Chapter 1
LED Explanation
Name
Button Description
Name
(WPS Button)
(Wi-Fi Button)
(LED Button)
1. 2. 2.

The Side and Back Panel

Status
Pulsing
The system is starting up
orange
Solid white
The router is working normally.
on
Red No internet connection.
Orange The router is connected to the internet, but the Wi-Fi is off.
The firmware is being upgraded, WPS connection is being
Pulsing
established or the router is being reset. Do not disconnect or
white
power off your router.
Off Power is off or the LED is turned off.
Press this WPS button, and immediately press the WPS button on your client
device. The LED of the router should change from pulsing white to solid on,
indicating successful WPS connection.
Press the Wi-Fi button to turn on or off the wireless function of your router.
Press the LED button to turn on or off the LEDs of your router.
Get to Know About Your Router
Indication
Description
4
