Settings Menu

Select TIME/DATE on Home Interface to enter into TIME/DATE SET interface as follow:
Enter settings menu (needs to be added)
1. Under Home Interface, meanwhile the device is at OFF mode (Off icon), press and hold up and down buttons at the
same time for over 5 seconds to enter Settings Menu.
2. Short press move up and down button to select a settings item, then short press button F to enter selected item.
3. Settings menu include, Preview menu, Z-Wave settings, Schedule, Monitor settings, Time/Date settings, Other settings

Time Setting

Select TIME/DATE on Home Interface to enter into TIME/DATE SET interface as follow:
2. Preview interface
On Home Interface, user can enter into PREVIEW
consumption, date, floor temperature etc.

Control Mode

Short press button on Home Interface to switch operation modes: the icons of Away, Auto, Manual, Drying, Off modes
will be displayed alternatively for 3 seconds and last displayed mode will be selected, or just short press
a desired mode when the modes' icon displayed alternatively. Press and hold
seconds to select Away mode directly, then Press and hold
1.Away Mode: the device will control the heating system according to the set temperature within the set period.
User can set time to leave home and time to go home according to the requirements of themselves, and set how the
device will control the temperature during this period.
1.1. If away mode has already been activated, the end time for away mode is valid, the device will execute Away Mode
Temperature Schedule before the end time.
1.2. If away mode has already been activated, the values of end time for away mode are set as 0, the device will always
execute current set temperature with no time limitation. The device will consider the mode as anti- freeze mode, the
recommended temperature setting is 4-10°C.
2. Auto Mode: the device will control the heating system according to the configured time schedule or Z-Wave protocol
Energy_Save_Heating Setpoint.
2.1. When configuration parameter 8 value set as 1, the device will control the temperature of energy save mode accord-
ing to the temperature set by Command Class Energy_Save_Heating Setpoint or set by using the move up and down
buttons, following mentioned schedule will be invalid.
2.2. When configuration parameter 8 value set as 0, the temperature set by Command Class Energy_Save_Heating
Setpoint and set by using the move up and move down buttons will both be invalid, Energy Save Mode will control
temperature according to following user schedule.
For instance, if user would like to keep room temperature at 18C during 18:00-23:00 on every Monday, and keep room
temperature at 20C after 22:30 on every Monday, then user can set schedule by himself.
Short press button to select the item you would like to modify, then short press up and
down buttons to modify value of selected item, then short press button
short pressing button
interface, the interface will display some basic configurations, energy
only quits without saving.
button for 3 seconds to quit Away mode.
F
to save and quit,
F
button on Home interface for over 3
button to select
