Assembly Instructions & User's Manual
for
Member's Mark Outdoor Gas Griddle
Item Number: 980167856 / 980169672 / 980014462
Model Number: GR2298901-MM-02 / GR2298906-MM-01
Customer Assistance
: 1-888-837-1380
(spare/replacement parts)
or Email: customerservice@rankam.com
THIS ASSEMBLY MANUAL CONTAINS INPORTANT SAFETY INFORMATION.
PLEASE READ AND KEEP FOR FUTURE REFERENCE.
1 |
P a g e
Advertisement
Table of Contents
Related Manuals for Rankam Member's Mark GR2298906-MM-01
Summary of Contents for Rankam Member's Mark GR2298906-MM-01
- Page 1 Member’s Mark Outdoor Gas Griddle Item Number: 980167856 / 980169672 / 980014462 Model Number: GR2298901-MM-02 / GR2298906-MM-01 Customer Assistance : 1-888-837-1380 (spare/replacement parts) or Email: customerservice@rankam.com THIS ASSEMBLY MANUAL CONTAINS INPORTANT SAFETY INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE. P a g e...
-
Page 2: Table Of Contents
Table of Contents Quality Statement ..........................3 Important Safety Information ......................3 Before Assembly ............................ 3 Care & Use ............................3-6 Package Contents ..........................7-8 Product Information ..........................8 Components ............................9-11 Hardware ..............................12 Tools ............................... 12 Step 1 – Step 16 ..........................13-20 Warning .......................... -
Page 3: Quality Statement
Quality Statement Important Safety Information Please read all instructions carefully before assembling this product. Where applicable, and for your safety, assembly by an adult is strongly recommended. Use only vendor-supplied hardware to assemble this item. Using unauthorized hardware could jeopardize the structural integrity of the item. - Page 4 USE AND INSTALLATION OF LP GAS CYLINDER (PROPANE TANK) BEFORE INSTALLING: The installation must conform with local codes or (in the absence of local codes) with either the National Fuel Gas Code, ANSI Z223.1/NFPA 54, Natural Gas and Propane Installation Code, CSA B149.1, or Propane Storage and Handling Code, B149.2, or the Standard for Recreational Vehicles, ANSI A 119.2/NFPA 1192, and CSA Z240 RV Series, Recreational Vehicle Code, as applicable.
- Page 5 INSTALLING GAS CYLINDER 1. Check that the cylinder valve is closed by turning the knob in clockwise. 2. Place cylinder into tank holder in bottom cabinet. 3. Place cylinder such that the valve opening faces the right side table in such a way that the hose is not kinked/damaged.
- Page 6 CONNECTION PROCEDURES 1. Make sure the tank valve is closed (turn valve clockwise until tight). 2. Check the tank valve to ensure it has the proper external male threads. 3. Make sure all burner valves are turned OFF. 4. Inspect valve connections, port, and regulator assembly.
-
Page 7: Package Contents
Package Contents P a g e... -
Page 8: Product Information
Component Description Quantity Component Description Quantity Hook Left Cart Beam Side Table Handle Right Cart Beam Griddle Right Rear Leg Side Table Locking Caster Side Table Left Tank Holder Bracket Side Table Right Tank Hook Bracket Griddle Adjustor Right Front Leg Grease Drip Tube Cart Base Left Rear Leg... -
Page 9: Components
Components Component 1 Component 2 Component 3 Hook Side Table Handle Griddle Part No. MET-4B0014 Part No. MET-4B0015 Part No. MET-4B0016 Qty 3 Qty 2 Qty 1 Component 4 Component 5 Component 6 Side Table Side Table Left Bracket Side Table Right Bracket Part No. - Page 10 Component 10d Component 10e Component 10f Grill Body – Valve & Manifold Grill Body – Control Panel Grill Body – Control Knob Assembly Part No. MET-4B0025 Bezel Part No. GAS-4B0003 Qty 1 Part No. PLA-4B0002 Qty 1 Qty 4 Component 10g Component 10h Component 10i Grill Body –...
- Page 11 Component 15 Component 16 Component 17 Locking Caster Tank Holder Tank Hook Part No. HAR-4B0001 Part No. MET-4B0031 Part No. MET-4B0032 Qty 2 Qty 1 Qty 1 Component 18 Component 19 Component 20 Right Front Leg Cart Base Front/Rear Cart Beam Part No.
-
Page 12: Hardware
Hardware Phillips Head Bolt, M6x12mm, Item No. A Qty: 58 Tools Phillips Head Screwdriver (Not included) Adjustable Wrench (Not included) Symbol: The following symbols will be shown in each procedure for indication of tightening the bolt and nut if necessary. Hand tighten or use the tools but not fully tighten at this time Tighten with tools at this time... -
Page 13: Step 1 - Step 16
Step 1 – Step 16 Step 1. Attach the Right Front & Rear Legs (18 & 14) to the Right Cart Beam (13) and the Tank Holder Supporting Beam (21) using 6pcs M6x12 Bolts (A). Remark: Please remind the holes position of the beams (13 & 21) as shown below. Step 2. - Page 14 Step 3. Attach the left and right leg assemblies to the Front / Rear Cart Beam (20) using 8pcs M6x12 Bolts (A). Step 4. Attach the Cart Base (19) to the cart assembly using 12pcs M6x12 Bolts (A). 14 | P a g e...
- Page 15 Step 5. Attach the Locking Casters (15) and tighten them to the right legs as shown. Step 6. Make sure that all the legs, beams and cart base are aligned then fully tighten all the bolts on the cart assembly. 15 | P a g e...
- Page 16 Step 7. Attach the Tank Holder (16) and the Tank Hook (17) to the cart assembly using 4pcs M6x12 Bolts (A). Fully tighten the bolts. Step 8. This step needs two people to complete! Attach the Grill Body Assembly (10) to the cart assembly using 4pcs M6x12 Bolts (A) and fully tighten the bolts.
- Page 17 Step 9. Attach the Side Table Left & Right Brackets (5 & 6) to the Side Table (4) using 4pcs M6x12 Bolts (A) as shown below. Attach the Side Table Handle (2) and the Hooks (1) to the Side Table (4) using 2pcs M6x12 Bolts (A). Tighten all the bolts. Step 10.
- Page 18 Step 11. Attach the Side Table Left & Right Brackets (5 & 6) and the Side Table Handle (2) to the Side Table (4) using 6pcs M6x12 Bolts (A). Tighten all the bolts. Step 12. Attach the right side table assembly to the grill body using 4pcs M6x12 Bolts (A) and tighten all the bolts.
- Page 19 Step 13. Attach the Grease Drip Tube (8) to the grill body using 2pcs M6x12 Bolts (A) and tighten all the bolts. Step 14. Attach the Griddle Adjustor (7) to the Griddle (3) as shown. 19 | P a g e...
- Page 20 Step 15. This step needs two people to complete! Place the griddle on the grill as shown. You can adjust the height of griddle by rotating the griddle adjustor. Step 16. Your unit is fully assembled! Make sure to read and follow the Instruction Manual before operating this appliance.
-
Page 21: Warning
Warning PROP 65 WARNING WARNING: This product can expose you to chemicals including benzene, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov. WARNING This outdoor cooking gas appliance shall be used only outdoors and shall not be used in a building, garage or any other enclosed area. - Page 22 The appliance is for household use only. DO NOT use this grill for other than its intended purpose. Never use natural gas in a unit designed for liquid propane gas. Never use charcoal or wood briquettes in a gas grill. Flavoring chips must be contained in a metal smoking box to contain ash and prevent fires.
- Page 23 LEAK TEST Although all gas connections on the grill are leak tested at the factory prior to shipment, a complete gas tightness check must be performed after assembly to ensure fittings were not damaged after leaving the factory. Periodically check the entire system for leaks following the procedures listed below.
- Page 24 5. Should gas continue to leak from any of the fittings, turn off the gas supply and contact customer service department at 1-888-837-1380, 8 a.m. - 5 p.m., Pacific Standard Time, Monday - Friday. BEFORE LIGHTING WARNING Inspect the gas supply hose prior to turning the gas ON. ...
-
Page 25: Danger
Danger DANGER (a) Do not store a spare LP gas cylinder under or near this appliance; (b) Never fill the cylinder beyond 80 percent full; (c) If the information in (a) and (b) is not followed exactly, a fire causing death or serious injury may occur. -
Page 26: Troubleshooting
Troubleshooting Problem Possible Cause Prevention / Solution Burner Will Not Light 1. LP cylinder fuel is used 1. Change a new, full LP cylinder. 2. Tip of electrode should be 2. Electrode tip not in pointing toward gas port opening proper position. -
Page 27: Care & Use Instructions
fully open. Light all burners and observe the temperature. Grill is Too Hot 1. Excess grease build-up 1. Refer to the section of “Maintenance and Cleaning causing grease fires. 2. Damaged or faulty instructions” on pg. 29-32 to regulator. clean the grill properly. 2. - Page 28 To turn burners off, turn the control knobs clockwise until they lock in the position LIGHTING INSTRUCTION: USE MATCH TO LIGHT BURNER Turn OFF all burner valves. Place a long lit match through lighting hole in the left hand side of the grill to approximately 1/2”...
- Page 29 MAINTENANCE & CLEANING INSTRUCTION CAUTION Keep cooking area clear and free from combustible materials, gasoline and other flammable vapors and liquids. Do not obstruct combustible and ventilation airflow. Keep the ventilation openings of the cylinder enclosure free and clear of debris. ...
- Page 30 BURNER CLEANING: Turn off the gas supply, and make sure all the knobs are in the OFF position. Wait for the grill to cool. Remove the griddle. Remove the burner fixing bolt and lift the burner out of the firebox. Clean the exterior of the burner with a brass brush.
- Page 31 TO REINSTALL THE MAIN BURNERS: 1. Insert the burner into the burner valve. 2. Firmly seat the valve connector into the burner tube. Make sure the valve orifice is inserted STRAIGHTLY into the burner tube as per below diagram. 3. Reinstall the carry over and tighten with the burner fixing bolt as shown. Step 2 Step 3 PROPERLY INSTALL THE BURNER...
-
Page 32: Technical Data
SEASONING THE GRIDDLE Seasoning is a process by which oil is baked into metal to create a stick-resistance surface and helps to prevent rusting. It can prolong the life of your griddle. First time use: Wash your griddle cooking surface with a mild dishwashing detergent. Rinse with hot water and dry completely with a soft cloth or paper towel. -
Page 33: Warranty Information
For assistance, contact customer service at customerservice@rankam.com or at 1-888-837-1380, Mon to Fri, 8:00am – 5:00pm Pacific Standard time Manufacturer information Rankam (China) Manufacturing Company Limited Address: 18/F, New Lee Wah Centre, 88 Tokwawan Road, Kowloon, Hong Kong. 33 | P a g e... - Page 34 NOTE: Please consider recycling all applicable packaging material. Distributed by Sam’s West Inc. 2101 SE Simple Savings Dr. Bentonville, Arkansas 72716-0745 Made in China Need Assistance? Visit us at: samsclub.com/membersmarkhelp 34 | P a g e...
Need help?
Do you have a question about the Member's Mark GR2298906-MM-01 and is the answer not in the manual?
Questions and answers
I have 2 of the 20's and I'm missing the part marked as 21 i can't complete assembly
The replacement part marked as 21 for the Rankam Member's Mark GR2298906-MM-01 is the Tank Holder Supporting Beam.
This answer is automatically generated
Part no. MET-4B0022 is missing out of my package
