate Bucket Base If setting up multiple buckets of any kind, please refer to “Multiple Bucket Calibration” on page 3- NOTICE X63/X62 Installation and Calibration Manual 3-34...

  • Page 59: Can Termination

    To ensure proper communication between the sensors and the GX-60, the last sensor physically connected must use the hard terminator provided with the X63/X62 system. Typically, this hard terminator connects to the bucket sensor (or the tilt bucket sensor). SENSOR...
  • Page 60 Machine Calibration 4. Navigate through the remaining steps of Machine Setup, saving the file and exiting. Figure 3-38. Set Filtering Level (Bucket Sensor) X63/X62 Installation and Calibration Manual 3-36...

  • Page 61: Verifying Range Of Motion

    Chapter 4 Verifying X63/X62 Setup After mounting and calibrating the sensors, verify the accuracy of the sensors and the effectiveness of communication with the GX-60 Display. Occasionally, these same verifications can be performed after several months of use to ensure continued excavating accuracy.

  • Page 62: Verifying Elevation Accuracy

    Verifying Elevation Accuracy To easily verify elevation accuracy (without GPS fluctuations), use the 3DMC simulator mode. When done, and before performing other function, be sure to close 3DMC and leave simulator mode. 1. Start 3DMC. X63/X62 Installation and Calibration Manual...
  • Page 63 Verifying Elevation Accuracy 2. At the Connecting to GPS screen, press the antenna icon and press Yes at the confirmation (Figure 4-2). Figure 4-2. Enter 3DMC Simulation 3. In front of the machine, set up a laser and grade rod with detector. 4.
  • Page 64 If the elevation does not match, moving one machine element at a time can help determine the problem sensor. Typical accuracy should be +/- 0.05 Ft. 1.53 Figure 4-4. Verify Elevation Change 7. Close and re-start 3DMC to leave the simulation mode. X63/X62 Installation and Calibration Manual...

  • Page 65: Verifying Main Antenna To Boom Length

    Verifying Main Antenna to Boom Length Verifying Main Antenna to Boom Length The distance from the Main antenna to the boom pivot determines the position of the machine front/back. Errors in this measurement will have a direct corresponding position error at the bucket. Main Figure 4-5.
  • Page 66 • If the Northing value recorded by 3DMC is larger, shorten the length in 3DMC by this amount (0.10) (Figure 4-6). 9. Repeat these steps to verify the correction. Figure 4-6. “Rotate” Main Antenna on Body X63/X62 Installation and Calibration Manual...

  • Page 67: Verifying Aux Antenna To Boom Length

    Verifying Aux Antenna to Boom Length Verifying Aux Antenna to Boom Length The position of the Main antenna to the Aux antenna determines GPS heading. The distance from the Aux antenna to the boom pivot determines the rotational heading of the machine. Small errors in this measurement may have a significant rotational position error at the bucket.
  • Page 68 For this example, the equation looks like this: ------ - -------------------------- - – 0.15 0.03 4. In 3DMC, navigate to the Excavator Antenna Mounting screen in the machine builder. Reduce the Aux antenna-to-boom pivot by 0.045 Ft. X63/X62 Installation and Calibration Manual...
  • Page 69 Verifying Aux Antenna to Boom Length 5. Repeat steps 1 to 6 on page 4-7 to verify the correction. There should be no difference between the 3DMC and Rover eastings. Figure 4-8. “Rotate” Aux Antenna on Body P/N 7010-0697...
  • Page 70 (e.g. 520.51). 13. To determine the error when extended, subtract the smaller number from the larger number. 14. Plot the Easting lines. Two Positions Over Same Hub Facing North Then South X63/X62 Installation and Calibration Manual 4-10...
  • Page 71 Verifying Aux Antenna to Boom Length • If the Extended position is larger, rotate (decrease) the machine position in 3DMC center-wise. • If the Curled In position is larger, rotate (increase) the Curled In machine position in 3DMC outwards. Table 4-2. Error in Length Measurement Curled In Extended 0.24...

  • Page 72: Verifying The Main Antenna

    520.38 520.35 0.03 • The difference in extended positions is – 520.51 520.48 0.03 7. Plot the Easting lines to show the offset error between Rover and 3DMC is constant when curled or extended. X63/X62 Installation and Calibration Manual 4-12...
  • Page 73 Verifying the Main Antenna • If the Rover Eastings are larger, the position of the machine needs to move East (increase) (Table 4-3 on page 4-13). • If the 3DMC Easting are larger, the position of the machine needs to move West (decrease). Table 4-3.
  • Page 74 (e.g. 520.46). 13. To determine the error when extended, subtract the smaller Two Positions Over Same number from the larger number Hub Facing North Then South (Table 4-4 on page 4-15). X63/X62 Installation and Calibration Manual 4-14...
  • Page 75 Verifying the Main Antenna Plotting the Easting lines shows that the Delta offset error between facing North and South is a constant when curled or Curled In extended (Table 4-4). Table 4-4. Error in Length Measurement Curled In Extended Facing N 520.39 520.40 Facing S...

  • Page 76: Verifying Main Antenna Height

    3DMC. • If the reported average elevations of 3DMC are lower than a survey rover, decrease the antenna height value in 3DMC (Figure 4-11). Figure 4-11. Adjust Main Antenna Height X63/X62 Installation and Calibration Manual 4-16...

  • Page 77: Verifying Aux Antenna Height

    Verifying Aux Antenna Height Verifying Aux Antenna Height This value is not critical to measuring elevation, so verifying is not required. Figure 4-12. Aux Antenna Height Verifying Boom Pivot Height The height of the boom pivot simply allows 3DMC to create a more accurate representation of the machine in the software’s graphics.
  • Page 78 Verifying X63/X62 Setup Notes: X63/X62 Installation and Calibration Manual 4-18...

  • Page 79: Ls-B10W Laser Receiver Setup

    LS-B10W Laser Receiver Setup The LS-B10W Laser Receiver adds a laser height reference to the X62/X63 system. The LS-B10W is calibrated for its location on the stick of the excavator. LS-B10W Mounting The LS-B10W laser receiver and bracket must be mounted on the left side of the stick.
  • Page 80 LS-B10W Laser Receiver Setup Remove the backing from the double sided tape and mount the bracket onto the stick as shown in Figure 5-1.. LS-B10W Bracket (horizontal) Figure 5-1. LS-B10W Mounting 3. Install the LS-B10W onto the bracket. X63/X62 Installation and Calibration Manual...

  • Page 81: Ls-B10W Calibration

    0.0° roll. 2. Orient the stick so that the LS-B10W is positioned vertically. 3. In 3DMC, tap Topcon LogoControlMachine setup. Select the applicable machine file for the job and press Edit. Press Next to navigate to the Laser Receiver (LSB10W) screen.
  • Page 82 Calibrate to determine the angle between the stick and the LS-B10W (Figure 5-3 on page 5-4). Figure 5-3. LS-B10W Laser Receiver Measurements If the stick sensor is replaced with a new tilt sensor, NOTICE you must recalibrate the LS-B10W laser receiver. X63/X62 Installation and Calibration Manual...

  • Page 83: Ls-B10W Test

    LS-B10W Test LS-B10W Test Performing a LS-B10W laser receiver test verifies the accuracy of the laser receiver on the machine. The Zero to Laser function becomes active in 3DMC when the laser receiver receives a laser signal. 1. Start 3DMC. 2.
  • Page 84 10. Place the bucket teeth on the bucket laser reference line and check that the cut/fill value on the main screen is close to 0.00. 11. Repeat steps seven to ten at various points along the reference line. X63/X62 Installation and Calibration Manual...

  • Page 85: Full System Test

    Chapter 6 Full System Test Performing a full system test verifies the accuracy of the X63/X62 system at various machine positions. If a hub with a known position is available, use it to measure the positions below. Testing Machine Element...
  • Page 86 If a hub with a known position is available use those coordinates as the reference. Otherwise, use the first position as a reference. Compare each position to the reference. The difference should be within ± 0.2Ft. X63/X62 Installation and Calibration Manual...
  • Page 87 Testing Machine Element Sensors for Accuracy P/N 7010-0697...

  • Page 88: Testing Machine Body Sensor For Accuracy

    4. Record the new position. Then subtract the two positions from each other. The difference between positions should be within +/- 0.2Ft. Machine on Cross Slope Position 1 Position 2 Differences X63/X62 Installation and Calibration Manual...
  • Page 89 Testing Machine Body Sensor for Accuracy Machine on 5% cross Position Position Position Position Figure 6-1. Check Cross Slope Accuracy P/N 7010-0697...
  • Page 90 Full System Test Notes: X63/X62 Installation and Calibration Manual...
  • Page 92 Topcon Positioning Systems, Inc. 7400 National Drive, Livermore, CA 94550 800∙443∙4567 www.topconpositioning.com ISO 9001:2000 FM 68448 X63/X62 Installation and Calibration Manual P/N: 7010-0697 Rev C ©201 Topcon Positioning Systems,Inc. All rights reserved. No unauthorized duplication.

This manual is also suitable for:
