Acer Aspire G7750 Series Service Manual page 97

ITEM
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
Chapter 6
PART NO. PART NAME
1 60.3V218.002 ASSY BRKT REAR BRACKET AG900
2 86.00J10.A60 SCREW M 6-32 L20 BZN
3 23.10240.001 FAN 7150 BUMBLEBEE ANNIE HDD
4 33.3V207.001 BRKT LINKBAR UP BRACKET AG900
5 54.13042.001 FRONT I/O BOARD YADB001-GP
6 33.3V209.001 BRKT FRONT IO BRACKET AG900
7 86.00E66.D60 SCRW PAN M 6-32 L5 BZN
8 42.3V218.001 CVR FRONT IO COVER AG900
9 60.3V208.001 ASSY TOP COVER AG900
60.3V212.001 ASSY BRKT R-SIDE BRACKET AG900
60.3V207.001 ASSY SIDE COVER RIGHT AG900
42.3V203.001 HINGE FRONT COVER RIGHT 1
42.3V204.001 HINGE FRONT COVER RIGHT 2
33.3V205.001 AG900-BKT-MB-BRACKET
50.3V203.001 C.A. LED SWITCH CABLE
42.3V229.001 HOLDER POWER KNOB AG900
42.3V223.001 LENS POWER AG900
42.3V222.001 KNOB POWER AG900
42.3V224.001 KNOB ODD AG900
42.3V226.001 DOOR ODD RIGHT AG900
42.3V225.001 DOOR ODD LEFT AG900
60.3V210.001 ASSY FRONT COVER AG900
60.3V220.001 ASSY HDD DOOR AG900
42.3V201.001 LBL CARD READER LABEL
60.3V209.001 ASSY FRONT BEZEL AG900
60.3V217.001 ASSY HDD CARRIER SATA AG900
60.3V216.001 ASSY BRKT 4HSP HDD CAGE AG900
60.3V204.001 ASSY FRONT STAND AG900
33.3V203.001 BRKT FRONT LOWER SIDE BRACKET
60.3V205.001 ASSY STAND BACK AG900
42.3V230.001 HOLDER SUPPORT VGA AG900
42.3V201.001 HINGE FRONT COVER LEFT 1
42.3V202.001 HINGE FRONT COVER LEFT 2
60.3V206.001 ASSY SIDE COVER LEFT AG900
60.3V213.001 ASSY BRKT L-SIDE BRACKET AG900
42.3V231.001 HOLDER FAN DUCK UP AG900
60.3V215.001 ASSY BRKT HDD BRACKET AG900
60.3V214.001 ASSY BRKT ODD CAGE AG900
#
#
QTY
1
4
1
2
1
1
4
1
4
1
1
1
1
1
1
1
1
1
2
2
2
1
1
1
1
4
1
1
1
1
1
1
1
1
1
1
1
1
91
