STEP 11
13
position against wall
mark position of strap hole on wall
drill 1/4" hole
tap in wall anchor
NOT TO SCALE. REFER TO PAGE 3 FOR ACTUAL SIZE HARDWARE.
x 1
x 1
1 3 . W a l l
1 6 . W a l l
A n c h o r
S c r e w
14
12
15
x 1
1 5 . T r u s s
H e a d S c r e w
16
12
fasten anti-tip strap with wall
screw provided
x 1
1 4 . W a l l
S t r a p
x 2
1 2 . W a s h e r
17
