Removing the Card Reader Board

1. See "Removing the Bezel Door" on page 31.
2. See "Removing the Left Side Panel" on page 34.
3. See "Removing the Front Bezel" on page 36.
4. See "Removing the Card Reader Drive" on page 42.
5. Place the module on a clean, static-free surface.
6. Remove the two screws (B) that secure the cover to the carrier.
Screw (Quantity)
Card reader carrier screw (2)
7. Disconnect the USB cable from the card reader board.
44
Color
Silver
Torque
N/A
Part No.
N/A
Chapter 3
