Slime 50123 Manual

Flat tire repair kit
Hide thumbs
1
2
3
4
5
6
7
8

Advertisement

Available languages

Available languages

Quick Links

Download this manual
SELECT MODE
AIR OR
AIR + SEALANT
BACKLIT
DIGITAL
GAUGE
PRESSURE RELEASE
Deflates tire
if it has too much air
ADAPTERS
PRESTA
BALL INFLATABLES
VALVE
VALVE
DEPRESSOR*
* VALVE DEPRESSOR IS TO BE USED WITH ACCESSORY ADAPTERS (SEE PAGE 2)
CAUTION: HOT • DO NOT HOLD IN HAND WHILE OPERATING • PLACE INFLATOR ON A HARD, CLEAN SURFACE.
1. DO NOT run vehicle while inflator is operating. You may need to be in "accessory" or "on" position.
Please make sure emergency brake is set and car is in park. Always ensure the valve connector is
fully seated to depress the core of the valve stem for proper inflation.
2. D O NOT use inflator continuously for more than 10 minutes. Allow unit to cool approximately 25
minutes between uses. Do not leave inflator unattended.
3. ALWAYS use a pressure gauge to check tire pressure. DO NOT overinflate.
4. Soft inflatables (i.e. rafts, balls, etc.) may not have recommended pressure markings. Be careful
not to inflate items beyond their capacity.
5. While operating, never block the inflator input or output.
6. Keep inflator out of reach of children.
7. For use with 12 volt DC power outlets rated 15 amps or higher. Do not use with older 8 amp
cigarette lighter receptacles.
ATTENTION! READ ALL INSTRUCTIONS CAREFULLY
FAILURE TO FOLLOW WARNING INSTRUCTIONS CAN RESULT IN FIRE,
SEALANT/
AIR HOSE
PERSONAL INJURY OR PROPERTY DAMAGE.
REPLACEABLE SLIME
SEALANT CARTRIDGE
# 10179
ON/OFF
POWER SOURCE
• Plugs into 12 volt,
15 amp power outlet
• 10ft. (3m) length
PART#50123 | REV022118ART

Advertisement

loading
Need help?

Need help?

Do you have a question about the 50123 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Slime 50123

Summary of Contents for Slime 50123

  • Page 1 6. Keep inflator out of reach of children. 7. For use with 12 volt DC power outlets rated 15 amps or higher. Do not use with older 8 amp cigarette lighter receptacles. ATTENTION! READ ALL INSTRUCTIONS CAREFULLY FAILURE TO FOLLOW WARNING INSTRUCTIONS CAN RESULT IN FIRE, PERSONAL INJURY OR PROPERTY DAMAGE. PART#50123 | REV022118ART...
  • Page 2 AIR ONLY INSTRUCTIONS: Check your tire warranty prior to installation of this product. The AIR ONLY mode can also be used for bicycles, sports balls, rafts and other inflatables. Select AIR ONLY. NOTE: Lay Flat Tire Repair Kit on the ground facing upward. Screw air/sealant hose onto tire’s valve stem. Plug inflator into 12 volt accessory power outlet. Do not run vehicle while inflator is operating. You may need to be in “accessory” or “on” position. Please make sure emergency brake is set and car is in park. Push green button to turn system on. Fill to desired pressure. Turn system off and check tire pressure. Once correct tire pressure has been achieved, disconnect air hose and power plug.

  • Page 3: Pressure Release

    Plug inflator into 12 volt accessory power outlet. Do not run vehicle while inflator is operating. You may need to be in “accessory” or “on” position. Please make sure emergency brake is set and car is in park. Push green button to turn system on. Gauge pressure will initially be high until the sealant bottle is emptied. Once bottle is empty the gauge pressure will drop and tire inflation begins. Fill to desired pressure. Turn system off and check tire pressure. Once correct tire pressure has been achieved, disconnect air hose and power plug. Drive two miles with speeds less than 25 miles per hour to disperse sealant throughout the tire, allowing it to seek out and seal the puncture. Recheck tire pressure to verify that the puncture has been sealed. At your earliest opportunity take your vehicle to a tire repair facility for a permanent professional repair. Inform tire repair specialist that Slime Sealant is in the tire. PRESSURE RELEASE The PRESSURE RELEASE ensures optimum PSI pressure. Push the area to deflate the tire if it has been overinflated, or if there is too much air prior to inflation. Check your gauge for the desired PSI level. NOTE: Correct tire pressure can be found in your vehicle’s owner’s manual or driver side doorjamb. SEALANT CARTRIDGE REMOVAL INSTRUCTIONS: Unwrap Lift off cartridge Rotate cartridge Pull cartidge out air/sealant hose. cover. to upright position. horizontally.

  • Page 4: Troubleshooting

    QUESTIONS OR COMMENTS: Call 1-888-457-5463 or visit www.slime.com ITW Global Tire Repair • 125 Venture Drive, Suite 210, San Luis Obispo, CA 93401 USA Slime® is a trademark of Illinois Tool Works, Inc., registered in the U.S. and other countries.
  • Page 5 CARTUCHO REEMPLAZABLE DE SELLADOR SLIME SELECCIONE EL Parte No. 10179 MODO AIRE O AIRE Y SELLADOR MEDIDOR BOTÓN DE DIGITAL CON ENCENDIDO ILUMINACIÓN POSTERIOR FUENTE DE ENERGÍA DESCARGA • Se conecta en una toma DE PRESIÓN de corriente de 12 V • 10 pies (3 m) de largo Desinfla la llanta si tiene demasiado aire MANGUERA DE ADAPTADORES AIRE/SELLADOR DEPRESOR DE VÁLVULA...
  • Page 6 INSTRUCCIONES “AIR ONLY”: Revise la garantía de su llanta antes de instalar este producto. En el modo AIRE SOLAMENTE se puede usar para bicicletas, pelotas para deportes, balsas y otros artículos inflables. Seleccione “AIR ONLY.” NOTA: Coloque Safety Spair sobre el piso volteado hacia arriba. Atornille la manguera de sellador/aire en el vástago de la válvula de la llanta. Enchufe el cordón eléctrico en la toma de corriente para accesorios de 12 voltios. NO PONGA EN MARCHA el vehículo cuando el compresor esté funcionando. Puede ser necesario tenerlo en la posición de “accesorios” o “encendido.” Asegúrese de haber puesto el freno de emergencia y de tener la palanca...
  • Page 7 Presione el botón verde para encender el sistema. Espere 6 minutos (en temperaturas por debajo de 32˚F espere 12 minutos). Puede quedar algo de sellador en la manguera. Apague el sistema y mida la presión de la llanta. Si se necesita inflar más, lea las instrucciones “AIR ONLY.” Desconecte el sistema cuando la presión de la llanta sea la correcta. Maneje dos millas a una velocidad inferior a los 40 kilómetros (25 millas) por hora para esparcir el sellador por la llanta y permitir que encuentre y selle el pinchazo. Revise nuevamente la presión de la llanta para verificar que se selló el pinchazo. Tan pronto como pueda, lleve su vehículo a un taller para que la reparación permanente sea por un profesional. Informe al especialista en reparaciones que hay Slime dentro de la llanta. DESCARGA DE PRESIÓN La DESCARGA DE PRESIÓN asegura una presión óptima en pies por pulgada cuadrada (PSI). Oprima para desinflar la llanta si está demasiado inflada o si tiene demasiado aire antes de inflarla. Verifique el medidor para obtener el nivel deseado de PSI. NOTA: La presión adecuada para las llantas se puede encontrar en el manual del propietario o en el marco de la puerta del conductor. INSTRUCCIONES PARA REMOVER EL CARTUCHO DE SELLADOR: Desenrolle la Levante la tapa del Gire el cartucho Tire del cartucho en manguera cartucho.

  • Page 8: Solución De Problemas

    PREGUNTAS O COMENTARIOS: Llamar al 1-888-457-5463 o visitar www.slime.com ITW Global Tire Repair • 125 Venture Drive, Suite 210, San Luis Obispo, CA 93401 USA Slime® es una marca registrada de Illinois Tool Works, Inc., registrada en Estados Unidos y en otros países.
