SLIDE OFF-DECK:
Instructions and Safety Tips
CAUTION - PUT SAFETY FIRST
1.
Before attempting to install or use this slide, study and fully understand the proper operating
procedures and safety precautions outlined in this owner's manual.
2.
NOT COMPLYING WITH THE PROCEDURES AND PRECAUTIONS OUTLINED IN THIS
MANUAL WILL INVALIDATE THE WARRANTY AND MAY RESULT IN PERSONAL INJURY OR
DEATH.
3.
If you have any questions about assembly, installation, use or suitability of this product, contact
an authorized dealer or ShoreMaster directly at 1-800-328-8945.
