- Page 1 Solutions for Fluid Technology 1011 10110 11011 OPERATING MANUAL for flow meters of the product line “VSI+ High Definition Flow Meter“...
-
Page 2: Table Of Contents
VSE reserves the right to make changes and substitutions. VSE is not liable for any printing errors. Reproduction, including excerpts, is permitted only after written approval by VSE. VSE reserves the right to modify technical data at any time. Last revised: 10/2021... -
Page 3: Important Information And Legal Notices
A missing manual or missing pages must be replaced immediately if lost. The operating instructions can be requested at any time from VSE or downloaded from our website www.vse-flow.com. The operating instructions must be passed on to each subsequent user of the flow meter. -
Page 4: General Function Description Of Flow Meter
Performance of the flow meter depends on type, size and meter for a trouble-free and safe operation of the flow meters. Owing to range and on the liquid that is to be measured. Please consult VSE for the great number of various applications and flow meter versions, the an exact description.. -
Page 5: Maximum Operating Pressure
= 700 bar/10100 psi Important: Please consult VSE for all operating pressures > 450 bar / 6500 psi and for special versions. 8. INFORMATION ON EU DIRECTIVE 2014/68/EU ON PRESSURE EQUIPMENT In terms of Article 2, No. 5 of the directive named above, VSE volume (1a). -
Page 6: Flow Meter Range
) refers to the testing fluid “hydraulic oil“ with a viscosity of riorates, while for fluids of higher viscosity (> 21 mm²/s) it can improve. 21 mm²/s at a temperature of 20°C. For this flow meter range, VSE Also note, however, that the flow meter range is restricted in case of specifies measurement accuracy of up to 0.3 % of the measurement... -
Page 7: Cleaning And Flushing Of Pipe Lines Before Initial Start-Up
11. CLEANING AND FLUSHING OF PIPE LINES BEFORE INITIAL START-UP Before initial start-up of the flow meter, you must flush and clean the VSE supplies bypass plates for all VSI-flow meter sizes. Flow meters are measurement pick-up systems made with high-level precision. They whole system. -
Page 8: Flow Meters With High Definition
13. FLOW METERS WITH HIGH DEFINITION The measuring volume of the flow meter is determined by the mechani- The output of the two 90° phase-shifted pulse signals via two channels cally displaced liquid volume within a tooth gap and the set interpola- also enables an edge evaluation (see figure 3). - Page 9 Table 3: Interpolation factor and resolution Interpolation Imp/V Max. resolution Resolution V Max. resolution Frequency f factor (evaluation of (volume (angle degrees) signal flanks) measurement V [ml] 90° 22,5° 11,25° 9° x 10 5,625° x 16 /128 2,8125° x 32 /256 1,40625°...
- Page 10 one measurement volume Vm 360° angle degrees channel Vm / 1 1. pulse 2. channel 1. channel Vm / 4 pulse pulse pulse pulse 2. channel channel Vm / 8 channel 1. channel Vm / 16 2. channel 0° 45° 90°...
- Page 11 Table 4: Volume measurement and max. frequency at high resolution Flow Vol. measurement Interpol. Vol. measurement V K-Faktor* meter IPF* (ml/pulse) (Imp/l) (Hz) 0.04 25000 1666.7 0.01 100000 6666.8 0.005 200000 13333.6 4 l/min 0.004 250000 16667 0.04 ml/Imp (= 4 000 ml/min 1,666.7 Hz 0.04…...
-
Page 12: Settings Of The Preamplifier
Table 4: Volume measurement and max. frequency at high resolution = physical volume measurement (size) of the flow meter (volume per tooth and per tooth gap) = max. flow (test conditions) = max. frequency at Q IPF* = programmable interpolation factor = all characters marked with * refer to IPF* = interpolated volume measurement * = V... -
Page 13: Pulse Filtering
15. PULSE FILTERING Oscillations in fluid systems manifest themselves through constant The filter memory contains a rotational movement over 8 teeth of the forward and backward movements of the liquid column, which is also meter. detected by the pair of toothed wheels or meter and converted into proportional electronic pulses or edge sequences. -
Page 14: Technical Specifications Of Preamplifier
17. TECHNICAL SPECIFICATIONS OF PREAMPLIFIER Pickup sensor 2 x AMR-sensor (sine and cosine signals) Configuration automatically Resolution Selectable standard 1, 4, 8, 10, 16, 32, 64, 128; alternative 2, 3, 5, 12, 24, 50, 100 (from SWV. 1B) Frequency up to 120kHz Signal outputs Channel A, Channel B Channel A and B... -
Page 15: Maintenance, Service Life And Warranty
20. STORAGE, RETURN AND DISPOSAL Temporary storage Disposal All VSE flow meters are supplied with sealing plugs and in suitable pack- VSE actively promotes environmental awareness and has an operational aging for all destinations and modes of transport to ensure optimum pro- management system that meets the requirements of ISO 9001:2015. -
Page 16: Technical Specifications Vsi 0.04 - Vsi 2
21. TECHNICAL SPECIFICATIONS VSI 0.04 / IPF – VSI 2 / IPF Size Measuring range Frequency Pulse value K-factor l/min /pulse Imp/liter VSI 0.04 0.004 … 4 1.667 * IPF … 1,666.67 * IPF 0.04 / IPF 25,000 * IPF VSI 0.1 0.01 …... -
Page 17: Flow Response Curves Vsi 0.04 - Vsi 2
22. FLOW RESPONSE CURVES VSI 0.04 – VSI 2 VSI 0,1 VSI 0,04 VSI 0.04 VSI 0.1 Flow Q Flow Q VSI 0,2 VSI 0.2 VSI 0.4 VSI 0,4 Flow Q Flow Q VSI 1 VSI 2 VSI 2 VSI 1 Flow Q Flow Q... -
Page 18: Dimensions Vsi 0.04 - Vsi 2
23. DIMENSIONS VSI 0.04 – VSI 2 Cast iron version Stainless steel version Connection diagram View X Housing without milled edge Plug position for VSI 0.04 to VSI 0.4 Centring bore hole Cast iron version Earth Connection diagram View X O-ring M12 x 1 Centring bore hole... -
Page 19: Dimensions Supplates Ap.0.2 - 1
Anschlussplatten AP. 24. DIMENSIONS SUPPLATES AP.0.2 – 1 Connection position, side Flow meter Subplate Anschlussbild Anschlussbild Connection drawing Connection drawing Volumensensor Volumensensor Flow Meter Flow Meter M../.. zur Befestigung der Platte M../.. zur Befestigung der Platte M../.. for fixing the subplate M../.. -
Page 20: Type Key
25. TYPE KEY Example VSI 0,2 / ..G P O 1 2 V - 4 2 R 1 1 / X Change code, factory definition 4 pin M12-connector 5 pin. M12-connector integrated 8…28V DC (VV - AMR standard) 2 pick-ups AMR - sensor FPM (Viton) standard... -
Page 21: Plug Assignment
Subplates AP … Example 26. PLUG ASSIGNMENT... -
Page 22: Connection Diagram
27. CONNECTION DIAGRAM Flowmeter VSI Evaluating unit (e.g. display) M12-standard + voltage (brown) +8-28V DC channel1 (white) signal- input 1 0 voltage (blue) channel2 (black) signal- input 2 Q: 8 l/min V: 11.53 l Rchtg: pos. f: 424.9 Hz PE/GND... -
Page 23: Certificate Of Non-Objection
(CERTIFICATE OF NON-OBJECTION) Last revised: 10/2021 Please reply to info @ vse-flow.com Flow meters, for which this certificate of conformity has not been completed and signed, cannot be inspected or repaired for safety reasons and will be returned unchecked at your expense. - Page 24 The undersigned is liable for all damages which arise as a result of the non-marked decontamination of the returned flow meter. VSE expressly points out that repairs and verification work is carried out by trusting the correctness of the completion of this safety declaration (certificate of non-objection). Should physical injuries, death or even damage to property occur, claims for damages will be asserted.
- Page 25 NOTES...
- Page 26 NOTES...
- Page 27 NOTES...
- Page 28 VSE Volumentechnik GmbH Hönnestraße 49 58809 Neuenrade / Germany Phone +49 (0) 23 94 / 6 16-30 +49 (0) 23 94 / 6 16-33 info@vse-flow.com www.vse-flow.com www.e-holding.de...
