LSW-010-001-002
Spot / Flood Tungsten Fresnel Light with Barn Doors
LSW-010 What's Included
1 x 150 Watt Light Fixture
1 x Set of Barn Doors
1 x Gel Frame
LSW-001 What's Included
1 x 300 Watt Light Fixture
1 x Set of Barn Doors
1 x Gel Frame
LSW-002 What's Included
1 x 650 Watt Light Fixture
1 x Set of Barn Doors
1 x Gel Frame
www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com
Quick Start Guide
CHECKED BY
because we're filmmakers too
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Ikan LSW-010
Summary of Contents for Ikan LSW-010
- Page 1 Quick Start Guide LSW-010-001-002 Spot / Flood Tungsten Fresnel Light with Barn Doors LSW-010 What’s Included 1 x 150 Watt Light Fixture 1 x Set of Barn Doors 1 x Gel Frame LSW-001 What’s Included 1 x 300 Watt Light Fixture...
- Page 2 Inserting Accessories Inserting and exchanging accessories must be carried out from a stable position. On the LSW-010, lift the top latch and turn it by 90° to the left. On the LSW-001 and LSW-002 press the pin on the side of the holding bracket to release the spring. Insert accessories e.g. barn door, or scrim into the bracket.
- Page 3 Lightstar Disclaimer The manufacturer disclaims liability for any damage to persons or property caused by inappropriate or misuse of the fixture. Damage of this kind is responsibility of the operator. Specifications & Photometrics LSW-010 Specs Head Type 3200K Rating AC Volts 120 v ac, 50-60Hrz...
- Page 4 Specifications & Photometrics LSW-001 Specs Head Type 3200K Rating AC Volts 120V AC, 50-60Hrz Light Source 1-300 Watt Bulb Power Supply 6 ft Power Cable Dimming Control Focusing Knob Lens 3.1 In. Fresnel Lens Focusing Rotating Rear Knob Beam Angle 14-53º...
- Page 5 Damage caused by abuse or misuse, dismantling, or changes to the product not made by the company. • Damage caused by natural disaster, abnormal voltage, and environmental factors, etc. ©2017 ikan Corporation. All rights reserved because we’re filmmakers too www.ikancorp.com | 1.713.272.8822 | sales@ikancorp.com...
