Type No. L22C0E081
Model. W242D
Multi Function Wide Monitor
User's Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the W242D and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Hyundai W242D

Summary of Contents for Hyundai W242D

  • Page 1 NEXT Type No. L22C0E081 Model. W242D Multi Function Wide Monitor User’s Guide...
  • Page 2 U.S.A. U.S.FEDERAL COMMUNICATIONS COMMISSION RADIO FREQUENCY INTERFERENCE STATEMENT INFORMATION TO THE USER NOTE : This equipment has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 3: Safety Information

    1. Introduction This manual contains instructions for installing and operating HYUNDAI IT CORP. HYUNDAI IT CORP. This is a highly ergonomic color display unit. • 24” viewable WUXGA LCD • High quality screen re-scaling capability • 100-240V AC input voltage •...
  • Page 4 Avoid operating the monitor in extreme heat, humidity or areas affected by dust. Temperature : 5~40°C Humidity : 30~80RH Be sure to turn the monitor off before plugging the power cord into the socket. Make sure that the power cord and the other cords are securely and rightly connected.

  • Page 5: Cleaning And Maintenance

    Cleaning and Maintenance • To avoid to risk of electric shock, do not disassemble the Cabinet of display Unit. The Cabinet is not user-serviceable. Remember to unplug the display unit from the power outlet before cleaning. • Do not use alcohol (methyl, ethyl or isopropyl) or any strong dissolvent. Do not use thinner or benzene, abrasive cleaners or compressed air.
  • Page 6 3. Installing the The following items should be found in the packaging. monitor 3-1. Packing List Power Cord Japan Signal Cable America/Canada Europe DVI Cable South Africa Australia Audio Cable Compact Disc Korea Above power cord can be changed upon different voltage areas. Please contact your dealer if anything is missing or damaged.

  • Page 7: Selecting A Suitable Location

    3-2. Selecting a suitable location • Place the monitor at least 30cm from other electrical or heat-emitting equipment and allow at least 10cm on each side for ventilation. • Place the monitor in a position where no light shines directly onto or is reflected on the screen.

  • Page 8: Audio System

    • Audio system This monitor has an audio system including two micro loudspeakers. Each of two micro loudspeakers has an 3W(max.) output power. This system also supports a headphone output jack. This system has been tuned to get a best tone quality which an audio input level is under 500mv rms.

  • Page 9: Setting The Refresh Rate

    3-4. Setting the refresh Follow the instructions below to set your refresh rate in Windows 98/ME/XP/2000. rate Go to the configuration window(Start-Settings-Configuration window). Double click on the ‘Display’ icon. Click on the ‘Settings’ tab. Click on the ‘Advanced’ button. Click on ‘Adapter’ and select 60Hz from the list. Click on ‘Apply’...
  • Page 10 Preset Timing Table If the signal from the system doesn't equal to the preset timing mode, adjust the mode with reference to the user guide of videocard because the screen may not be displayed. Supported Mode Resolution V-Freq.(hz) H-Freq.(Khz) Analog 640 X 350 70.0 31.4...
  • Page 11 W240D Multi Function Wide Monitor 3-6. User’s Environment Recommended Ergonomic User’s Environment • Viewing angle of the monitor should be between -3~17 degree. 11/23...
  • Page 12 W240D Multi Function Wide Monitor Kensington Security • This display unit supports a Kensington-type security device to secure your (Locking) Slot monitor. Kensington lock is not included. • To purchase and install the Kensington locking device, please refer to the following contact information.

  • Page 13: Adjusting The Picture

    4. Adjusting the picture You can adjust the screen display by using the buttons located below the screen. The second Menu from the OSD can't be chosen in digital-mode. 13/23...

  • Page 14: Using The On-Screen Display

    4-1. Using the On Screen To make adjustments in the On Screen Display, follow these steps: Display Push the MENU button to call the OSD to the screen. Push the button to choose the item you want to adjust. The selected item is highlighted.

  • Page 15: Osd Adjustments

    4-3. OSD Adjustments • Picture BRIGHTNESS To adjust the brightness of the screen. CONTRAST To adjust the contrast of the screen. H.POSITION To move image left and right. V.POSITION To move image up and down CLOCK To adjust the horizontal size of the entire screen image. HDMI MODE BRIGHTNESS To adjust the brightness of the screen.

  • Page 16: Auto Color

    PC ANALOG • Color STANDARD For general Color tone. REDISH For Redish color with warm tone. BLUISH For Bluish color with cool tone. USER For adjusting degree of RGB as User wants AUTO COLOR TO adjust the horizontal size of the entire screen image. HDMI MODE STANDARD For general Color tone.

  • Page 17: Osd Configuration

    • Sound VOLUME To adjust the audio volume level. BASE To emphasize low frequency audio. TREBLE To empahsize high frequency audio. BALANCE To use this function to balance sound from the left and right speakers. MUTE Audio ON or OFF •...

  • Page 18: Display Control

    DISPLAY CONTROL If you choose DISP. CONTROL on the OSD menu, you can adjust the following <PC> - Full (16:10) : Shows full screen regardless of screen size. - 4:3 : Displays image at 4:3 ratio. <HDMI Mode> - Full (16:10) : Shows full screen regardless of screen size. - 16 : 9 : Displays image at 16:9 ratio.

  • Page 19: Display Power Management

    If the power management function of your computer is enabled, your monitor 5. Display power turns on and off automatically. You can control power management features from management your computer. Your computer may have power management features which enable the computer or monitor to enter a power saving mode when the system is idle.

  • Page 20: Troubleshooting

    6. Troubleshooting If your monitor is not functioning properly, you may be able to solve the problem by following the suggestions below : Problem Possible solution Blank screen If the power LED is not lit, push the Soft power switch or check the AC cord to turn the monitor on.
  • Page 21 Problem Possible solution Color defects Check that the signal cable connector is properly connected and that the connection pins are not bent or damaged. Try another color temperature. Size, position, Adjust the picture characteristics as described in the section shape or quality Adjustment(4-3).

  • Page 22: Contacting Service

    Problem Possible solution The power LED is LED Indicator can be orange color on changing of video mode or a orange color Input Signal. Check the Resolution and the frequency on the video part of your computer. Compare these values with the data in the Preset Timing Table.

  • Page 23: Specifications

    TUV-GS, CB, FCC, CE, VCCI, GOST Operating Temperature 5 ~ 40 Weight Dimensions (W X H X D mm) • Specification is subject to change without notice. • HYUNDAI IT CORP. specification on “dead pixel” of LCD Panel applies to ISO 13406-2 Standard. 23/23...
