System Tour

Features

Below is a brief summary of the computer's many feature:
NOTE: The feature listed in this section is for your reference only. The exact configuration of the server
depends on the model purchased.
Processor
Intel core i7 processor Extreme Edition (up to 1600 MHz FSB)
•
Intel core i7 processor
•
Chipset
North bridge: Intel X58 chipset
•
South bridge: Intel ICH10R chipset
•

Memory subsystem

up to 12GB of DDR3 DIMMS supports DDR3-800/1066 MHz SDRAM
•
Supports 3 channels on six DIMMs
•

Media storage

Two 5.25" drive bays
•
BD+SuperMulti burner
•
BD/HD DVD reader + SuperMulti DVD burner
•
Super-Multi DVD drive (with Labelflash technology)
•
Four 3.5" easy-swap HDD drive bays
•
4 HDD cage
•
Easy-swap HDD cage with hot-swap
•
Networking
Gigabit Ethernet, Wake-on LAN ready (dual LAN support)
•
Modem: 56K ITU V.92, Wake-on Ring ready
•
PCI I/O
Three PCI Express x16 slot (one full x16 slot, two x8 refitted to x16 size)
•
Two PCI Express x1 slots
•
PCI Express x8 slots
•
PCI slot supports 2.3V/5V PCI bus
•
Graphics
Enabled ATI CrossFireX(TM)
•
2x PCI Express 2.0 x 16 graphics card support
•
