DVMT 5.0 technology support.
•
Enhanced 3D and Clear Video technology support.
•
Need to measure VGA follow Acer VGA SOP.
•
PCEx16 socket must with latch and afford the weight of any VGA card.
•
Monitor compatible is requested to the monitor AVL and DQM recommended list.
•

Hard disk drive

Support up to four SATA ports.
•
3.5",25.4mm.
•
Capacity and models are listed on AVLC.
•

Optical disk drive

Support up to two SATA 5.25" standard ODD.
•
Support DVD-ROM, DVD-SuperMulti, BD-combo, BD-rewrite.
•
Maximum ODD depth to 185mm with bezel.
•
Models are listed on AVLC.
•

Graphics card

One PCI-E x 16 graphics card.
•
No mechanical retriction to support for double slot, full length graphics cards in the single PCIe X16 slot.
•
Audio
ALC662
•
Rear IO: 3 jack
•
Front IO: 1*Microphone-in, 1*head phone jack
•

Serial ATA controller

Slot Type: SATA connector.
•
SATA ports quantity: 6(2* SATA 6Gb/s, 4* SATA3Gb/s. different color to identify SATA 6Gb/s and SATA
•
3Gb/s).
Design requiremnt:
•
Blue Ray ODD.
•
AHCI/RAID mode supported for internal SATA port.
•
LAN
Controller: Realtek RTL8111E.
•
Extension slot
1 * PCIE x16 (PCIE V2.0)
•
3 * PCIE x1 (PCIE V2.0)
•

USB ports

Supports at least 12 USB ports on both front and rear side.
•
H67 at least 6 ports located on rear panel and others located on front bezel and top bezel.
•
All USB ports must be boot-capable includes USB-ODD, USB-HDD, USB-FDD, and etc...
•
All USB ports must be 2.0 certified.
•
