HazLoc Low Bay Supplemental Installation Guide
INSTALLING OPTIONAL DOME AND WIRE GUARD
Step 3. Gently pry glass lens off using a flat screwdriver
03/26/21
ETG-HLB
Step 1. From standard fixture with
glass lens, remove 8 pcs M4*16
screws holding outer plate and glass
lens on
LMAN0075-01-EN
HLB Supplement Installation Guide
Step 2. Remove outer plate
Step 4. Clean dome lens with alcohol
wipe.
Page 1
