INSTR,INSTL,AK-2 - LINEAR P/N: 218370 C - INK: BLACK - MATERIAL: 20 LB. MEAD BOND - SIZE: 8.500" X 11.000" - SCALE: 1-1 - FOLDING: ALBUM-FOLD - BINDING: SADDLE-STITCH
AK-2
Digital Keyless
Entry System
Installation and Programming Instructions
(760) 438-7000 • FAX (760) 438-7043
USA & Canada (800) 421-1587 & (800) 392-0123
Toll Free FAX (800) 468-1340
www.linearcorp.com
Advertisement
Table of Contents
Related Manuals for Linear Access AK-2
Summary of Contents for Linear Access AK-2
- Page 1 INSTR,INSTL,AK-2 - LINEAR P/N: 218370 C - INK: BLACK - MATERIAL: 20 LB. MEAD BOND - SIZE: 8.500” X 11.000” - SCALE: 1-1 - FOLDING: ALBUM-FOLD - BINDING: SADDLE-STITCH AK-2 Digital Keyless Entry System Installation and Programming Instructions (760) 438-7000 • FAX (760) 438-7043 USA &...
-
Page 2: Table Of Contents
AK-2 OPERATION ........ -
Page 3: Component Locations
FACEPLATE KEYPAD BEEPER MOUNTING LEVEL JUMPER (JP1) PLATE Figure 1. Component Locations WIRING DIAGRAM TYPICAL DOOR INSTALLATION WIRING AK-2 TERMINALS TERMINAL TERMINAL BLOCK 2 BLOCK 1 12-24 VOLT 1 - AC OR DC SENSE - 8 POWER N.C. DOOR AC OR DC... -
Page 4: Installation
Install the Electrical Box and Mounting Plate INSTALLATION The keypad is designed to fi t into a standard single-gang electrical Before installing the keypad, the unit must be partially box. Select a location near the controlled door and choose a disassembled to access the mounting plate. -
Page 5: Keypad Wiring
❑ To avoid damage to the unit from static discharges, connect the EARTH GROUND terminal (TB1 #5) to a good earth grounding point. Suggested wiring size is 18 AWG for earth TERMINAL BLOCK 1 ground. AK-2 REAR VIEW N.C. DOOR SENSE - 8 SENSE SENSE INPUT COM - 7... -
Page 6: Factory Defaults
FORCED ENTRY OUTPUT ......... OUTPUT #3 The yellow indicator will fl ash quickly while the AK-2 searches its memory for DOOR AJAR OUTPUT . - Page 7 DEVICE COMMON Press: 1 6 # RELAY Output N.C. AK-2 = Output to Activate (0-4) Output OUTPUTS N.O. EITHER RELAY CAN TRIGGER 1 = Main Relay, 2 = Auxiliary Relay, 3 = Output #3, 4 = Output #4, 0 = No Output...
-
Page 8: Resetting Keypad
Default: No Selects whether or not the keypad beeps during Auxiliary Relay activation. Keypad users request access by entering their code. ❑ Users of the AK-2 have up to 40 seconds to key in their Press: 4 2 # Sound entry code.
