Blue Ridge JEEP JKU ATTIC Install Manual

Welcome! This installation isn't rocket science but it is kind of like karate - you can hurt yourself or break
something if you don't pay attention. Used properly, this Install Guide will tell you all you need to know
- like Yoda, but with better grammar.
If you have any trouble, contact us for product support: blueridgeoverlandgear.com/pages/contact-us

TOOLS YOU NEED: NONE

I N S T A L L G U I D E
FOR: JEEP JKU ATTIC
3"

STEP #1

Unroll the attic and loosen the 8 straps by
sliding the G-Hooks close to the ends of the
straps, but leave a 3" tail. These tails will be
used to tighten the attic later. Do not remove
the G-Hooks from these straps.

STEP #2

Lay the attic on the back of the seat and align
it so that the two curved corners face forward
and line up with the speakers on the rollbar
above. Make sure the paracord lacing is facing
downward.

STEP #3

Lift the attic and pass each of the 8 straps over
the top of the rollbars** and wrapping them
back under, attaching the G-Hooks back to the
flat loops on the attic*.
*Note: Do not attach the G-Hooks back to their straps.
They must be attached to the attic itself.
**Note: If you have trouble passing the straps over
the rollbars, we recommend removing the roof first.
GO TO NEXT PAGE >
p.1
