OWNER'S MANUAL
3 8 " B O X S C R A P E R
4 2 " B O X S C R A P E R
MODEL:
B S - 3 8 1
B S - 3 8 1 - A
B S - 4 2 B H
B S - 4 2 B H - A
• Assembly
• Installation
• Operation
• Repair Parts
This implement is for use with garden tractors
equipped with sleeve hitch. Also, tire chains and
wheel weights are recommended.
Call Customer Service, Toll-Free: 877-728-8224
Visit us on the web!
www.brinly.com
Important: This manual contains information for the safety
of persons and property. Read it carefully before
assembly and operation of the equipment!
1
BS-381
BS-42BH
BS-381-A
BS-42BH-A
1019911-A
Advertisement
Related Manuals for Brinly BS-42BH
Summary of Contents for Brinly BS-42BH
- Page 1 B S - 4 2 B H B S - 4 2 B H - A • Assembly • Installation • Operation BS-381 BS-42BH • Repair Parts BS-381-A BS-42BH-A This implement is for use with garden tractors equipped with sleeve hitch. Also, tire chains and wheel weights are recommended.
-
Page 2: Table Of Contents
INTRODUCTION AND SAFETY ================================================================================================ CONGRATULATIONS on the purchase of your new Brinly-Hardy Box Scraper! Your product has been designed, engineered and manufactured to give you the best possible dependability and performance. Should you experience any problem you cannot easily remedy, please do not hesitate to contact our knowledgeable customer service department toll-free at 1-877-728-8224. -
Page 3: Parts
PARTS ================================================================================================ * 1019747 Included on some models. Ref # 1019988 Hardware Bag Ref # 1019988 Hardware Bag 10M1240P Bolt; Carriage, 3/8 x 2-1/2" 45M4440P Washer; SAE, Plain, 1-1/4 30M1200P Nut; Reg Hex, 3/8 - 16 B-1675P Nut; Hex Lock, 3/8"-16 30M1600P Nut;... - Page 4 PARTS: HARDWARE IDENTIFIER ================================================================================================ DO NOT RETURN PRODUCT IF YOU ARE MISSING PARTS. Illustrations on this page Please Call: 1 (877) 728-8224 are to scale for faster identification of hardware during assembly. Washer: Lock 3/8” (x10) ..40M1200P Washer: Flat 1-1/4”...
- Page 5 Pin; Linch, 5/16" Weight Support Drawbar 10M1220P Bolt; Carriage, 3/8 x 1-1/4" Bracket (x1) Assembly (x1) B-5344-10 B-4351-10 * 1019747 Included on model BS-42BH-A only. Hitch Assembly (x1) B-4265 Weight Mount Angling 38" Blade (x1) Bracket (x2) Lever (x1) B-4813-10...
-
Page 6: Assembly
These QR codes link directly to tractor the Box Scraper product pages. BS-381 BS-42BH BS-381-A BS-42BH-A right hand side Step 1 Align the Blade (3) with the Blade Mount Plate (7), as illustrated. On the inner curve of the blade, find the two TOP CENTER HOLES and run two 3/8"... - Page 7 ASSEMBLY ================================================================================================ Step 2 Align the Weight Mount Brackets (27). (V-Angle End next to Blade Mount Plate) to two Bottom Holes Blade and Blade Mount Plate. On the inner curve of the blade, find the two LOWER CENTER HOLES and run two 3/8" x 1-1/4"...
- Page 8 ASSEMBLY ================================================================================================ Step 4 Note: Slightly longer edge points up. Run two 1/2" x 1-1/4" Hex Bolts (11) through the hitch assembly and drawbar, as illustrated. Align the Hitch Assembly (9) with the Drawbar (10) as illustrated Add a Lock Washer (18) and nut (15) to here.
- Page 9 ASSEMBLY ================================================================================================ Step 5-B - Insert the 3/8" x 2-1/2" Carriage Bolt (13) through the remaining two holes (square) in the angling lever (4). - Secure with a 3/8" Hex Lock Nut (2). NOTE: Tighten the lock nut (2) just enough to remove any "looseness"...
- Page 10 ASSEMBLY ================================================================================================ Step 7 Align the Scarifier Bar Assembly (21), teeth points down and facing forward. Slide the bar ends through the slots of Side Plates (22) as shown. Secure in place by installing Linch Pins (24) through the holes on the end of the Scarifier Bar (21) as illustrated here.
-
Page 11: Operation
• When the Unit is not being used, remove all dirt, scale and Toll-Free: 877-728-8224 rust; then touch-up with paint. • Apply a coat of grease, oil or rust preventative to blade Chat online: www.brinly.com edge, scarifier and other areas that appear to have "scoured" from operation. Email: customerservice@brinly.com •... -
Page 12: Warranty
CONSEQUENTIAL OR INCIDENTAL DAMAGES OF ANY KIND. of receipt of the parts. This warranty does not apply to damage MADE IN U.S.A. Brinly-Hardy Company • 3230 Industrial Parkway • Jeffersonville, IN 47130 • (877) 728-8224 • brinly.com BS-381 BS-42BH BS-381-A...
