XPAND UP
Height Adjustable 90 Degree Station– Assembly
Instructions
Tools Required
Cordless Drill
Philips bit with extension
for Work Surface screws
(XP-Screw-WS)
3/16 Hex drive bit
for XP-Screws
Measuring Tape
Level
Rubber Mallet
For additional assembly support, refer to www.openplan.com
or contact 844.OPS.OPS1
www.openplan.com | 844.OPS.OPS1 | sales@openplan.com
Advertisement
Related Manuals for Openplan Systems XPAND UP
Summary of Contents for Openplan Systems XPAND UP
- Page 1 XPAND UP Height Adjustable 90 Degree Station– Assembly Instructions Tools Required Cordless Drill Philips bit with extension for Work Surface screws (XP-Screw-WS) 3/16 Hex drive bit for XP-Screws Measuring Tape Level Rubber Mallet For additional assembly support, refer to www.openplan.com or contact 844.OPS.OPS1...
- Page 2 XPand UP – Height Adjustable- 90 Degree Station XPand Parts Used for Assembly Item Part name Part Image Item Part name Part Image Description Description Legs for XP-HA- XP-HA-Base, leg XP-CTC Cable Tray Clip Base Stretcher Bar Cable Tray XP-SB-Bracket...
- Page 3 XPand UP – Height Adjustable- 90 Degree Station Step 1: Prepare a large floor space to put the XPand order together. Unpack the parts and check to see if all the XPand parts are present as per the sales order pick list.
- Page 4 XPand UP – Height Adjustable- 90 Degree Station Step 5: Assemble the Stretcher Bar (XP-SB-XX) to the Step 6: Repeat Step 2 to Step 4 to build an End leg Assembly Stretcher Bar Bracket (XP-SB-Bracket) using (3) XP-Screws and assemble the other end of the Stretcher Bar to the Stretcher per Stretcher Bar.
- Page 5 XPand UP – Height Adjustable- 90 Degree Station Holes on the Link should be facing the Returns or facing away from the center Figure B Step 8: Assemble the 21” Link to the Link-Bracket using (4) XP-Screws per Bracket. Note: While Assembling the Links make sure the Holes are facing away from the center (as shown in the picture).
- Page 6 XPand UP – Height Adjustable- 90 Degree Station Step 10: Repeat Step 2 to Step 5 twice to build (2) Return Height Adjustable Stations and assemble XP-SB-Bracket to the Stretcher bars using (2) XP-Screws per Bracket. Step 11: Assemble the XP-SB-Brackets to the 21” Link...
- Page 7 XPand UP – Height Adjustable- 90 Degree Station Step 12: Slide (4) Cable Tray Clips onto each cable tray and Snap on the assembled cable tray clips to the Stretcher bar. Note: Assemble (2) XP-CTA-30 on XP-HA-SB-72 Stretcher Bar, (2) XP-CTA-18 on XP-HA-SB-60 Stretcher Bar and (1) CTA-18 onto the 21”...
- Page 8 XPand UP – Height Adjustable- 90 Degree Station Figure D Step 14: Place the Screen Brackets (XP-SB-HA) in flush with the (6) Leg Rails and (2) 21” Links (as shown in the picture), do not tighten them. Slide in the Cable Tray Covers (XP-CTCXX) over the Screen Brackets.
- Page 9 XPand UP – Height Adjustable- 90 Degree Station Step 16: Place the Work Surface (CCWSXXXXXX) on the frame. Center the Work Surface to the Screen and secure the Work Surface to the Frame using (12) XP-Screw-WS per each Work Surface.
