Acer Aspire G7750 Series Service Manual page 41

4. Pull the carrier out of the drive bay.
5. Place the HDD carrier on a clean, static-free network surface.
6. If you are replacing a hard disk, remove the four screws (A) that secure the hard disk to the carrier.
Screw (Quantity)
HDD carrier screw (4)
7. Remove the disk from the carrier.
8. Keep the screws for later installation.
Chapter 3
Color
Silver 3.5 to 4.5 kgf-cm
Torque Part No.
N/A
33
